The engine exhaust from this product contains chemicals
known to the State of California to cause cancer, birth defects,
or other reproductive harm.
Read and understand all provided literature before
use. Failure to do so could result in serious injury.
Note: This product complies with CAN ICES-2/NMB-2.
X7503323507
© 01/2021 ECHO Incorporated
Operator's
Manual
CS-355T
Chain Saw

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS-355T and is the answer not in the manual?

Questions and answers

Related Manuals for Echo CS-355T

Summary of Contents for Echo CS-355T

  • Page 1 State of California to cause cancer, birth defects, or other reproductive harm. Read and understand all provided literature before use. Failure to do so could result in serious injury. Note: This product complies with CAN ICES-2/NMB-2. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Introduction......................... 3 Servicing Information....................3 Parts and Serial Number..................3 Service ....................... 4 ECHO Consumer Product Support ..............4 Product Registration................... 4 Additional Literature ................... 4 Packing List ........................ 4 Safety ......................... 5 Rules for Safe Operation..................5 Correct Use of Chain Brake ................

  • Page 3: Introduction

    SERVICING INFORMATION Parts and Serial Number Genuine ECHO Parts and Assemblies for your ECHO products are available only from an Authorized ECHO Dealer. When you do need to buy parts always have the Model Number and Serial Number of the unit with you. For future reference write them in the space provided below.

  • Page 4: Service

    Due to packaging restrictions, some assembly may be necessary. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts. Power Head...

  • Page 5: Safety

    Kick Guard in place. Do not rely exclusively upon the safety devices built into your saw. As a chain saw user, you should take several steps to keep your cutting jobs free from accident or injury. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 6: Correct Use Of Chain Brake

    • If the brake is tripped by kickback Unlocked reaction, the chain will stop immediately. Release the throttle to avoid possible damage to the engine or clutch. • Do not attempt to operate the engine with the brake locked. X7503323507 © 01/2021 ECHO Incorporated...
  • Page 7 Chain brakes have been designed and tested to comply with international safety standards as follows: USA: ANSI Standard B175.1 Safety Requirement for chain saws Canada: CSA Standard Z62.1, Z62.3 X7503323507 © 01/2021 ECHO Incorporated...
  • Page 8 The impact should lock the chain brake. When checking the operation of the automatic chain brake, use a soft surface substance like wood to absorb the impact so the chain is not damaged. X7503323507 © 01/2021 ECHO Incorporated...
  • Page 9 (For example, if improper tools are used to remove the flywheel or if an improper tool is used to hold the flywheel in order to remove the clutch, structural damage to the flywheel could occur and could subsequently cause the flywheel to burst.) X7503323507 © 01/2021 ECHO Incorporated...
  • Page 10 Always wear proper safety clothing to protect your lower  body from sharp saw chain and hot muffler. Always keep exhaust area clear of flammable debris during  transportation or when storing, otherwise serious property damage or personal injury may result. X7503323507 © 01/2021 ECHO Incorporated...
  • Page 11 If damage or leaks are found, do not use unit, otherwise serious personal injury or property damage may occur. Have unit repaired by an authorized servicing dealer before using. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 12: Personal Condition And Safety Equipment

    Eye protection that meets ANSI Z87.1 or CE requirements ◆ must be worn whenever you operate the unit. For additional safety, a full-face shield can be worn over ◆ safety glasses or goggles to provide protection from sharp branches or flying debris. X7503323507 © 01/2021 ECHO Incorporated...
  • Page 13 Gloves also provide protection against cuts and scratches, cold environments, and reduce the transmission of machine vibration to your hands. Hearing and Ear Protection ECHO recommends wearing personal protective equipment whenever unit is used. Breathing Protection Operators who are sensitive to dust or other common airborne allergens may need to wear a dust mask to prevent inhaling these materials while operating unit.
  • Page 14 To reduce the risk of serious or fatal injury, persons with pacemakers should consult with their physician and the pacemaker manufacturer before operating this machine. In the absence of such information, ECHO does not recommend the use of this machine by anyone who has a pacemaker.
  • Page 15 Never touch wires directly or indirectly, otherwise serious injury or death can result. Do not operate this product indoors or in inadequately ventilated areas. Engine exhaust contains poisonous emissions and can cause serious injury or death. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 16: International Symbols

    Both of the operator’s hands must be used to Fuel and Oil Mixture operate the chain saw Hot Surface Chain Oil Fill Chain Oiler Chain Brake Operation Adjustment X7503323507 © 01/2021 ECHO Incorporated...
  • Page 17 Symbol Description Symbol Description Choke Control “COLD START” Position (Choke Closed) Purge Bulb Choke Control “RUN” Position (Choke Open) De-Compression STOP / Momentary Device STOP Switch Note: Not all symbols will appear on your unit. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 18: Manual Safety Symbols And Important Information

    Note: This enclosed message provides tips for use, care and maintenance of the unit. CIRCLE AND SLASH SYMBOL This symbol means the specific action shown is prohibited. Ignoring these prohibitions can result in serious or fatal injury. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 19: Emission Control (Exhaust & Evaporative)

    The 50 or 300 hour emission compliance period is the time span selected by the manufacturer certifying the engine emissions output meets applicable emissions regulations, provided that approved maintenance procedures are followed as listed in the Maintenance Section of this manual. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 20: Description

    Locate the safety decal(s) on your unit. Make sure the decal(s) is legible and that you understand and follow the instructions on it. If a decal cannot be read, a new one can be ordered from your ECHO dealer. Safety label is for example only. Your label my appear slightly different.
  • Page 21 Spark Arrestor Muffler or Spark Arrestor Muffler with Catalyst CHAIN SAW TERMS CHAIN BRAKE - Stops the saw chain. DRIVE SPROCKET - Drives saw chain. CLUTCH - Turns drive sprocket when engine rpm is fast enough to provide the power needed for cutting. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 22: Preparation For Use

    IMPORTANT: Dimple in Kick Guard must engage recess in guide bar. Tighten nut (G) and bolt by hand until snug. Make certain Kick Guard is flush against guide bar. Tighten nut (G) additional 1/2 turn. X7503323507 © 01/2021 ECHO Incorporated...
  • Page 23 (J) for correct position on clutch drum. If brake band is not in place around drum, remove sprocket guard, and reinstall. Tighten sprocket guard nuts finger tight. Adjust saw chain tension, as instructed in “Adjusting Chain Tension”. X7503323507 © 01/2021 ECHO Incorporated...
  • Page 24 Remove air cleaner cover and disconnect spark plug lead. Loosen sprocket guard nuts (A). Hold the bar nose up, and turn the adjuster (B) toward (+) until chain contacts underside of the bar. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 25: Operation

    Fuel Diesel fuels and alternative fuels, such as E-15 (15% ethanol), E- 85 (85% ethanol) or any fuels not meeting ECHO requirements are NOT approved for use in ECHO 2-stroke gasoline engines. Use of diesel or alternative fuels can cause performance...
  • Page 26 NOT approved. Use of ECHO branded fuel is recommended to extend engine life in all air-cooled 2-stroke and 2/4-stroke hybrid engines. Two Stroke Oil - A two-stroke engine oil, such as ECHO branded 2-stroke oils, meeting ISO-L-EGD (ISO/CD 13738) and J.A.S.O. FD Standards must be used.
  • Page 27 Vapors ignited by an ignition source can flash back to the fuel container, resulting in an explosion, fire, serious or fatal injuries, and extensive property damage. X7503323507 © 01/2021 ECHO Incorporated...
  • Page 28 • Empty the fuel tank prior to storing the unit. Return unused fuel to an approved fuel storage container. Stored two-stroke fuel can separate. ALWAYS shake fuel container thoroughly before each use. Used oil and gasoline, and soiled towels are hazardous waste materials. Disposal laws vary by locality. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 29: Chain Lubricant

    Metal cutters can also create sparks if the cutter strikes rocks, metal, or other hard objects. Contact local fire authorities for laws or regulations regarding fire prevention requirements. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 30: Starting Cold Engine

    Pull starter handle with right hand several times until first firing sound. Note: Do not pull starter rope out to maximum position. Do not allow recoil handle to snap back against the casing. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 31: Starting Warm Engine

    Make sure the bar and chain are free from any obstruction when starting the chain saw. Move chain brake lever fully FORWARD to LOCK chain brake before starting. Confirm there is fuel and chain oil in the tanks. X7503323507 © 01/2021 ECHO Incorporated...
  • Page 32 (chain brake unlocked position). Note: If engine does not start after 5 pulls, use Start Cold Engine procedure. Do not increase engine speed while chain brake is locked. Severe brake damage will result. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 33: Running

    Do not run the engine at high speed unnecessarily. Be sure that saw chain stops moving when throttle trigger is released. Stopping Release throttle trigger and allow engine to idle. Move control lever (A) REARWARD to “STOP” position. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 34: Checking Chain Tension

    This chain saw is designed for cutting wood. Do not cut ◆ metal, plastic or any non-wood material. Wear suitable hearing ◆ protection such as earmuffs or earplugs to protect against objectionable or uncomfortable loud noises. X7503323507 © 01/2021 ECHO Incorporated...
  • Page 35 It is not necessary to press down hard to make the saw cut. Pushing the saw too hard will slow the engine and cutting will actually be more difficult. X7503323507 © 01/2021 ECHO Incorporated...
  • Page 36 5 seconds or engine damage can occur. Keep chain properly tensioned during operation to prevent ◆ the chain from jumping out of the guide bar rail slot and damaging metal engine parts. X7503323507 © 01/2021 ECHO Incorporated...
  • Page 37 5 cm (2 in.) will act as a One-third tree diameter hinge when the tree falls, guiding it in the desired direction. When the tree starts to fall, kill the engine, place the saw on the ground and make your retreat quickly. X7503323507 © 01/2021 ECHO Incorporated...
  • Page 38 Always use both hands. Don’t cut with the saw overhead or aligned vertically with your body. If the saw should kick back, you may not have enough control to prevent possible injury. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 39: Guide Bar And Saw Chain Combinations

    To cut the trunk, use the bucking and two-cut sequence shown. The first cut should be no deeper than one-third the trunk diameter. Guide Bar and Saw Chain Combinations The following combinations are recommended for model CS-355T. Guide Bar Saw Chain ECHO Part No.

  • Page 40: Kick Guard Tm

    (Optional) To purchase an optional Kick Guard contact your dealer. For the name of the dealer nearest you, For ECHO, Call: 1-800-432-ECHO (3246) or on the web at www.echo-usa.com. For Shindaiwa, Call: 1-877-986-7783 or on the web at www.shindaiwa-usa.com. Guide Bar (Low-kickback) Replacement guide bars.

  • Page 41: Maintenance

    Level 1 = Easy to do. Common tools may be required. Level 2 = Moderate difficulty. Some specialized tools may be required. Level 3 = See your dealer. Click HERE or go to http://www.echo-usa.com/products/maintenance-kit HERE https://www.shindaiwa-usa.com/you-can.aspx For information about maintenance kits.

  • Page 42: Maintenance Intervals

    Inspect / Replace * Fuel Filter Inspect * Fuel Cap Gasket Inspect * Spark Plug Inspect / Clean / Replace * Muffler Spark Arrestor Inspect / Clean / Replace * Cylinder Exhaust Port Inspect / Clean / De-carbon X7503323507 © 01/2021 ECHO Incorporated...

  • Page 43: Carburetor Adjustment

    Arrestor Screen”. Make sure the bar and chain are properly adjusted. Start engine and run several minutes to bring to operating temperature. Flash choke twice during warm-up to clear any air from the fuel system. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 44: Lifting Hook

    If damaged or broken, do not continue using the unit with the lifting hook. If you have any doubt of serviceability, have the unit checked out by your nearest authorized ECHO dealer. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 45: Air Filter

    • Do not allow dust to enter fuel tank. • A clogged Fuel Filter will cause difficulty in starting engine or abnormalities in engine performance. Pull Fuel Filter (A) out through gas port, and inspect it. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 46: Automatic Oiler

    • Always check oil discharge when in use. • Turn Adjusting Screw (A) counterclockwise to increase oil volume, clockwise to decrease oil volume. • Do not turn the Adjusting Screw beyond the maximum or minimum limit of volume adjustment. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 47: Oil Filter

    • When the sprocket has worn 0.5 mm (0.020 in.) or more, replace it. • Check sprocket and the clutch and clean the bar mount area before installation of the bar. • Replace either or both if worn. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 48: Cooling System Cleaning

    USDA Forest Service Regulation SAE J335. Check with your local or state authorities for specific regulations in your area. Failure to follow these requirements is a violation of the law. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 49: Spark Arrestor Screen

    As needed: Muffler gasket Remove spark plug lead. Place piston at top dead center. Remove Bolts (A) that attach Muffler Cover (B) and remove cover. Remove muffler (C). Check parts for wear or damage, and replace if necessary. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 50: Setting The Saw Chain

    • Keep the cutters sharp at all times. • Keep the left and the right cutters properly aligned. • Note that blunt or irregular cutters will result in poor cutting performance, increased vibration of chains and premature breakage of the saw chain. X7503323507 © 01/2021 ECHO Incorporated...
  • Page 51 • Place depth gauge tool firmly on Depth Gauge Tool guide bar so that depth gauge protrudes. Then file top of depth gauge with the flat file until flat with top of the depth gauge tool. X7503323507 © 01/2021 ECHO Incorporated...
  • Page 52 • If the saw chain becomes soiled with resin, for instance, Parallel depth gauge clean it with kerosene and soak in it oil. To sharpen other chains, follow chain manufacturer’s instructions. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 53: Troubleshooting

    Clean or replace runs, but Fuel filter Contaminants Replace filter or dies Fuel filter dirty or residue in fuel replace fuel Engine Fuel vent Contaminated Fuel vent Clean or replace does not plugged fuel accelerate properly X7503323507 © 01/2021 ECHO Incorporated...

  • Page 54: Storage

    • Inspect and adjust every part of the chain saw. • Completely clean every part and repair if necessary. • Apply thin coating of oil on metal parts to prevent rust. • Remove chain and guide bar. X7503323507 © 01/2021 ECHO Incorporated...

  • Page 55: Specifications

    Do not lend or rent your chain saw without the Operator’s Manual. Note: • For future reference, you should keep this Operator’s Manual. • If this Operator’s Manual becomes illegible or is lost, please contact your dealer, or go to www.echo-usa.com. SPECIFICATIONS Model CS-355T 220 mm (8.7 in.)

  • Page 56: Product Registration

    Please go to http://www.echo-usa.com/Warranty/Register-Your-ECHO to register your new product on-line. It's FAST and EASY! NOTE: your information will never be sold or misused by ECHO, Incorporated. Registering your purchase enables us to contact you in the unlikely event of a service update or product recall, and verifies your ownership for warranty consideration.
  • Page 57 CS-355T PRODUCT REGISTRATION X7503323507 © 01/2021 ECHO Incorporated...
  • Page 58 NOTES CS-355T NOTES X7503323507 © 01/2021 ECHO Incorporated...
  • Page 59 CS-355T NOTES NOTES X7503323507 © 01/2021 ECHO Incorporated...
  • Page 60 C67415001001 - C67415999999 ECHO INCORPORATED 400 Oakwood Road Lake Zurich, IL 60047 www.echo-usa.com...
