  • Page 1 * Assembly Guide & Warranty Card Included M SERIES ELLIPTICAL OWNER’S MANUAL Revision 022514...
  • Page 2 M SERIES ELLIPTICAL OWNERS MANUAL IMPORTANT: All Products shown are prototype. Actual product delivered may vary. Product specifications, features & software are subject to change without notice. For the most up to date owner’s manual please visit www.truefitness.com. For documents in additional languages please visit www.truefitness.com/document-library/29/international-manuals IMPORTANTE: Todos los productos mostrados son prototipos.
  • Page 3 The proud manufacturing tradition of quality and the culture of innovation at TRUE have given rise to a full line of truly extraordinary treadmills, indoor cycles and elliptical cross-trainers. As a result, people all over the world are benefiting from the TRUE experience.

  • Page 4: Table Of Contents

    Assembly Steps Reporting Freight Claims or Parts Damage Chapter 3: Product Overview Chapter 7: Additional Information Elliptical Overview Troubleshooting M30 Specification Sheet Chapter 4: Programming & Operation M50 Specification Sheet Warranty Registration Heart Rate Monitoring Heart Rate Control Program Descriptions...

  • Page 5: Chapter 1: Safety Instructions

    Do not modify the plug provided with this product. If it will not fit an electrical outlet, have a proper outlet installed by a qualified electrician. Your TRUE Fitness product must be properly grounded to reduce risk of shock if the elliptical malfunctions.
  • Page 6 To disconnect, turn power OFF at the ON/OFF switch if applicable, then remove plug from electrical outlet. • Never operate a TRUE product if it has a damaged power cord or electrical plug, or if it has been dropped, damaged, or even partially immersed in water. Contact TRUE Customer Service.

  • Page 7: Space Requirements

    SPACE REQUIREMENTS: • TRUE’s recommendation is to leave a 39” safety zone at rear of elliptical. The sides of the unit should be at least 20” away from the wall or obstructions. (See Fig 1) Truefitness.com / 800.426.6570 / 636.272.7100...

  • Page 8: Grounding Instructions

    CHAPTER 1: SAFETY INSTRUCTIONS GROUNDING INSTRUCTIONS: This product must be grounded, if it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug.

  • Page 9: Power Requirements

    CHAPTER 1: SAFETY INSTRUCTIONS Truefitness.com / 800.426.6570 / 636.272.7100...

  • Page 10: Warning Decals

    CHAPTER 1: SAFETY INSTRUCTIONS WARNING DECALS: WARNING: Replace warning labels that may be worn, damaged or missing. *To replace any worn or missing warning decals contact TRUE FITNESS by one of the following: www.truefitness.com or contact customer service at 800-883-8783. COMPLIANCES: This equipment complies with all applicable codes and regulations.

  • Page 11: Chapter 2: Assembly Instructions

    • Please save these instructions for future reference. *Should you need technical assistance in assembly of your TRUE Fitness product, contact TRUE Fitness Technical Support at 1-800-883-8783. PRE-ASSEMBLY CHECK LIST:...
  • Page 12 Console Set Pedal Tube –Right Center Trim Cover Balance Bar Pedal Tube Pivot Cover –A Upper Arms *M30 ONLY Pedal Tube Pivot Cover –B Upper Multi-Grip Arm (LH) *M50 ONLY Water Bottle Upper Multi-Grip Arm (RH) *M50 ONLY Chest Strap Upper Pivot Cover –A (LH)
  • Page 13 CHAPTER 2: ASSEMBLY INSTRUCTIONS PRE-ASSEMBLY CHECK LIST (continued): Item Description Bolt M10Xp1.5x135 Bolt M10xP1. 5x80 Nut M10xP1.5 Bolt M10xP1. 5x85 Wavy Washer Bolt M10xP1. 5x20 Washer Ø10x Ø30x3.0t Bolt M8xP1.25x12 Bolt M6xP1.0x15 Screw M5xP0.8x12 Screw Ø4x 16 Screw Ø3x 16 Truefitness.com / 800.426.6570 / 636.272.7100...

  • Page 14: Assembly Steps

    CHAPTER 2: ASSEMBLY INSTRUCTIONS ELLIPTICAL ASSEMBLY STEPS: CAUTION: For safety reasons, two people are required to assemble elliptical. Step 1. Console Mast: a) Slide the console mast (B) into frame (A). b) Insert 3 Bolts (a) in holes at front of frame and engage the threads.
  • Page 15 CHAPTER 2: ASSEMBLY INSTRUCTIONS ELLIPTICAL ASSEMBLY STEPS (continued): Step 3. Balance Bar: a) Attach balance bar (G) to console mast (B) as follows: Connect the wire as shown in detail view figure 3-1. b) Start the 5 screws (i) in holes first. One person holds the balance bar (G), the other person installs the 5 screws.
  • Page 16 CHAPTER 2: ASSEMBLY INSTRUCTIONS ELLIPTICAL ASSEMBLY STEPS (continued): Step 5. Pedal Tube: a) Mount the left pedal tube (E) with swing arm assembly (C), one person needs to hold the rear end of pedal tube to align it. Please ensure the pedal tube is aligned on the center of roller as shown in figure 5-1.
  • Page 17 CHAPTER 2: ASSEMBLY INSTRUCTIONS ELLIPTICAL ASSEMBLY STEPS (continued): Step 6. Upper Exercise Arms a) Place the upper exercise arms (H M30) (H1 & H2 M50) onto swing arms (C) and (D) stub shafts and fasten using 3 bolts (h) each.
  • Page 18 CHAPTER 2: ASSEMBLY INSTRUCTIONS ELLIPTICAL ASSEMBLY STEPS (continued): Step 7. Upper Pivot Cover and Display Console: a) Locate the left pivot cover parts (I) and (K) and install using 5 screws (l). Locate the right pivot cover set (J) and (L) and same use 5 screws (l) to fasten the covers.

  • Page 19: Chapter 3: Product Overview

    CHAPTER 3: PRODUCT OVERVIEW ELLIPTICAL OVERVIEW: Upper Exercise Arms Console Assembly (M50) Upper Exercise Arms (M30) Contact Heart Rate Pads Foot Pads Side Steps Power Cord Leveling Feet Truefitness.com / 800.426.6570 / 636.272.7100...
  • Page 20 Upper Exercise Arms (M50): Ergonomic Multi-Grip Handles that provide resistance to the upper body during a workout. Upper Exercise Arms (M30): Protective dipped foam exercise arms that provide resistance to the upper body during a workout. Contact Heart Rate Pads: Allows the user to check their heart rate without wearing a wireless chest strap.

  • Page 21: Chapter 4: Programming & Operation Heart Rate Monitoring

    HEART RATE CONTROL (HRC): Introduction: You are now the owner of the most sophisticated Heart Rate Control equipment available. TRUE HRC is unique and patented. It accommodates users from rehabilitation to world class athletes, and all those in between. TRUE HRC allows users to do a completely adjustment free heart rate controlled workout.
  • Page 22 HEART RATE CONTROL (continued): The TRUE HRC system is unique because users must enter the key parameters of the workout; target heart rate, weight, age, and time, prior to beginning the HRC workout. As users approach their target heart rate, the elliptical’s computer takes full control over the workout and changes the workout intensity automatically to keep users near their target heart rate.

  • Page 23: Program Descriptions

    CHAPTER 4: PROGRAMMING & OPERATION PROGRAM DESCRIPTIONS: Quick Start: A workout in which the user controls all settings. The workout continues until it is ended by the user. Manual: Users set up their own workout to a TIME or DISTANCE limit Rolling Hills: A series of gradual increasing and decreasing WORKLOAD changes that simulate rolling hills.

  • Page 24: Console Overview

    CHAPTER 4: PROGRAMMING & OPERATION CONSOLE OVERVIEW: Upper LED Lower LED Cardio 360™ HRC Cruise Target Display Display Display Quick Start Control Decrease Increase Workload Workload Start Workout Change Enter Reading Warning Target Finder Display Rack Decal Truefitness.com / 800.426.6570 / 636.272.7100...
  • Page 25 CHAPTER 4: PROGRAMMING & OPERATION CONSOLE OVERVIEW (continued): Workload Keys: Manually increases or decreases the workout intensity. Start: Allows the user to begin a Quick Start workout or preset workout. Workout Finder: Pressing this button scrolls through available workouts. When the desired workout is displayed, the user must press enter to input user data and begin the workout.

  • Page 26: Console Navigation

    CHAPTER 4: PROGRAMMING & OPERATION CONSOLE OVERVIEW (continued): Upper LED Display: Shows the workout data of the program in progress in four value displays. Value Display #1 Value Display #2 Value Display #3 Value Display#4 Heart Rate – Beats per Time –...
  • Page 27 CHAPTER 4: PROGRAMMING & OPERATION CONSOLE NAVIGATION (continued): Workout Data Entry: Before beginning a preset workout, the console will ask the user for information in order to give more accurate workout data. To adjust the Data Value (A), use the Up and Down Workload Keys (B). Once the desired value is displayed, press Enter (C) to move to the next Data Value.
  • Page 28 Cardio 360™: TRUE’s unique Cardio 360™ is like having a personal trainer built in to the elliptical, walking users through a full-body workout. In just minutes, users will work their upper-body, lower-body and core. Plus, with the variety that Cardio 360™...

  • Page 29: Advanced Console Functions

    ADVANCED CONSOLE FUNCTIONS: WARNING: Misconfiguration of the console may cause damage to the unit and void the manufacturer warranty. If necessary, please contact TRUE Fitness Technical Support at 800-883-8783 for assistance. Entering Diagnostics Mode: With the console powered up Press and hold the + WORKLOAD key for 10 seconds or until the console beeps. NOTE: If the sound is turned off no beep will be emitted from the console.

  • Page 30: Chapter 5: Care & Maintenance

    CAUTION: Do not use any acidic cleaners. Doing so will weaken the paint or powder coatings and may void the TRUE Fitness Warranty. Never pour water or spray liquids on any part of the elliptical. Allow the elliptical to dry completely before using.

  • Page 31: Leveling The Unit

    If the elliptical is not level the user may experience knocking or clicking sounds. OTHER SCHEDULED PREVENTIVE MAINTENANCE: TRUE recommends that quarterly scheduled maintenance be performed by a qualified service technician. Please contact your dealer or visit www.truefitness.com to contact a local TRUE authorized service technician.

  • Page 32: Chapter 6: Customer Service

    HOURS OF OPERATION: 8:30 A.M. - 5:00 P.M. CST E-MAIL: service@truefitness.com CONTACTING SALES: Interested in TRUE Products? Please contact us with any sales or product inquires so that we may direct you to the appropriate sales representative to answer your questions. TRUE FITNESS HOME OFFICE 865 HOFF ROAD ST.

  • Page 33: Reporting Freight Claims Or Parts Damage

    Severe Damage: Obvious damage to external packaging / internal product. Please refuse the shipment and it will be returned to TRUE Fitness by the carrier. Contact the TRUE Fitness customer support team by calling 800.883.8783 or sales support team by calling 800.426.6570 Monday-Friday during normal business hours to notify us that the shipment has been refused.

  • Page 34: Chapter 7: Additional Information

    *This troubleshooting guide is intended to assist in diagnostics only and is not all inclusive. Technical specifications, error codes and programming are subject to change without notice. TRUE accepts no liability for any damage or loss suffered by persons whom rely wholly or in part on any description or statement contained within this manual. Please visit www.truefitness.com to obtain the most recent version of all manuals and contact the TRUE Service Department at 800-...
  • Page 35 CHAPTER 7: ADDITIONAL INFORMATION TROUBLESHOOTING GUIDE (continued): Malfunction Possible Cause Corrective Action Transmitter belt contacts are not making good contact Readjust the transmitter belt so that it is in full contact with the skin with the skin Contacts on the transmitter Moisten the contacts on the transmitter belt belt are not moist Transmitter belt is not...

  • Page 36: M30 Specification Sheet

    P r e m i u m F i t n e s s E q u i p m e n t S i n c e 1 9 8 1 With one of the smallest footprints on the market, the M30 is a space-friendly total body trainer built with you in mind.
  • Page 37 CHAPTER 7: ADDITIONAL INFORMATION ELLIPTICAL TECHNICAL Power Source 110V/15A SPECIFICATIONS Cord Length 8' (2.4M) Drive System Core Drive Total Body Workout Cardio 360 Resistance Source Eddy Current Brake Maximum Workload 300 Watts Frame Construction Robotically Welded Heavy-Gauge Steel Stride Length 21"...

  • Page 38: M50 Specification Sheet

    Featuring ergonomic multi-grip handles, and orthopedic cushioned footpads, the M50 elliptical is equipped with premium user-focused features. Paired with TRUE's legendary patented Heart Rate Control technology and HRC Cruise Control, the M50 elliptical truly maximizes your fitness investment. Plus with one of the smallest footprints on the market, it’s a...
  • Page 39 CHAPTER 7: ADDITIONAL INFORMATION ELLIPTICAL TECHNICAL Power Source 110V/15A SPECIFICATIONS Cord Length 8' (2.4M) Drive System Core Drive Total Body Workout Cardio 360 Resistance Source Eddy Current Brake Maximum Workload 300 Watts Frame Construction Robotically Welded Heavy-Gauge Steel Stride Length 21"...

  • Page 40: Warranty Registration

    Labor All TRUE® Fitness products are distributed by TRUE and are warranted to the original registered Product purchaser and the parts of the TRUE Labor is covered for a period of one year from the date of purchase unless otherwise expressed within this limited warranty as long as a product (the “Product”) listed below, under normal use and service,...
  • Page 41 7. This Limited Warranty is in lieu of all warranties, express or implied, and in lieu of all other obligations or liabilities on the part of TRUE, under no circumstances shall TRUE be liable by virtue of this Limited...
  • Page 42 If you prefer to mail your warranty card, have the owner of the product complete the information below and return it to TRUE Fitness within 30 days from the date of equipment installation.
