  • Page 1 M e r c h a n d i s e r ® C o u n t e r t o p Models: SC-24/2S SC-36/2S • I N STALLATION • OPERATION • MAI NTENANCE W 1 6 4 N 9 2 2 1 W a t e r S t r e e t • P. O . B o x 4 5 0 • M e n o m o n e e F a l l s , W i s c o n s i n 5 3 0 5 2 - 0 4 5 0 U S A : 262.251.3800 •...
  • Page 2 ® D E L I V E RY U N PA C K I N G 1. Carefully remove the This Alto-Shaam appliance has been appliance from the thoroughly tested and inspected to insure only carton or crate. the highest quality unit is provided. Upon...
  • Page 3 SAFETY PROCEDURES A N D P R E C A U T I O N S Knowledge of proper procedures is essential to the 1. This appliance is intended to cook, hold or safe operation of electrically and/or gas energized process foods for the purpose of human equipment.

  • Page 4: Site Installation

    This Alto-Shaam appliance is designed for the purpose of maintaining hot food at a temperature INSTALLATION REQUIREMENTS for safe consumption. The unit must be...
  • Page 5 I N S T A L L A T I O N SITE INSTALLATION 2-1/2" (65mm) 24" (610mm) S C - 2 4 / 2 S 11" (282mm) 29" (739mm) O P T I O N S & A C C E S S O R I E S Exterior Dimensions S C - 2 4 Divider Bar Kit 5004543...

  • Page 6: Electrical Connection

    I N S T A L L A T I O N ELECTRICAL CONNECTION 1. An identification tag is permanently mounted 230V: To prevent an electrical shock hazard on the unit. between the appliance and other appliances or metal parts in close vicinity, an equalization- bonding stud is provided.

  • Page 7: Operation

    Do not block the top vent by covering FOR USE WITH PRE PACKAGED FOODS ONLY with utensils, signs, plates, etc. SC-24/2S: 12 wrapped sandwiches per shelf ✧ To avoid personal injury and damage to the unit, treat glass with care. SC-36/2S: 24 wrapped sandwiches per shelf Remember ––...
  • Page 8 O P E R A T I O N switch switch bottom shelf top shelf LIGHT BEFORE INITIAL USE: The proper temperature range for the Before operating, clean the exterior with a food being held will depend on the food clean, damp cloth and mild soap solution.

  • Page 9: General Holding Guidelines

    O P E R A T I O N GENERAL HOLDING GUIDELINES Chefs, cooks and other specialized food service personnel employ varied methods of H O L D I N G T E M P E R A T U R E R A N G E cooking.

  • Page 10: C L E A N I N G A N D P R E V E N T I V E M A I N T E N A N C E

    C A R E a n d C L E A N I N G C L E A N I N G A N D P R E V E N T I V E M A I N T E N A N C E PROTECTING STAINLESS STEEL SURFACES CLEANING AGENTS It is important to guard against...
  • Page 11 C A R E a n d C L E A N I N G The cleanliness and 4. Avoid the use of appearance of this abrasive cleaning equipment will contribute compounds, chloride considerably to operating efficiency and savory, based cleaners, or appetizing food.
  • Page 12 S A N I TAT I O N Food flavor and aroma are usually so closely The most accurate method of measuring safe related that it is difficult, if not impossible, to temperatures of both hot and cold foods is by separate them.
  • Page 13 S E R V I C E Part Number Description SC-24 SC-36 Side panel 1003312 1003312 Top cover 1003885 1003313 Guard, front shelf 1003880 1003319 Control BA-34294 BA-34294 Power Supply BA-33554 BA-33554 Terminal Block BK-3019 BK-3019 Thermistor block, shelf BK-33546 BK-33546 Cord Bushing BU-3964...
  • Page 14 SERVICE SC-36/2S Operator Side Power & Light Switches SW-3887 Panel Overlay PE-26096 Top Cover 1003313 for SC-36 1003885 for SC-24 Side Cover Control Knobs 1003312 KN-26290 Identification Tag GFCI Breaker CI-34157 Rubber Foot Pad DR-2969 # 8 7 5 • I N S TA L L AT I O N / O P E R AT I O N / S E RV I C E M A N U A L • 13.
  • Page 15 SERVICE Control Control Bushing BA-26247 BA-26247 BU-3964 FA-3973 FA-3974, 230V Power & Light Switches SW-3887 Power Supply BA-33554 Ballast SC-36/2S LP-34135 with top panel LP-34123, 230V removed SC-36/2S with side panel removed Lamp Bulb SC-36: LP-34156 LP-33822, 230V SC-24: LP-34151 LP-33822, 230V Receptacle Glass Shelf...
  • Page 16 # 8 7 5 • I N S TA L L AT I O N / O P E R AT I O N / S E RV I C E M A N U A L • 15.
  • Page 17 # 8 7 5 • I N S TA L L AT I O N / O P E R AT I O N / S E RV I C E M A N U A L • 16.
  • Page 18 # 8 7 5 • I N S TA L L AT I O N / O P E R AT I O N / S E RV I C E M A N U A L • 17.
  • Page 19 # 8 7 5 • I N S TA L L AT I O N / O P E R AT I O N / S E RV I C E M A N U A L • 18.

  • Page 20: Limited Warranty

    ALTO-SHAAM, INC. RECORD THE MODEL AND SERIAL NUMBER OF THE APPLIANCE FOR EASY REFERENCE. ALWAYS REFER TO BOTH MODEL AND SERIAL NUMBER IN ANY CONTACT WITH ALTO-SHAAM REGARDING THIS APPLIANCE. Model: Date Installed:...
