Summary of Contents for Edgewater Networks 4610W
- Page 1 4610W Network Services Gateway Quick Start Guide Version 1.0 Page 1 of 7 EWN015-05-A001...
-
Page 2: Before You Start
Additional configuration needed to deploy the device in a specific environment can be performed with the help of online help. This guide also provides an example of a typical 4610W device deployment that can be used as a guideline for your installation. -
Page 3: Step 1 ! Connecting The Cables
Figure 1: 4610W Front Panel 1. Connect one end of an Ethernet cable to local LAN port 24 of the 4610W device. This port can be seen in the area “C” of the above diagram. Connect the other end of the cable to your computer’s Ethernet port. - Page 4 8. Plug one end of the power adapter into an AC outlet and the other end into the power receptacle of the 4610W device (shown below as “B” in Figure 2). Make sure that the power and status LEDs (shown above as Figure 1 as “A” and “B”) are solid green after a short while.
- Page 5 Step 2 ! Configuring the EdgeMarc 1. The EdgeMarc device comes preconfigured with 192.168.1.1 local LAN address with a subnet mask of 255.255.255.0. So configure your computers Ethernet adapter’s IP address to any address other than 192.168.1.1 in the same subnet mask, for example 192.168.1.10.
-
Page 6: Step 3 ! Plan Your Configuration
Step 3 ! Plan Your Configuration The EdgeMarc 4610W Network Services Gateway can be deployed as a gateway router in a network. It can also be deployed in a network behind an existing firewall. Based on your deployment criteria, consult the VoIP Operating System (VOS) for EdgeMarc User Manual for... - Page 7 The web page configurations for the various 4610W device deployments are shown below. The two darker-shaded rows indicate the minimum configuration required for each deployment. 4610W Device 4610W 4610W Device within 4610W Device behind GUI Configuration Device as existing infrastructure...
