VENTS-US - TT PRO SERIES- INLINE FAN
INSTALLATION GUIDE
IN-LINE MIXED FLOW TURBO TUBE FANS
TT PRO 100/125/150
INSTALLATION
Pencil

MOUNTING

Fans may be mounted either vertically or horizontally.We recommend minimum 8' of insulated flexible duct between any exhaust grill and fan for low noise level. Outlet flange
should always be connected to an air duct.
Vents-US
400 Murray Road, Cincinnati, OH 45217, USA
Tel: 1-888-640-0925, 513-583-5786, Fax: 513-268-4597
E-mail: support@ventsus.com
www.vents-us.com
#2 Chootoo Road, South Aranguez, San Juan, Trinidad
INSTALLATION GUIDE

Tools required

Drill
Screwdriver
Typical installation of the fan
min 8 inch
min 8 inch
Dowel (4 pcs.)
Screws (4 pcs.)
MIU_08EN-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TT PRO 100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Vents-us TT PRO 100

  • Page 1 VENTS-US - TT PRO SERIES- INLINE FAN INSTALLATION GUIDE INSTALLATION GUIDE IN-LINE MIXED FLOW TURBO TUBE FANS TT PRO 100/125/150 INSTALLATION Tools required Pencil Drill Screwdriver Dowel (4 pcs.) Screws (4 pcs.) MOUNTING Fans may be mounted either vertically or horizontally.We recommend minimum 8’ of insulated flexible duct between any exhaust grill and fan for low noise level. Outlet flange should always be connected to an air duct.
  • Page 2 VENTS-US - TT PRO SERIES- INLINE FAN INSTALLATION GUIDE 1) Disconnect the fan from power supply. 2) Deinstall the fixing brackets. 3) Remove the fan from the casing. 4) Mark holes on the wall. 5) Drill the holes and insert the expansion anschors.
  • Page 3 VENTS-US - TT PRO SERIES- INLINE FAN INSTALLATION GUIDE The fan must be connected using durable, insulated and heat-resistant cables and wires. Connection of the fan and standard wall socket Connect the cables according to the wiring diagram. BREAKER BOX...
