OUTPUTS SPECIFICATIONS AND CONNECTIONS

Contact type
Disconnection type
Rated current by output
Maximum inrush current
Dropping voltage
Outputs per common (channel)
Different phases connection
Maximum current
Connection type
Recommended cable section
Cable type
Maximum response time
Contact type
No. of automatic cycles (A)
per automatic action

INPUT SPECIFICATIONS AND CONNECTIONS

CONCEPT
Number of inputs per common
Input voltage
Input current
Input impedance
Switching type
Connection method
Max. cable length
NTC probe length
NTC accuracy (@ 25ºC)
Temperature measure precision
Cable cross-section
Response time
Any combination of the next accessories is allowed in the inputs:
Temperature Probe
Temperature
probe
references:
ZN1AC-NTC68E
ZN1AC-NTC68F
ZN1AC-NTC68S
(1) The micro switch number 2 in the ZN1IO-DETEC-P must be in Type B position to
( )
*
In order to guarantee the correct functioning of relays when several outputs are controlled jointly, it is necessary to place the
Motion sensor reference:
ZN1IO-DETEC actuator as close as possible to the KNX power supply. A 29VDC KNX power supply is recommended.
ZN1IO-DETEC-N
(1)
ZN1IO-DETECT-P

SAFETY INSTRUCTIONS


Do not connect Main Voltage (230 V) or any other external voltages to any point of the BUS.
Connecting an external voltage might put the entire KNX system at risk.

Flexible cable with crimping terminals or rigid cable without terminals must be used for output connection.

Make sure during the installation that there is always sufficient insulation between the mains voltage 230V and the bus or
the extension inputs.

Once the device is installed, the output terminal should not be accessible.
Technical Documentation
© Zennio Avance y Tecnología S.L.
Potential free outputs through bistable
relays with tungsten pre-contact.
Micro-disconnection
16A * 250V AC (4000 VA)
16A * 30V DC (480W)
800A/200μs (fluorescent lamps)
165A/20ms (resistive lamps)
Negligible
1 individual output
Possibility to connect different phases in
adjoining outputs
60A
Terminal block (screw)
0.25 mm² to 4 mm² (26-10 AWG)
Stranded or solid wire
50 ms
Potential free outputs through bistable
relays with tungsten pre-contact.
Mechanical
3 million operations (60cpm)
(min)
Electrical 100.000 cycles at Max. current (6cpm
(min.) and resistive load)
DESCRIPTION
6
+3.3V DC for the common
1.0mA @ 3.3V DC (each input)
Aprox. 3.3kΩ
Dry voltage contacts
input and common
Cable screw terminal
30 m.
1.5 m.
0.5ºC
0.1ºC
0.15 mm² to 2.5 mm² (26-12 AWG)
Max 10ms.
Motion Sensor
Edition 3
Attaching MAXinBOX66 to DIN rail:
between
Removing MAXinBOX66 from DIN rail:
Up to two motion sensors
can be plugged into the
same MAXinBOX66 input
(parallel wiring)
Motion sensor cable screw
terminal.
Motion sensor references:
ZN1IO-DETEC-P
ZN1IO-DETEC-X
work properly.
Further information www.zennio.com

WIRING AND ASSEMBLY DIAGRAMS

Figure 2: (From up to down and
from left to right) Terminal block 1
wiring examples for shutter channel,
outputs with same phase or outputs
with different phases
.
Switch/Sensor/
Push button
(1)
