Crestron CNXENET+ Operations & Installation Manual page 8

CNX Enhanced Ethernet Expansion Card
4 • CNX Enhanced Ethernet Expansion Card: CNXENET+
CNMSX Installation (1 of 3)
1
2
2. Remove six screws
3. Lift and remove control system top cover
4. As shown below, remove six screws
board to the control system.
CNMSX Installation (2 of 3)
6
REAR PANEL
(REFERENCE ONLY)
5
4
5. Slide the I/O printed circuit board
control system so that the rear connectors are clear of the rear panel
slots and reposition the I/O printed circuit board
LAN/DPA cover plate
6. Using a #1 Phillips tip screwdriver, remove two screws
lock washers
system rear panel.
7. From inside the control system, remove the LAN/DPA cover plate
8. For older model control systems, carefully push the computer interface
ribbon cable aside to make room for the CNXENET+. For newer
systems, make sure that cable does not interfere with CNXENET+
placement.
Crestron CNXENET+
REAR PANEL
(REFERENCE ONLY)
from each side of the control system.
that secure I/O printed circuit
7
toward the front panel of the
.
that secure the LAN/DPA cover plate
Operations & Installation Guide – DOC. 8153A
3
.
8
to gain access to the
and two
to the control
.
