Communicating With the Control System via
Ethernet
The Crestron Viewport may be used to communicate with the control system via
Ethernet. To connect the Viewport to the control system, perform the procedure
below.
1. In the Viewport, select Remote | TCP/IP | Connect as shown below.
Viewport Connect TCP/IP
2. As shown below, enter the IP address of the configured control system
and select the Connect button. (Within the address, X and Y may range
from 0 to 255. In the example shown below, X is 135 and Y is 246.)
Connect TCP/IP Address Dialog Box
3. If a password has been set for the control system, an access password is
required to connect. As shown on the next page, enter the required
password. (The correct password must be entered within three attempts
or the password dialog box displays a password invalid message.)
