Crestron C2N-IIF-SPMK
The C2N-IIF-SPMK includes all of the parts required for mounting a
C2N-IIF to a Holovision door station plate. The following table lists all
of the parts included with the C2N-IIF-SPMK.
Supplied Components
Screw, 08-32, 1/4" L, pan phillips
Screw, 06-32, 1 3/4" L, flat phillips
Spacer, 06, 1 7/16" L, round, 1/4" OD
Screw, 04-40, 3/4" L, pan phillips
Spacer, 04, 3/8" L, round, 1/4" OD
The C2N-IIF-SPMK is compatible with the following Holovision door
station models:
NOTE: When ordering a Holovision plate, specify that the plate is to be
used with a Crestron C2N-IIF. Older Holovision plates may not have the
appropriate mounting provisions for the C2N-IIF-SPMK.
NOTE: If the C2N-IIF-SPMK is being used with a camera-capable door
station plate, the camera is not included with the C2N-II-SPMK.
NOTE: The C2N-IIF-SPMK cannot be used with Holovision plates that
use a camera hidden behind the speaker grate.
Installation Guide - DOC. 6265
DESCRIPTION
Mounting Plate
Speaker Assembly
Microphone Assembly
Washer, flat
• Basic Model 100
• Camera Models 200 and 201
• Keyless Model 101
• Gate Entry Models: 300, 301, 302, and 303
Intercom Interface Mounting Kit
PART
NUMBER
2010173
2007264
2010428
2010427
4005371
4005461
2007184
2007088
2007658
Intercom Interface Mounting Kit: C2N-IIF-SPMK • 3
QUANTITY
1
2
4
4
1
1
2
2
2
