5799339COM
5 Drawer Dresser
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Secure Your Furniture
Keep your home and family safe
with the wall anchor kit that is
included with the product.
Serious or fatal crushing injuries can
occur from tipping furniture.
WARNING: Manufacturer assumes no liability
for improper installation or excessive loads
placed on screws or bracket. This wall anchor
is not a substitute for proper adult supervision.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
B345799339COM0
Tough
You
Tube

Advertisement

loading
Need help?

Need help?

Do you have a question about the 5799339COM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ameriwood HOME 5799339COM

Summary of Contents for Ameriwood HOME 5799339COM

  • Page 1 Easy Tough Assembly Difficulty Meter Serious or fatal crushing injuries can occur from tipping furniture. Follow Ameriwood Home WARNING: Manufacturer assumes no liability for improper installation or excessive loads placed on screws or bracket. This wall anchor Tube is not a substitute for proper adult supervision.

  • Page 2: Helpful Hints

    Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Tube Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 2 ESTIMATED ASSEMBLY TIME: 2 HOURS...

  • Page 3: Before You Start

    Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.
  • Page 4 ameriwoodhome.com Tube...

  • Page 5: Board Identification

    Board Identification Not actual size Support 35799339030 35799000050 Bottom Left Panel Right Panel Drawer Front (x4) 357993390040 35799339010 35799339020 35799339060 SIDE BACK Upper Drawer Front Drawer Side (x8) Drawer Back (x4) Drawer Bottom (x5) 35799339070 39991167346200C 39991167060190B 39991341061210D SIDE BACK Upper Drawer Side (x2) Upper Drawer Back 39991120346200C...
  • Page 6 Board Identification Not actual size This piece is paperboard construction. It is not made from wood, but is required for the assembly of your unit. SIDE SIDE BACK BACK SIDE SIDE ameriwoodhome.com...

  • Page 7: Part List

    Part List Actual Size (x6) (x6) (x6) (x4) (x62) #A22620 #A22610 #A21670 #A23030 #A12120 cam lock cam bolt wood dowel confirmat #8 x 7/16" pan head (x10) (x20) (x50) (x28) #A17400 #A21970 #A11080 #A21110 8-32 x 7/8" truss drive fastener #6 x 7/16"...
  • Page 8 Part List Not Actual Size Left Cabinet Member Right Cabinet Member Left Drawer Member (x5) #A51715 Right Drawer Member handle (x5) #A56770 drawer slide pkg. (x5) #A54900 drawer brace (x1) #A95660 metal base kit ameriwoodhome.com...
  • Page 9 STEP 1 Left Cabinet Member (x5) #A56770 (x2) (x1) (x15) (x2) #A22620 #A22610 #A11080 #A21670 finished edge Quick Assembly Proper orientation of CAM LOCK ameriwoodhome.com...
  • Page 10 STEP 2 Right Cabinet Member (x5) #A56770 (x2) (x1) (x2) (x15) #A22620 #A22610 #A21670 #A11080 finished edge Quick Assembly Proper orientation of CAM LOCK ameriwoodhome.com...
  • Page 11 STEP 3 Do not fully (x4) #A84050 tighten screw. #A22610 ameriwoodhome.com...
  • Page 12 STEP 4 Quick Assembly (x2) (x2) #A22620 #A21670 Proper orientation of CAM LOCK ameriwoodhome.com...
  • Page 13 STEP 5 finished edges will face up ameriwoodhome.com...
  • Page 14 STEP 6 finished edges will face up ameriwoodhome.com...
  • Page 15 STEP 7 (x4) #A23030 finished edges will face up unfinished surface ameriwoodhome.com...
  • Page 16 STEP 8 (x28) #A21110 IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT AND MUST BE INSTALLED PROPERLY. With the help of another person, turn the unit over on its front side. Position back panel as shown. Align squarely with outer edges. Flush bottom edge of back panel with bottom edge of the bottom and nail straight into back edges of left panel (A), right panel (B), top (C) and bottom (D).
  • Page 17 STEP 9 (x1) #A95660 ameriwoodhome.com...
  • Page 18 STEP 10 With the help of another (x12) person, carefully position #A12120 the unit as shown. ameriwoodhome.com...
  • Page 19 STEP 11 (x20) #A12120 (x8) (x2) #A54520 #A54510 For this step, you will apply eight large drawer brackets (12) to eight large drawer sides and apply two small drawer brackets (11) to two small upper drawer sides. SIDE SIDE ameriwoodhome.com...
  • Page 20 STEP 12 (x20) Note, the large drawer sides go on the large #A12120 drawer front (F) and the small drawer sides to the upper drawer front (G). Be sure the grooves in the drawer sides are centered with the groove in the drawer fronts. SIDE SIDE ameriwoodhome.com...
  • Page 21 STEP 13 SIDE finished surface SIDE ameriwoodhome.com...
  • Page 22 STEP 14 Tap the drive fasteners (7) lightly with a hammer to securely fasten. Note that the small drawer back will (x20) go with the small drawer sides and #A21970 the large drawer back will go with the large drawer sides. BACK SIDE SIDE...
  • Page 23 STEP 15 Left Drawer Member Right Drawer Member (x5) (x10) (x20) #A56770 #A17400 #A11080 Attach the slides first and then the handle. (x5) #A51715 BACK SIDE SIDE ameriwoodhome.com...
  • Page 24 STEP 16 (x10) (x5) #A12120 #A54900 BACK ameriwoodhome.com...
  • Page 25 STEP 17 For Masonry, Concrete, or other wall materials: Consult your local hardware store for appropriate anchors to securely attach the safety bracket. #A84050 IMPORTANT: THIS UNIT MUST BE SECURE TO THE WALL TO HELP PREVENT TIPOVER. FOLLOW THESE INSTRUCTIONS TO INSTALL THE ANTI-TIPPING SAFETY BRACKET PROVIDED WITH THIS PRODUCT.
  • Page 26 STEP 18 Note: The drawer bracket holes are slotted. Drawer fronts can be adjusted by loosening screws, making needed adjustments and retightening screws. roller cabinet member drawer runner roller ameriwoodhome.com...
  • Page 27 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 35 lbs 50 lbs 15.8 kg 22.6 kg (each drawer) Warning: Risk of injury to persons - do not place a television on this furniture. This furniture is not approved for use with a television.
