BBBBBBBBBB
RRRRRRRRR RRRRRRR BRRRRRR
Date of Purchase: ____/____/_____
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
WARNING
–Unit can tip over causing severe injury or death.
–Anchor unit to stud in wall (if instructed to)
–Do not allow children climb on unit
–Put heavy items on lower shelves or drawers
BBBBBBBBBBBBBBB
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
042019PK
Tough
Advertisement
Related Manuals for Ameriwood HOME 5728872COM
Summary of Contents for Ameriwood HOME 5728872COM
- Page 1 Easy Tough Assembly Difficulty Meter WARNING Follow Ameriwood Home –Unit can tip over causing severe injury or death. –Anchor unit to stud in wall (if instructed to) –Do not allow children climb on unit –Put heavy items on lower shelves or drawers...
- Page 2 BRRRRcR Us! Do NOT return this product! Contact our friendly customer service team first for help Call us! Assembly Tips 1-800-489-3351 Monday-Friday 9am - 5pm CST Visit ameriwoodhome.com HRlpful HRRRs PEOPLE NEEDED FOR ASSEMBLY: 1-2 ESTIMATED ASSEMBLY TIME: 30 MINUTES - Open your item in the area you plan to keep it for less heavy lifting - Identify, sort and count the parts before attempting assembly - Compression dowels are tapped in with a hammer...
- Page 3 BRfRRR YRu RRRRR Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.
- Page 4 BRRRd IdRRt f cRt RR Not actual size T5728872010PK T5728872020PK T5728872030PK TOP PANEL BOTTOM PANEL LEFT SIDE PANEL T5728872040PK T5728872050PK T5728872060PK RIGHT SIDE PANEL DOOR SHELF T5728872070PK T5728872080PK T5728872090PK BRACE FRONT DRAWER LEFT SIDE DRAWER ameriwoodhome.com...
- Page 5 BRRRd IdRRt f cRt RR Not actual size T5728872100PK T5728872110PK T5728872120PK RIGHT SIDE DRAWER BACK DRAWER BOTTOM DRAWER T5728872130PK T5728872140PK DRAWER SUPPORT BACK PANEL ameriwoodhome.com...
-
Page 6: Actual Size
PRRR LRsR Actual Size TPK0001 TPK0003 TPK0004 TPK0006 SHELF HOLDER Cam Bolt Cam Lock 15-9 DOWEL 8 X 30 TPK0010 TPK0007 TPK0008 TPK0009 SCREW PH 4 X 30 CBS 3.5 x 16 CBS 4 x 38 CBS 4 x 50 TPK0015 TPK3005 NAIL... - Page 7 PRRR LRsR Not Actual Size TPK2002 TPK2004 TPK2001 TPK3004 LEG BRACKET ANTI TIPPING KIT WOODEN LEG ACRYLIC HANDLE TPK4001 TPK1001 DOOR HINGES DRAWER SLIDE 300MM ameriwoodhome.com...
- Page 8 Step 1 TPK0001 TPK0003 TPK0004 Quick Assembly Properly insert Cam Lock and dowel. Proper orientation of CAM LOCK ameriwoodhome.com...
- Page 9 Step 2 TPK1001 TPK0007 Slide (CL), screw position on panel number 3. Slide (CR), screw position on panel number 4. ameriwoodhome.com...
- Page 10 Step 3 TPK0001 TPK0003 TPK2004 TPK0004 Quick Assembly Properly insert Cam Lock and dowel. Proper orientation of CAM LOCK Attach Anti-Tipping kit as shown. Do not fully tighten yet in this step. ameriwoodhome.com...
- Page 11 Step 4 Attach panel 7 to panel 3 &4. Then fully tighten the cam lock. ameriwoodhome.com...
- Page 12 Step 5 Next, attach panel 1 as shown. Make sure edge with profile facing upwards. Then fully tighten the cam lock. ameriwoodhome.com...
- Page 13 Step 6 TPK0009 Next, attach panel 2 as shown. Make sure edge with profile facing upwards. Fix using screw as shown. ameriwoodhome.com...
- Page 14 Step 7 TPK0015 Before attach panel 14, make sure to turn the carcass upside down. Be careful, the floor must clean and spread with soft cloth. Attach panel 14, this panel is part of construction stability. Please ensure corner to corner in same dimension.
- Page 15 Step 8 TPK0010 TPK2002 First, turn up the unit, with panel number 1 on the floor. To attach these plastic brackets, please be alert, this bracket designed with slanting face. Please carefully align the shorter edge to outside corner. higher edge Shorter edge IBPBRTANT! Shorter edge...
- Page 16 Step 9 TPK2001 Please remove plastic cap on the leg first. Carefully align bolt to the bracket, turning the leg clockwise to tighten the leg. ameriwoodhome.com...
- Page 17 Step 10 TPK0007 TPK4001 Attach door hinges to the door panel. Align carefully the hinges and make sure side faces parallel with door edge. Fully tighten the screws. ameriwoodhome.com...
- Page 18 Step 11 TPK0007 Insert door to the side panel as shown below. First, insert screw to the side panel. To adjust outside level, turn this screw, clockwise to move in, counter clockwise to move out. Loosen this screw to move door front or back, fully tighten this screw after finish make adjustment.
- Page 19 Step 12 TPK0006 TPK3005 TPK3004 This cabinet designed with 3 levels of adjustment for shelf. Insert shelf holder in desired level of holes. Attach handles as shown in illustration. ameriwoodhome.com...
- Page 20 Step 13 For Masonry, Concrete, or other wall materials: Consult your local hardware store for appropriate anchors to securely attach the safety bracket. IMPORTANT: THIS UNIT MUST BE SECURE TO THE WALL TO HELP PREVENT TIPOVER. FOLLOW THESE INSTRUCTIONS TO INSTALL THE ANTI-TIPPING SAFETY BRACKET PROVIDED WITH THIS PRODUCT.
- Page 21 Step 14 TPK0001 TPK0003 Quick Assembly Properly insert Cam Lock and dowel. Proper orientation of CAM LOCK ameriwoodhome.com...
- Page 22 Step 15 Attach panel 9 & 10 to the panel 8. Fully tighten the cam lock. ameriwoodhome.com...
- Page 23 Step 16 Attach panel 12 by slot into groove on panel 9 & 10. ameriwoodhome.com...
- Page 24 Step 17 Attach panel 13 to panel 8. Fully tighten the cam lock. ameriwoodhome.com...
- Page 25 Step 18 TPK0008 Attach panel 11 and fix it using screw as shown. ameriwoodhome.com...
- Page 26 Step 19 TPK3005 TPK3004 Fix the handle using provided screw. ameriwoodhome.com...
- Page 27 Step 20 TPK0007 TPK1001 Attach the slides (DL & DR) as shown. (DL) (DR) ameriwoodhome.com...
- Page 28 Step 21 Carefully attach the drawer to the carcass. ameriwoodhome.com...
-
Page 29: Maximum Loads
Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 25 lbs. 50 lbs. 11 kg 23 kg 40 lbs. 18 kg 50 lbs. 23 kg Warning: Risk of serious injury to person - do not place a television on this furniture. - Page 30 We would like to extend a big “Thank You” to all RR RssRRRlR RhRs RuR cusRRRRRs fRR RRkRRR RhR of our customers for taking the time to assemble RRRds pRRducR, RRd RR RRvR us yRuR vRluRRlR this Ameriwood Home product, and to give us your fRRdRRck. valuable feedback ameriwoodhome.com...
- Page 31 Español BuRRRRRR DRlRRRRRR Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Lunes - Viernes 9am - 5pm CST Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
- Page 32 Español PRRR 1B Step 5 - Next, attach panel 1 as shown. Make sure edge with profile facing upwards. Then fully tighten the cam lock. PRRR 1B Step 6 - Next, attach panel 2 as shown. Make sure edge with profile facing upwards. Fix using screw as shown. PRRR 1B Step 7 - Before attach panel 14, make sure to turn the carcass upside down.
- Page 33 Visite el sitio web de su distribuidor local, califique su producto comprado y déjenos algunos comentarios! Nos gustaría extender un gran “Gracias” a todos nuestros clientes por tomarse el tiempo para montar este producto Ameriwood Home, y para darnos sus valiosos comentarios Gracias! ameriwoodhome.com...
- Page 34 Français cRpRR RvRRR Ce livret d’instructions contient d’importantes informations de sécurité. S’il vous plaît lire et conserver pour référence ultérieure. Ne pas retourner ce produit! Contactez notre équipe de service à la clientèle amical pour aider. Appel: 1-800-489-3351 (gratuit) Lundi - Vendredi 9am - 5pm CST Visite: www.ameriwoodhome.com BIRE EN GARDE Ce mobilier peut basculer et causer des blessures graves et / ou la mort.
- Page 35 Français PRRR 11 Étape 4 - Fixez le panneau 7 aux panneaux 3 et 4. Serrez ensuite complètement le verrou de came. PRRR 1B Étape 5 - Ensuite, attachez le panneau 1 comme indiqué. Assurez-vous que le bord avec le profil est orienté vers le haut. Serrez ensuite complètement le verrou de came.
- Page 36 Visitez le site Web de votre distributeur local, classez votre produit acheté et laisser des commentaires! Nous aimerions étendre un grand “Merci” à tous nos clients pour prendre le temps de rassembler ce produit Ameriwood Home et de nous faire part de vos précieux commentaires Merci! ameriwoodhome.com...
