5756337COM
QUEEN/FULL HEADBOARD
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
You
Tube
B345756337COM1
Tough
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ameriwood HOME QUEEN
Summary of Contents for Ameriwood HOME QUEEN
- Page 1 5756337COM QUEEN/FULL HEADBOARD B345756337COM1 Date of Purchase ___ / ___ / ___ Lot Number: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Do Not Return This Product! Contact our customer service team for help first.
-
Page 2: Helpful Hints
Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Tube Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 ESTIMATED ASSEMBLY TIME: 1 HOUR... -
Page 3: Before You Start
Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight. -
Page 4: Board Identification
Board Identification Not actual size Upper Rail Left Vertical Molding Right Vertical Molding 35756337040 35756337010 35756337020 35756337030 Frame Assembly x2 Stringer Leg x2 35756337090 35756337070 35756337081 ameriwoodhome.com Tube... - Page 5 Board Identification ameriwoodhome.com...
-
Page 6: Part List
Part List Actual Size (x27) (x5) #A12930 #A22980 #8 x 1-1/8" screw quick connect Hardware for attaching to a bed frame Not actual size (x8) (x4) (x4) #A25400 #A20480 #A19875 1/4" washer 1/4-20 nut 1/4-20 x 1-3/4" bolt (x2) #A54285 connecting plate ameriwoodhome.com Tube... - Page 7 STEP 1 (x3) #A12930 Fasten one of the Frame Assemblies (I) to the Upper Rail (D) using three screws. * raw edges are shaded ameriwoodhome.com Tube...
- Page 8 STEP 2 (x6) #A12930 Fasten the Stringer (G) to both Frame Assemblies (I). * raw surfaces are shaded ameriwoodhome.com Tube...
- Page 9 STEP 3 (x8) #A12930 Note the orientation of the Legs (H). They must be attached as shown in order to fit the bed frame. finished edge ameriwoodhome.com Tube...
- Page 10 STEP 4 (x10) #A12930 Note: You may need to loosen the screws in the previous steps if adjusting the parts is needed. Align the parts and then tighten all the screws. ameriwoodhome.com Tube...
- Page 11 STEP 5 (x5) #A22980 Press the quick connects into the holes in the Upper Rail (D) and Top (A). Turn the screw in the quick connect to tighten the parts together. ameriwoodhome.com Tube...
- Page 12 STEP 6 There are two connecting plates (supplied) used for reinforcement. These plates are to go between the bed frame and the Legs (H) shown below. 0 lbs 0 kg front surface (x2) #A54285 Certificate of Conformity 1. This certificate applies to the Dorel Home Furnishings, Inc. product identified by this instruction manual. 2.
- Page 13 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com Tube...
- Page 14 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Lunes - Viernes 9am - 5pm CST Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
- Page 15 Visite el sitio web de su tienda local, califique su comprado y denos sus comentarios! Nos gustaría enviar un gran "Agradecimiento" a todos nuestros clientes por tomarse el tiempo de ensamblar este producto de Ameriwood Home, y por darnos sus valiosos comentarios. Gracias ameriwoodhome.com...
- Page 16 Français Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. VEUILLEZ LIRE ET GARDER POUR UNE RÉFÉRENCE FUTURE Ne retournez pas ce produit! Contactez notre équipe de service à la clientèle amicale d'abord pour obtenir de l'aide. Appelez-nous: 1-800-489-3351 (sans frais) du Lundi au Vendredi de 9h à...
- Page 17 Visitez le site Web de votre détaillant local, évaluez votre produit acheté et laissez-nous quelques commentaires ! Nous tenons à offrir un grand "Merci" à tous nos clients pour avoir pris le temps d'assembler ce produit "Ameriwood Home", et de nous donner vos commentaires précieux. Merci ameriwoodhome.com...
