5733296COM
Nesting Tables
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Visit: www.ameriwoodhome.com
WARNING
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
B345733296COM 00NHH
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
You
Tube
Tough
Advertisement
Table of Contents
Related Manuals for Ameriwood HOME 5733296COM
Summary of Contents for Ameriwood HOME 5733296COM
- Page 1 Easy Tough Assembly Difficulty Meter WARNING WARNING Follow Ameriwood Home - Unit can tip over causing severe injury or death. Tube - Anchor unit to stud in wall (if instructed to). - Do Not allow children to climb on unit.
-
Page 2: Helpful Hints
Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Tube Visit ameriwoodhome.com Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1 ESTIMATED ASSEMBLY TIME: 1.0 HOURS - Open your item in the area you plan to keep it to avoid excessive heavy lifting. - Identify, sort and count the parts before attempting assembly. -
Page 3: Before You Start
Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight. -
Page 4: Board Identification
Board Identification Not Actual Size 5733296 5733296 5733296 010NHH 020NHH 030NHH LARGE TABLE TOP BOTTOM LONG RAIL BOTTOM SHORT RAIL 5733296 040NHH 5733296 5733296 050NHH 060NHH LONG LEG LEFT LONG LEG RIGHT LONG LEG 5733296 5733296 5733296 070NHH 080NHH 090NHH SMALL TABLE TOP SHELF SHORT LEG... - Page 5 Board Identification Not Actual Size ameriwoodhome.com Tube...
-
Page 6: Part List
Hardware Bag Reference Number: 25733296COM 0NHH Part List Not Actual Size Ø6X32 mm Ø15X10 mm Ø8X25 mm × 6 × 6 × 6 CAM BOLT CAM LOCK WOOD DOWEL TNHH0001 TNHH0002 TNHH0005 M6X1 6 X1 mm M6X13X 1 mm M6X55 mm ×... - Page 7 STEP Ø6X32 mm Ø8X25 mm × 6 × 6 1.1 Attach (1) to (D), (E), (F) as illustrated. Do NOT over tighten. 1.2 Attach (3) to (B), (C) as illustrated. ameriwoodhome.com Tube...
- Page 8 STEP Ø15X10 mm × 6 Proper orientation of CAM LOCK 2.1 Attach (C) to (D) with (2) as illustrated. 2.2 Attach (B) to (D), (E) & (F) with (2) as illustrated. ameriwoodhome.com Tube...
- Page 9 STEP M6X1 6 X1 mm M6X13X 1 mm M6X55 mm M4X60 mm × 8 × 8 × 8 × 1 3.1 Attach sample from Step 2 to (A). Make sure to apply all (4), (6), (5) into the holes properly. Then tighten by Allen key (7).
- Page 10 STEP M6X1 6 X1 mm M6X13X 1 mm M6X55 mm M4X60 mm × 12 × 12 × 12 × 1 4.1 Attach (I) to (H). Make sure to apply all (4), (6), (5) into the holes properly. To make the next assembly step successful, do NOT fully tighten the bolt at this step. 4.2 Attach (I) to (G).
- Page 11 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. SMALL TABLE 75 lbs./ 34 kg LARGE TABLE 35 lbs./ 75 lbs./ 15.9 kg 34 kg Warning: Risk of injury to persons - do not place a television on this furniture.
- Page 12 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com Tube...
