Ameriwood HOME 5770330COM Manual

Ameriwood HOME 5770330COM Manual

Adult closet system
Hide thumbs

Advertisement

Quick Links

Download this manual
5770330COM
ADULT CLOSET SYSTEM
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1‐800‐489‐3351 (toll free)
Monday‐Friday 9am ‐ 5pm CST
Visit: www.ameriwoodhome.com
WARNING
‐ Unit can tip over causing severe injury or death.
‐ Anchor unit to stud in wall (if instructed to).
‐ Do Not allow children to climb on unit.
‐ Put heavy items on lower shelves or drawers.
B345770330COM2
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
You
Tube
Tough

Advertisement

loading
Need help?

Need help?

Do you have a question about the 5770330COM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ameriwood HOME 5770330COM

Summary of Contents for Ameriwood HOME 5770330COM

  • Page 1 Tough Visit: www.ameriwoodhome.com Assembly Difficulty Meter WARNING Follow Ameriwood Home ‐ Unit can tip over causing severe injury or death. ‐ Anchor unit to stud in wall (if instructed to). ‐ Do Not allow children to climb on unit. ‐ Put heavy items on lower shelves or drawers.

  • Page 2: Helpful Hints

    Warning Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1‐800‐489‐3351 Monday‐Friday 9am ‐ 5pm CST Tube Visit ameriwoodhome.com Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1‐2 ESTIMATED ASSEMBLY TIME: 2 HOURS ‐...

  • Page 3: Before You Start

    Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.

  • Page 4: Board Identification

    Board Identification Not actual size Upper Left End Panel Upper Right End Panel Lower Right End Panel Lower Left End Panel 35770330010 35770330020 35770330040 35770330030 Divider Support Rail 35770330050 35770330060 35770330080 35770330070 Upper Fixed Shelf Drawer Front Upper Adjustable Shelf Center Shelf 35770330100 35770330120...
  • Page 5 Board Identification Not actual size BACK SIDE SIDE Drawer Back Drawer Side Drawer Bottom 39991140044740B 39991140346200C 35770331160 Bottom Shelf Lower Fixed Shelf Cubby Adjustable Shelf 35770330170 35770330180 35770330190 The back panel's are paper board construction. they're not made from wood but are required for the assembly of your unit.
  • Page 6 Board Identification This piece is paper board construction. It is not made from wood but is required for the assembly of your unit. SIDE BACK SIDE ameriwoodhome.com Tube...

  • Page 7: Part List

    Part List Actual Size #A22570 #A22510 #A21660 #A80250 #A53600 Angle Bracket Cam Lock Cam Bolt Wood Dowel Shelf Spoon #A23030 #A21970 #A11080 #A12120 #A12700 2" Flat Head drive fastener 7/16" Flat Head 7/16" Pan Head 7/8" Pan Head #A13020 #A21110 #A20940 Nail 1-1/4"...
  • Page 8 Part List Not Actual Size Left Right Left Right Cabinet Drawer #A54510 Cabinet Drawer Drawer Bracket Member Member Runner Runner #A56770 Drawer Slide Package #I20630 #A84050 Telescoping Tube Wall Anchor Kit ameriwoodhome.com Tube...
  • Page 9 Step 1 (x6) (x1) (x3) #A12120 #A84050 #A53600 Assemble the rail (G) and the top (H) using the angle brackets and screws. Attach the wall anchor bracket as shown. (x3) *Raw edges are shaded ameriwoodhome.com Tube...
  • Page 10 Step 2 (x4) (x4) #A21660 #A22510 Insert two wood dowels and two cam bolts into upper left end panel (A) & upper right end panel (B). & ameriwoodhome.com Tube...
  • Page 11 Step 3 Quick Assembly (x4) (x4) #A21660 #A22570 Proper orientation of CAM LOCK Insert four wood dowels and four cam locks into upper fixed shelf (J). ameriwoodhome.com Tube...
  • Page 12 Step 4 (x3) (x6) (x4) #A53600 #A12120 #A22510 Assemble the rail (G) and the center shelf (k) using angle brackets and screws. Insert four cam bolts as shown below. (x3) *Raw edges are shaded ameriwoodhome.com Tube...
  • Page 13 Step 5 Attach the upper left end panel (A) & upper right end panel (B) to the upper fixed shelf (J) using the cam system. *Raw edges are shaded ameriwoodhome.com Tube...
  • Page 14 Step 6 (x8) #A23030 Attach the top (H) and the center shelf (J) to the upper left end panel (A) & upper right end panel (B) using eight screws. ameriwoodhome.com Tube...
  • Page 15 Step 7 (x3) (x1) #A11080 #A56770 Attach the left drawer slide to the lower left end panel (C) as shown below. Drawer slide is marked with an "L" *Raw edges are shaded ameriwoodhome.com Tube...
  • Page 16 Step 8 (x2) (x4) (x2) #A21660 #A22510 #A22570 Insert four cam bolts, two cam locks, and two wood dowels into the lower left end panel (C). Quick Assembly Proper orientation of CAM LOCK *Raw edges are shaded ameriwoodhome.com Tube...
  • Page 17 Step 9 (x3) (x1) #A11080 #A56770 Attach the right drawer slide to the lower right end panel (D) as shown below. Drawer slide is marked with an "R" *Raw edges are shaded ameriwoodhome.com Tube...
  • Page 18 Step 10 (x2) (x4) (x2) #A21660 #A22510 #A22570 Insert four cam bolts, two cam locks, and two wood dowels into the lower right end panel (D). Quick Assembly Proper orientation of CAM LOCK *Raw edges are shaded ameriwoodhome.com Tube...
  • Page 19 Step 11 Quick Assembly (x4) (x4) #A21660 #A22570 Proper orientation of CAM LOCK Insert four wood dowels and four cam locks into lower fixed shelf (R). ameriwoodhome.com Tube...
  • Page 20 Step 12 (x2) #A21660 Insert two wood dowels into large holes in divider part (E). *Raw edges are shaded ameriwoodhome.com Tube...
  • Page 21 Step 13 (x4) (x4) (x3) (x6) #A21660 #A22570 #A53600 #12120 Assemble the support (F) to the bottom shelf (Q) using angle brackets and screws. Insert cam locks and wood dowels as shown below. (x3) *Raw edges are shaded ameriwoodhome.com Tube...
  • Page 22 Step 14 (x2) #A23030 Attach the bottom (Q) to the divider (E) using two screws. *Raw edges are shaded ameriwoodhome.com Tube...
  • Page 23 Step 15 (x2) #A23030 Attach the lower fixed shelf (R) to the divider (E) using two screws. ameriwoodhome.com Tube...
  • Page 24 Step 16 LOCK UNLOCK Attach the lower left end panel (C) and the lower right end panel (D) to the assembly from the previous step using the cam lock system as shown. ameriwoodhome.com Tube...
  • Page 25 Step 17 (x2) (x4) #A53600 #A12120 For this step you’ll need to carefully place the unit on its front face as shown. Attach the support (F) to the lower left end panel (C) and lower right end panel (D) using angle brackets and screws. ameriwoodhome.com Tube...
  • Page 26 Step 18 LOCK UNLOCK Place the unit back onto its back side and assemble the upper and lower portion of the unit using the cam lock system as shown. ameriwoodhome.com Tube...
  • Page 27 Step 19 (x30) #A21110 2 people are required for this step. Carefully turn the unit over onto its front side as shown. Assure that the unit is square. Distance from corner to corner must be equal as shown. Align the upper back panel with the top of the unit.
  • Page 28 Step 20 (x2) #A54510 #A12120 Using screws, attach a drawer bracket to the drawer sides as shown. SIDE SIDE bracket orientation bracket orientation ameriwoodhome.com Tube...
  • Page 29 Step 21 (x4) #A12120 Attach the drawer front using four screws as shown below. Be sure the groove in the drawer sides are centered with the groove in the drawer front. If not, loosen the screws in drawer front, adjust and retighten. SIDE SIDE ameriwoodhome.com...
  • Page 30 Step 22 (x4) #A11600 Slide the drawer bottom into the grooves. You will need to tap the drive fasteners with a hammer to securely fasten. BACK SIDE finished surface SIDE ameriwoodhome.com Tube...
  • Page 31 Step 23 (x1 each) (x4) #A56770 #A11080 Attach the drawer slides to the bottom of the drawer sides. SIDE BACK SIDE ameriwoodhome.com Tube...
  • Page 32 Step 24 (x3) (x6) (x6) (x6) #I20630 #A12700 #A20940 #A13020 First, locate your closet rods where you would like to position them in‐line with the holes in the unit and mark hole locations on the wall. Next, if you are using the anchors to fasten the closet rods, insert them into the wall securely by screwing them into the wall using a screwdriver.
  • Page 33 Step 25 Notice, the drawer bracket holes are slotted. Drawer fronts can be adjusted by loosening screws, making needed adjustments and retightening screws. cabinet member roller drawer runner roller ameriwoodhome.com Tube...
  • Page 34 Step 26 (x4) #A80250 Place the shelf spoons into the holes in their desired position and place upper adjustable shelf (I) and cubby adjustable shelves (S) in place as shown. ameriwoodhome.com Tube...
  • Page 35 Step 27 For Masonry, Concrete, or other wall materials: Consult your local hardware store #A84050 for appropriate anchors to securely attach the safety bracket. THIS UNIT MUST BE SECURE TO THE WALL TO HELP PREVENT TIPOVER. FOLLOW IMPORTANT: THESE INSTRUCTIONS TO INSTALL THE ANTI‐TIPPING SAFETY BRACKET PROVIDED WITH THIS PRODUCT.

  • Page 36: Maximum Loads

    MAXIMUM LOADS This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 50 Lbs. each 50 Lbs. 22.7 Kg. each 22.7 Kg. 40 Lbs. 18.2 Kg. 20 Lbs.
  • Page 37 CARGA MAXIMA Esta unidad ha sido diseñada para soportar la carga máxima anotada. El exceder estos límites puede causar inestabilidad, colapsarse y/o causar serias lesiones. 50 Lbs. each 50 Lbs. 22.7 Kg. each 22.7 Kg. 40 Lbs. 18.2 Kg. 20 Lbs. 9.1 Kg.
  • Page 38 CHARGES MAXIMALES Ce meuble a été conçu pour supporter les charges maximales indiquées. En excédant ces limites de charge, le meuble pourrait devenir instable, s’effondrer, et/ou causer des blessures graves. 50 Lbs. each 50 Lbs. 22.7 Kg. each 22.7 Kg. 40 Lbs.
  • Page 39 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com Tube...
  • Page 40 Español Consejos Útiles (página 2) ‐ Abra su artículo en el área donde usted planea utilizarlo para evitar levantar y moverlo menos ‐ Identificar, ordenar y contar las piezas antes de intentar ensamblar ‐ Las clavijas de compresión se golpean con un martillo ‐...
  • Page 41 Español Paso 4 Montar el riel (G) y la plataforma del centro (k) con escuadras y tornillos e inserte cuatro pernos de leva como se muestra a continuación. Paso 5 Fijar el panel del extremo superior izquierdo (A) y el panel del extremo superior derecho (B) al estante fijo superior (J) usando el sistema de leva.
  • Page 42 Español Paso 14 Fijar la parte inferior (Q) en el divisor (E) utilizando dos tornillos. Paso 15 Fijar el estante fijo inferior (R) al divisor (E) utilizando dos tornillos. Paso 16 Fijar el panel del extremo inferior izquierdo (C) y el panel del extremo inferior derecho (D) a la unidad desde el paso anterior utilizando el sistema de bloqueo de leva, como se muestra en la figura.
  • Page 43 Español Paso 20 Usando los tornillos, fije un soporte del cajón a los lados del cajón como se muestra. Paso 21 Fije los lados del cajón al frente del cajón (I) con los tornillos. Nota: Asegúrese de que la ranura de los lados del cajón esté centrada con la ranura en el frente del cajón.
  • Page 44 Español Paso 27 Para mampostería, hormigón u otros materiales de la pared: Consulte a su ferretería local para los #A84050 anclajes apropiados para fijar firmemente el soporte de seguridad. IMPORTANTE: ESTA UNIDAD DEBE SER ASEGURADA CON LA PARED PARA PREVENIR VOLQUEO. SIGA ESTAS INSTRUCCIONES PARA INSTALAR EL SOPORTE DE SEGURIDAD ANTIVOLQUEO SUMINISTRADO CON ESTE PRODUCTO.
  • Page 45 Visite el sitio web de su tienda local, califique su comprado y denos sus comentarios! Gracias Nos gustaría enviar un gran "Agradecimiento" a todos nuestros clientes por tomarse el tiempo de ensamblar este producto de Ameriwood Home, y por darnos sus valiosos comentarios. ameriwoodhome.com Tube...
  • Page 46 Français Astuces Utiles (page 2) ‐Ouvrez votre article dans la zone que vous prévoyez de le garder pour moins de levage lourd ‐Identifier, trier et compter les pièces avant d'essayer d'assembler ‐Les goujons de compression sont taraudés avec un Marteau ‐Les glissières sont marquées d'un R (droit) et d'un L (gauche) pour un bon placement ‐Assurez‐vous toujours de faire face la pointe situé...
  • Page 47 Français Étape 5 Fixez le panneau de fermeture supérieur gauche (A) et le panneau de fermeture supérieur droit (B) à l'étagère fixe supérieure (J) en utilisant le système de boulons et de serrures batteuses. Étape 6 Fixez l'étagère du haut (H) et l'étagère médiane (J) au panneau de fermeture supérieur gauche (A) et au panneau de fermeture supérieur droit (B) en utilisant huit vis.
  • Page 48 Français Étape 16 Fixez le panneau de fermeture inférieur gauche (C) et le panneau de fermeture inférieur droit (D) à l'assemblage de l'étape précédente en utilisant le système de boulons et de serrures batteuses comme montré. Étape 17 Pour cette étape, vous aurez besoin de placez l'unité délicatement sur sa face avant comme montré.
  • Page 49 Français Étape 20 À l'aide des vis, fixez un support de tiroir sur les côtés du tiroir, tel qu'illustré. Étape 21 Fixez les côtés du tiroir à l'avant du tiroir (I) avec des vis. Remarque : Veillez à ce que la rainure dans les côtés du tiroir sont centrées sur la rainure de la façade du tiroir.
  • Page 50 Français Étape 27 Pour la maçonnerie, béton ou d'autres matériaux de mur: Consultez votre magasin local de matériel pour les ancrages #A84050 appropriés pour fixer le support de sécurité. IMPORTANT: CET APPAREIL DOIT ÊTRE FIXÉ AU MUR POUR AIDER À PRÉVENIR LE BASCULEMENT. SUIVRE CES INSTRUCTIONS POUR INSTALLER LE SUPPORT DE SÉCURITÉ...
  • Page 51 Visitez le site Web de votre détaillant local, évaluez votre produit acheté et laissez-nous quelques commentaires ! Nous tenons à offrir un grand "Merci" à tous nos Merci! clients pour avoir pris le temps d'assembler ce produit "Ameriwood Home", et de nous donner vos commentaires précieux. ameriwoodhome.com Tube...
  • Page 52 Certificate of Conformity 1. This certificate applies to the Dorel Home Furnishings, Inc. product identified by this instruction manual. 2. This certificate applies to compliance of this product with the CPSC Ban on Lead‐Containing Paint (16 CFR 1303). 3. This product is distributed by: Dorel Home Furnishings, Inc. 410 East First Street South Wright City, MO 63390 636‐745‐3351...
