N.3 Performance Specification
The following pages contain audio performance specification figures for the X-Rack Stereo Dynamics
Module. No other Solid State Logic products are covered by this document and the performance of other
Solid State Logic products can not be inferred from the data contained herein.
N.3.1 Measurement Conditions
For each set of figures on the following pages, the specific unit and test setup will be stated at the
beginning of that section. Any changes to the specified setup for any particular figure(s) will be detailed
beside the figures to which that difference applies.
N.3.2 Measurement References
Unless otherwise specified the references used in this specification are as follows:
• Reference frequency:
• Reference level:
• Source impedance of Test Set:
• Input impedance of Test Set:
• All unweighted measurements are specified as 22Hz to 22kHz band limited RMS and are expressed in
units of dBu
• All distortion measurements are specified with a 36dB/Octave low pass filter at 80kHz and are
expressed as a percentage
• The onset of clipping (for headroom measurements) should be taken as 1% THD
• Unless otherwise quoted all figures have a tolerance of ±0.5dB or 5%
• All measurements are made with the operating level switch set for +4dBu
N.3.3 Compressor/Limiter
Controls:
Ratio (slope)
Threshold
Attack Time
Release
The Compressor/Limiter has two modes of signal detection, Peak and RMS. As their names suggest these
modes of detection either act on peaks of the incoming signals or on their RMS levels. This gives two very
different modes of compression and limiting with Peak Mode giving far more dramatic compression
characteristics.
N.3.4 Expander/Gate
Controls:
Range
Threshold
Attack Time
Hold Time
Release Time
The side chain signal can be sourced either from the signal feeding the dynamic or the external Key input.
LED meters independently indicate amount of compression and expansion.
1kHz
0dBu, where 0dBu ≈ 0.775V into any load
50Ω
100kΩ
Variable from 1 to infinity (limit)
Variable from +10dB to –30dB
Normally auto sensing, switchable to 1mS
Variable from 0.1 to 4 seconds
Variable from 0 to 40dB
Variable from –30dB to +10dB
Normally auto-sensing, switchable to 150µs
Variable from 0 to 4 seconds
Variable from 0.1 to 4 seconds
X-Rack Stereo Dynamics Module
