4. Operation – Total Recall
4.1

Overview

The Total Recall computer stores all of the switch and rotary control
positions for each X-Rack module in one of thirty two internal stores.
These can be recalled and compared with the current settings using
front panel LEDs to show which controls do not match. If the module
layout has changed since the snapshot was taken, only the modules
that match will be recalled.
The contents of all the stores can be archived and restored as a MIDI
system exclusive data dump.
Additionally, the X-Rack can interface with the Total Recall system on
AWS 900, AWS 900+, AWS 924, AWS 948 or Matrix consoles. This
allows the settings of up to four (AWS) or six (Matrix) X-Rack units to
be stored along with the console settings.
4.2

Stand-alone Mode

4.2.1 Saving Stores to Internal Memory

A maximum of 32 stores can be saved in internal non-volatile memory, provided the stores have not been
write-protected – indicated by the 'Wr Prot' LED
First select a store by turning the D-Pot
store all of the current control positions.
If the store has already been used the SAVE LED will flash. Press the
SAVE switch a second time to overwrite the store.
5

4.2.2 Recalling and Displaying Stores

To select a store using the D-Pot
The current store is displayed on the dual 7-segment display
If the selected store is empty the 'Empty' LED
With a valid store selected, the X-Rack module SEL LEDs will light if the module type in the store (EQ,
Dynamics etc.) matches the module currently fitted in that slot. A flashing SEL LED indicates that some controls
on that module do not match the stored positions. A steady LED shows that all controls are matched. The
switch LEDs will light if the current switch position does not match the stored positions. Press or release
the switch as required to extinguish the LED.
Above each rotary control is a bi-colour LED:
The LED lights red if
the
turning anti-clockwise.
The LED extinguishes when the control matches the stored position.
If a store is already being displayed when you select a different store the display will flash and the new
store will not become active until you press the D-Pot for a second time.

4.2.3 Exiting Display Mode

Push the D-Pot
All SEL LEDs will extinguish and the channel switch LEDs will now show the position of their respective
switches.
then press the D-Pot to select that store.
4
control needs
a second time to exit display mode.
4
being illuminated.
3
, then press SAVE
4
.
lights and the unit will not switch to display mode.
2
or
TOTAL RECALL
4
Push to Select
SAVE COPY/
5
to
5
Push to Select
The LED lights green if
the control needs
turning clockwise.
2
Empty
3
Wr Prot
SETUP/
DEL MIDI
6 7
SAVE
