A.3.4 Instrument Input Performance
Un-balanced signal applied to Instrument Input and measured at Output. Pad switched out and Input
Gain control set to +12dB (minimum).
Gain
Input Impedance
Output Headroom
THD + Noise
(-18dBu applied, +28dB gain)
Frequency Response
Equivalent Input Noise
(Input terminated with 150Ω)
A.3.5 Line Input Performance
Signal applied to Line Input and measured at Output. Input Gain control set to 0dB (indent).
Gain
Input Impedance
THD + Noise
(+24dBu applied, 0dB gain)
Frequency Response
Equivalent Input Noise
(Input terminated with 150Ω)
Page A-4
Continously variable from +12dB to +75dB
Independently switchable 18dB Pad available
1MΩ
> +26dBu at onset of clipping
< 0.03% at 1kHz
< 0.05% at 10kHz
+0.05dB/-0.1dB from 20Hz to 20kHz
–3dB at 150kHz
< –82dB at +12dB (minimum) gain
< –88dB at +28dB gain (mid' position)
Continuously variable from –20dB to +20dB
> 10kΩ
< 0.005% from 20Hz to 20kHz
±0.1dB from 20Hz to 20kHz
–3dB at 150kHz
< –90dB
