Connector Details

Ins Rtn, Ext, Mon, Alt Mon
Location: Rear Panel
Conn' Type: 25-pin 'D' Type Female
Pin Description
1 Alt Monitor Out Right (+ve)
14 Alt Monitor Out Right (–ve)
2 0V
15 Alt Monitor Out Left (+ve)
3 Alt Monitor Out Left (–ve)
16 0V
4 Main Monitor Out Right (+ve)
17 Main Monitor Out Right (–ve)
5 0V
18 Main Monitor Out Left (+ve)
6 Main Monitor Out Left (–ve)
19 0V
7 External Input Right (+ve)
20 External Input Right (–ve)
8 0V
21 External Input Left (+ve)
9 External Input Left (–ve)
22 0V
10 Mix Insert Return Right (+ve)
23 Mix Insert Return Right (–ve)
11 0V
24 Mix Insert Return Left (+ve)
12 Mix Insert Return Left (–ve)
25 0V
13 n/c
Please note that the 'D' type connector binding posts fitted to the X-Rack Master Module are 4-40 UNC thread.
Headphones
Location: Front Panel
Conn' Type: Stereo 1/4" Jack Socket
Pin Description
Tip Left
Ring
Sleeve 0V
Ins Snd, Mix, Rec, Fol Mon
Location:
Conn' Type:
Cct Pin
1
8 14
2
15
7 3
16
4
6 17
5
18
5 6
19
7
4 20
8
21
3 9
22
10
2 23
11
24
1 12
25
13
PL2
Location:
Conn' Type:
Pin
n/a
X-Rack Master Module
Rear Panel
25-pin 'D' Type Female
Description
Follow Monitor Right (+ve)
Follow Monitor Right (–ve)
0V
Follow Monitor Left (+ve)
Follow Monitor Left (–ve)
0V
Record Output Right (+ve)
Record Output Right (–ve)
0V
Record Output Left (+ve)
Record Output Left (–ve)
0V
Mix Output Right (+ve)
Mix Output Right (–ve)
0V
Mix Output Left (+ve)
Mix Output Left (–ve)
0V
Mix Insert Send Right (+ve)
Mix Insert Send Right (–ve)
0V
Mix Insert Send Left (+ve)
Mix Insert Send Left (–ve)
0V
n/c
Internal
16-pin IDC Plug
Description
For Future Expansion
Cct
8
7
6
5
4
3
2
1
