CVBS to HDMI MInI ConVerter
720P/1080P: Press 720P/1080P button to choose output HDMI
signal as 720P@50/60Hz or 1080P@50/60Hz
LED: Output HDMI signal 720pwhen LED is red and 1080p when
green
troUBLe sHootinG
No image output?
A: 1) Please check and make sure all the connection is correct,
signal LED indicator lights up normally and HDTV channel is
chosen correctly.
2) Check whether the output HDMI signal is supported by the
HDTV.

teCHniCaL paraMeter

power adapter
HdMi signal
CvBs input
ddC signal
tMds signal
power Consumption
dimension (L*W*H)
Maintenance: Clean only with a dry cloth. Do not use cleaning
solvents or abrasives.
Warranty: No guarantee or liability can be accepted for any changes
and modifications of the product or damage caused due to incorrect
use of this product.
This product is marked with this symbol. It means
that used electrical and electronic products should
not be mixed with general household waste. There is
a separate collections system for these products in
compliance with EU Directive WEEE.
With the CE sign, Techly
conformed to the basic European standards and directives.
DC5V/1A
HDCP compliant
Detect PAL/NTSC automatically
1.0Vp-p Impedance: 75Ohm
5Vp-p (TTL)
0.5-1.0Vp-p (TMDS)
2.5W
105.5*64.5*23 mm
