TM
User's Manual

1. Introduction

Congratulations on purchasing the Pocket C@m. Using the latest innovations in technology the Pocket C@m offers fun,
affordable and easy to use digital imaging.
Although you probably want to get started right away, please take a few minutes to read this guide and familiarise yourself
with your new Pocket C@m. Your new Pocket C@m will take 20 Hi-Res (High Resolution) or 80 Low-Res (Low Resolution)
images, which you upload to your PC (Personal Computer) running Windows® 98SE, Me, 2000, XP or Macintosh® running
OS 8.6 - 9.2 via the USB (Universal Serial Bus) port.
You can also use your Pocket C@m to capture not only snaps of your family and friends, but also video clips of them in action
(for Windows® Users only).
Your Pocket C@m can also be used as a Web Cam. If you have an internet connection and microphone (not supplied) you
can chat face-to-face with friends and colleagues, conferencing in real time.
Please note that your images are stored on your Pocket C@m's internal memory. When you have taken your images, the
Pocket C@m will wait for 30 seconds and then automatically switch to Stand-by mode, which draws a constant trickle of
power from the battery. When the LCD display blinks, all stored images must have been uploaded and saved as otherwise
they will be lost.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CIC-175 and is the answer not in the manual?

Questions and answers

Related Manuals for Cool-Icam CIC-175

Summary of Contents for Cool-Icam CIC-175

  • Page 1: Introduction

    User’s Manual 1. Introduction Congratulations on purchasing the Pocket C@m. Using the latest innovations in technology the Pocket C@m offers fun, affordable and easy to use digital imaging. Although you probably want to get started right away, please take a few minutes to read this guide and familiarise yourself with your new Pocket C@m.

  • Page 2: Table Of Contents

    Getting Started ... 6 6.1 How to use your Pocket C@m ... 6 For Windows® Users: 6.2 How to install the Digital Camera Software ... 7 6.3 Uploading Images from Your Pocket C@m ... 7 6.4 How to install ArcSoft® Softwares... 8 6.5 How to install Microsoft®...

  • Page 3: System Requirements

    3. System Requirements For Windows® Users • Compatible with Microsoft® Windows® 98SE, Me, 2000 or XP • Pentium ® II 333Mhz or Pentium® compatible processor • 128MB RAM or higher • USB Port • 200MB free disk space • CD-ROM Drive •...

  • Page 4: Shutter Button

    5.1 Shutter Button The Shutter Button has 5 functions. Although these are covered in more detail later in this manual, please nd below a brief description. 5.1.1 Still Image To take an image, aim the Pocket C@m by looking through the viewnder and press the Shutter Button once. A beep means you have taken an image.

  • Page 5: Low Battery

    5.6 USB Cable Port The USB cable allows you to upload images from the Pocket C@m to your PC or Mac. One end of the cable connects to the USB port on the side of the Pocket C@m and the other end connects to your PC’s or Mac’s USB port. When your Pocket C@m is connected to your PC or Mac, it will draw power from the PC in order to preserve your battery life.

  • Page 6: Getting Started

    6.1 How to Use Your Pocket C@m 6.1.1 Switching the Pocket C@m On Your Pocket C@m will automatically switch on when you insert new batteries or connect your Pocket C@m to your PC or Mac via USB port. Press the Mode Button to turn on your Pocket C@m when your Pocket C@m is in Stand-by Mode. The LCD will indicate the mode for high resolution and it will also display the number of images which may be taken.

  • Page 7: For Windows® Users: Pc

    6.3 Uploading Images from Your Pocket C@m You can use the Digital Camera Manager to upload images captured by your Pocket C@m at any time whether or not the Pocket C@m is full. Connect your Pocket C@m to your PC via the USB cable. Plugging the USB connector into the Pocket C@m will cause it to reset and issue a double beep but all stored images will remain.

  • Page 8: How To Install Arcsoft® Softwares

    You are now able to enhance the resolution of your taken images by using the Digital Camera Manager. Before you start to capture all stored images, a window will pop up and ask you if you want to convert all the stored images to High Resolution (640x480) automatically.

  • Page 9: How To Install Microsoft Netmeeting

    ArcSoft VideoImpression™ 1.6 ArcSoft VideoImpression™ is an easy-to-use video and image editing software program. The program enables users to create and edit new videos using existing video and image les - making desktop video presentations for home, business, and the Web.

  • Page 10: How To Use Arcsoft Photofantasy™ 2000

    2. Click “Get Fantasy” to select the template in the existing library and then click “OK” to conrm. Important! Make sure the “Digital Camera” CD-ROM is in the CD-ROM Drive. Using the images stored in your Pocket C@m:- 3. Double click on “Get Photo 1” and click “Acquire”. Select “STV0680 Camera’ or “USB Dual Mode Camera”...

  • Page 11: How To Use Arcsoft Photoprinter®2000

    Resolution supports 20 frames of video. • When the Pocket C@m is full, attach it to your PC via USB and run the Digital Camera Manager. • You can now start to create your own movie clips by following these steps: 2.

  • Page 12: How To Use Arcsoft Videoimpression™1.6

    To adjust frame rate: You can adjust the frame rate (number of frame per second) by pressing the 1. Click the button. 2. Enter the frame rate you want for your movie clip. For example:- • 80 frames at 10 frames per second = 8 sec. movie clip •...

  • Page 13: How To Use Microsoft Netmeeting

    6.13 How to Install Digital Camera Driver Software Notes Important: Macintosh® users may only choose one type of driver at a time to install (digital camera driver without enhancement). The driver cannot run properly if both driver are installed. 6.13.1 How to Install Digital Camera Driver (without enhancement): 1.

  • Page 14: How To Install Photostudio 2000

    6.13.2 How to Uninstall Digital Camera Driver (without enhancement): To uninstall the Digital Camera Driver (without enhancement), you have to remove 3 les located in different folders and restart your Mac. The 3 les are listed below. “STV0680 Camera” in Control Panel Folder “STV0680 Downloader”...

  • Page 15: How To Install Cu-Seeme

    2. Click “Get Fantasy” to select the template in the existing library and then click “OK” to conrm. Important! Make sure the “Digital Camera” CD-ROM is in the CD-ROM Drive. 3. Go to “Get Photo 1” and click “Add”. Find the image you want which you have already saved in your hard disk and click “Open”.

  • Page 16: How To Use Arcsoft Photoprinter 2000

    6.21 How to use ArcSoft PhotoPrinter 1. Double click the “PhotoPrinter” icon from the PhotoPrinter. Important! Make sure the “Digital Camera” CD-ROM is in the CD-ROM Drive. 2. Choose the “Page Layout”. The selected page layout will on shown on the right panel.

  • Page 17: Customer Support

    SPECTRA MERCHANDISING INTERNATIONAL, INC. Chicago Industry Tech Park 4230 North Normandy Avenue Chicago, Illinois 60634, USA. Internet Address: spectra@interaccess.com For customer service, please call 1-888-235-0808 or visit our WebSite www.coolicam.com Fill in the registration card now! See your local customer support details on the registration card enclosed. 8.

  • Page 18: Troubleshooting

    Pocket C@m C@m. I cannot upload images to the PC LCD display is ashing. I cannot run the Digital Camera Manager. Please also refer to the help les & User Guides that accompany the enclosed applications. For further information and support, please visit our website: For Macintosh®...

  • Page 19: Battery Guidance

    Important Note: We strongly recommend that you do not use rechargeable batteries as this will affect the performance of your Pocket C@m. WARNINGS! • Batteries should be replaced by an adult. • Non-rechargeable batteries are not to be recharged. • Rechargeable batteries are to be removed from the camera before being charged (if •removable). •...

  • Page 20: Fcc Notice

    12. FCC Notice This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
