Alarm.com Video Doorbell (ADC-VDB770) - Installation Guide
Use this guide to assist with the installation of your ADC-VDB770 doorbell camera.
Pre-installation checklist
Media, iframe, embed and object tags are not supported inside of a PDF.
Important: A Video Analytics service package and the Doorbell Cameras add-on is required to enroll the ADC-VDB770.
For more information about which service packages have Video Analytics, see
enrolling the
ADC-VDB770?.
• ADC-VDB770 and included accessories
• Wire crimping tool
• Wi-Fi connection to broadband (Cable, DSL, or Fiber Optic) internet
https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-VDB7...
What service packages can support
Updated: Wed, 25 Oct 2023 20:50:59 GMT
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Alarm.Com ADC-VDB770-BZ
Summary of Contents for Alarm.Com ADC-VDB770-BZ
- Page 1 Alarm.com Video Doorbell (ADC-VDB770) - Installation Guide Use this guide to assist with the installation of your ADC-VDB770 doorbell camera. Pre-installation checklist Media, iframe, embed and object tags are not supported inside of a PDF. Important: A Video Analytics service package and the Doorbell Cameras add-on is required to enroll the ADC-VDB770.
-
Page 2: Installation
The new version will be marked on the packaging and by a new hardware version number HWV0310+. Digital chime installations will require a battery replacement kit (ADC-VDBA-770BAT). For more information about how to use the battery replacement kit, see the ADC-VDB770 Power Guide. Installation https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-VDB7… Updated: Wed, 25 Oct 2023 20:50:59 GMT... - Page 3 Media, iframe, embed and object tags are not supported inside of a PDF. 1. Verify that the electricity is turned off at the transformer before installing the power module. Locate your chime box and remove the cover. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-VDB7… Updated: Wed, 25 Oct 2023 20:50:59 GMT...
- Page 4 4. Using a crimp tool and the wire connectors provided, connect the wires that were set aside to the straight gray wires of the power module. 5. Affix the power module to the side of the chime using the included adhesive. Replace the chime cover. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-VDB7… Updated: Wed, 25 Oct 2023 20:50:59 GMT...
- Page 5 Note: The power module must be used in every installation regardless of the chime type. The power module is used to prevent the chime from buzzing or humming, and it helps ensure sufficient power is provided to the Alarm.com Video Doorbell.
- Page 6 1. Remove the existing doorbell from the wall and disconnect the wires. Secure the wires so that they can be connected in a later step. If possible, verify that the Alarm.com Video Doorbell will be out of direct sunlight in hotter climates.
- Page 7 2. At the installation location, an angled mounting bracket can be used to modify the field of view. Choose a mounting bracket type best suited for your installation setup. Installation scenarios corresponding to mounting bracket types A, B, and C are provided below to guide your decision. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-VDB7… Updated: Wed, 25 Oct 2023 20:50:59 GMT...
- Page 8 3. Thread the existing wires through the mounting bracket. Install the mounting bracket to the wall using the included wall screws (and anchors, if needed for the mounting surface). https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-VDB7… Updated: Wed, 25 Oct 2023 20:50:59 GMT...
- Page 9 4. Thread the wire extenders through the backplate. Remove the wire caps. 5. Crimp the two wires coming through the backplate to the existing wires threaded through the mounting bracket. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-VDB7… Updated: Wed, 25 Oct 2023 20:50:59 GMT...
- Page 10 7. Attach the doorbell to the backplate by aligning and pushing together until it clicks into place and the connection is well sealed. 8. Turn the electricity back on. Check that the doorbell camera’s light is flashing white after the boot process is complete. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-VDB7… Updated: Wed, 25 Oct 2023 20:50:59 GMT...
- Page 11 30-35s and release when the LED begins to blink blue. 2. Activate WPS Mode on the router. The router will begin to connect to the Wi-Fi network. Verify the LED turns to solid green, indicating the connection is complete. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-VDB7… Updated: Wed, 25 Oct 2023 20:50:59 GMT...
- Page 12 1. Add the device to the account by selecting the account in MobileTech, by using the customer Mobile App, or by using a web browser and entering the following web address: www.alarm.com/addcamera. 2. Select the Video Doorbell from the video device list or enter in its MAC address to begin adding the device. The device’s MAC address is located on the included reference card.
- Page 13 LED pattern Description Solid green Connected to Alarm.com Blinking green Local network connection Unable to ring indoor chime Double-blinking blue For more information about what causes this status, What does the double-blinking blue LED on the ADC-VDB770 mean?. Cool-Down mode is active...
-
Page 14: Troubleshooting
2. If issues persist, factory reset the Video Doorbell by pressing and holding the doorbell button until the LED starts blinking red and green (~45-50s). The device will reboot with factory defaults. Important: If the device was previously installed to an Alarm.com account, it will need to be deleted before it can be installed again. - Page 15 If the indoor chime does not make sound when it should, see The indoor chime does not make sound when a guest rings the ADC-VDB770. https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Alarm.com_Video_Doorbell_(ADC-VDB7… Updated: Wed, 25 Oct 2023 20:50:59 GMT...
