Maintenance

Battery Replacement

1. Twist off the battery compartment cap
2. Holding the battery housing in place with a finger, pull out the battery carrier using the two
small tabs.
3. Replace the four (4) CR2032 batteries observing polarity.
4. Replace the battery compartment cap
Safety: Please dispose of batteries responsibly; never dispose of batteries in a fire, batteries
may explode or leak. If the meter is not to be used for 60 days or more, remove the battery
and store separately

Electrode Replacement

1. To remove an electrode, unscrew and completely remove the electrode collar (turn the collar
counter-clockwise to remove).
2. Gently rock the electrode from side to side, pulling it downwards, until it disconnects from the
meter.
3. To attach an electrode, carefully plug the electrode into the meter socket (note that the
electrode connector is keyed, ensuring proper connection).
4. Tighten the electrode collar firmly enough to make a good seal (a rubber gasket seals the
electrode with the meter).
