Side
DC IN terminal
USB port
2

INSTALLING THE BATTERIES

Insert two (2) AA-size alkaline batteries (included with the camera).
1. Be sure that the camera power is off.
2. Slide the battery/memory card door in the direction of the arrow, and lift it open.
3. Insert two AA batteries with the positive (+) and negative (-) poles matching the directions indicated inside
the battery cover.
4. Close the Battery/Memory Card door.
+
Battery Status Indications
The battery power level indicator represents the level of power of the batteries. The meaning of each icon is as
follows:
High Low
Charge Level
Indicator
2
