3

INSTALLING AN SD CARD

1. Turn off the camera.
2. Slide the Battery/Memory Card door in the direction of the arrow
to open the door.
3. Insert the memory card as shown in the diagram.
4
TURNING THE POWER ON / OFF
Press and hold the POWER button for more than 1 second to turn
the camera on.
To turn off the camera
Press the power button to turn off the camera.
5

USING THE CAMERA MODE BUTTON

Use the Camera Mode button to change shooting mode.
Shooting Mode
Review Mode
Video Mode
The camera mode changes as shown in the following diagram when the Camera Mode button is pressed.
Shooting Mode
6

OPERATING THE MULTI-CONTROLLER

The multi-controller is used to set shooting mode, to move cursor when the camera Menu is shown, and to
confirm the selection.
Up Button ( )
• To set the Flash mode in Shooting Mode.
• To delete files in Review Mode.
• To move the cursor up when MENU screen is shown.
Right Button ( )
• To enter Quick View mode.
• To move the cursor to right when MENU screen is shown .
• To enter submenu.
For shooting still images
For viewing the recorded images and video clips
For shooting video clips
Play Mode
3
Movie Mode
Left button
Power button
Up button
Right button
Down button
