- Page 1 Z5383 Mounting instructions 1.3 en...
- Page 2 General information Z5383 Mounting instructions Version: 1.3 en, 10/2015, D2821.EN .01 Copyright © 2015 by d&b audiotechnik GmbH; all rights reserved. Keep these mountings instructions with the product or in a safe place so that they are available for future reference.
- Page 3 1.1. Scope of supply and weight........... 4 1.2. Safety precautions..............4 1.3. Intended use................4 1.4. Assembly.................. 5 1.5. Adjustments................5 1.6. Built-in dimensions..............6 Declarations................ 7 2.1. Manufacturer's declaration............ 7 2.2. Disposal................... 7 d&b Z5383 Mounting instructions 1.3 en...
- Page 4 Load safety information The Z5383 VP Mounting bracket is designed to support one V7P/ V10P or Vi7P/Vi10P loudspeaker. No additional loads must be added. The bracket must only be used in an upright position or suspended vertically as shown in the graphic opposite.
- Page 5 Potential risk of damage to material. The maximum vertical aiming must not exceed ±30° 1. Slightly slacken the fixing screws [F]. 2. Set the loudspeaker to the required vertical angle. 3. Retighten the fixing Screws [F]. d&b Z5383 Mounting instructions 1.3 en...
- Page 6 The horizontal aiming is set at the loudspeaker stand adapter or the TV spigot assembly. 1.6. Built-in dimensions Z5383 VP Mounting bracket, built-in dimensions in mm [inch] Z5383 VP Mounting bracket dimensions in mm [inch] Built-in dimensions Z5010/Z5012 Assembly d&b Z5383 Mounting instructions 1.3 en...
- Page 7 When out of use the rigging components must be disposed of in accordance with the national environmental regulations. Ensure that damaged rigging components are disposed of in a way that they cannot be used again. d&b Z5383 Mounting instructions 1.3 en...
