Ametek ECLIPSE II PLUS Owner's Manual page 47

SYMPTOM
Display Reads - Low Battery
Fault
Display Reads - High Battery
Fault
Display Reads - Setup Error
Fault
Display Reads - Check AC
Power
Display Reads -
Overtemperature Fault
Display Reads - Phase Error
Fault
Display Reads - DIDT Fault
05/18/2021
PROBABLE CAUSES
(1) Fixed Cell Setting Incorrect
(2) Bad Harness/Connections – Loose Or Incorrect
(3) Bad Battery
(4) Bad Control Board
(5) Bad Output Cables/Connector
(6) BID Not Programmed Properly
(1) Fixed Cell Setting Incorrect
(2) Bad Battery
(3) Bad Control Board
(4) BID Not Programmed Properly
(1) Cell Size Setting Has Been Changed On Control Board
(2) A.H. Resistor Has Been Changed On Control Board
(3) Bad Keypad Connection (Keypad-Control)
(4) Bad Keypad
(5) Bad Control Board
(1) Intermittent AC Fail (Supply)
(2) Bad Harness/Connection – Loose Or Incorrect
(3) Bad Control Board
(1) See "Unit smells hot" in this chapter
(1) Bad Internal Charger Primary Board
(2) AC Supply
(3) Bad Control Board
(4) Bad Harness/Connections – Loose Or Incorrect
(1) Bad Battery
(2) Bad Control Board
(3) Bad BID
193111-121
TROUBLESHOOTING
ACTION
STEPS
47
3
32
4
13
28
47
32
4
28
48
49
6
7
4
1
3
4
-
5
1
4
3
32
4
28
47
