Programming Your EC2000 Control

The programming function allows 42 functions to be
programmed to customize your Prestolite Eclipse II
Plus to your battery charging application. Program-
ming is not available during an active charge cycle,
and can only be accessed before battery connect or
after charge termination.
All programmable functions are keyed with the
sequence shown below. To prevent unauthorized
access, use the optional password feature. Any
single programming item can be accessed by enter-
ing its function number at the prompt or by using the
arrow keys to scroll to the item. If the password
feature is used and the improper number is entered,
the control will reject access to programming and
display "Password Failed". The sequence may then
be started over.
Keys Display
Program Enter
Function 3-MAH 4-ARCH
2 Enter Prog Func #
Enter password if required. Key in function number
or scroll using arrow keys to reach the desired
programming function (see Figure 7-2).
Once the desired function is reached, press the
"enter" key to enable programming. Functions 33/34
and 59-63 are not programmable. On functions with
several numeric data fields, the display will show
"Enter Numeric Value". The flashing digit will
change as the entries are keyed in. Press the
"Enter" key again when programming of that function
is complete. On functions with 1 or 2 data places,
the display will show "
the arrow keys to increment or decrement the data.
Again press the "Enter" key when programming of
that function is complete.
19. E
PRESENT TIM
The current time. Program in 24 hour military time
format (0000 to 2359 military time).
20.
WEEK DAY
The present day of week (SUN through SAT).
1 = Sunday
Use the up or down arrow to select the proper
setting.
05/18/2021
1-REV 2-PROG
to Change Data". Use
PROGRAMMING YOUR EC2000 CONTROL
21.
EQUALIZE TYPE
The type of auto equalize selected. The types that
can be selected are listed below.
By cycle count (see AUTO EQ. COUNT).
Factory setting.
By the day of week (see AUTO EQ. DAY).
By BID cycle count
Use the up or down arrow to select the proper
setting.
22.
EQUALIZE COUNT
The number of complete charge cycles between
equalize charges when the auto equalize function is
programmed "ON" and the auto equalize type is set
to "COUNT" or "BID".
05 = factory setting
Use the up or down arrow to select the proper
setting.
23.
EQ. DAY
The day of the week that an equalize charge cycle
is performed when the auto equalize function is
"ON" and the auto equalize type is set to "DAY".
Saturday = factory setting
Use the up or down arrow to select the proper
setting.
24.
AUTO EQUALIZE
Sets the auto equalize function on or off.
Auto equalize "ON" = Factory Setting
Use the up or down arrow to select the proper
setting.
25. T.O.D. START
Sets the time of day start time (0000 to 2359 military
time). See START MODE.
Factory = 01:00
26.
DELAYED START
Sets the delayed start time interval
(00H 00M to 23H 59M)
Factory = 00H 00M. See START MODE
27.
BLOCK START
Sets the beginning time of the time of day blockout
function (0000 to 2359 military time). See START
MODE.
Factory = 01:00
