EC2000 CONTROL FEATURES
"Manual Stop" status.
53. BID AMP HOURS
If a connected battery is equipped with a Battery I.D.
module, the battery amp-hour size (0000-9999) may
be reprogrammed into the BID. The control must be
in "Manual Stop" status.
54. BID BATTERY TYPE
If a connected battery is equipped with a Battery I.D.
module, the battery type may be programmed into
the BID. The control must be in "Manual Stop" sta-
tus.
00 FLD
01 CTM
02 YGR
03 SLR
04 DSG
05 SLE
06 DAG
07 CDR
08 MAX
55. PASSWORD
Optional password required to program if turned on.
56. NO GASSING HOURS
The number of Hours before the charger can begin
the gassing portion of the charging cycle. (0 – 8
Hours)
57.
MAX BATT TEMP
The maximum battery temperature for charging to
start or continue. Once interrupted, the charge will
restart after the temperature drops 5 degrees F.
(For use with BID only)
58. BID START AMPS
Programs the charger start rate at the programmed
BID AH rating to the selected amps/100AH. For
example, to charge an 800AH battery at 320 amps,
the "BID Start Amps" would be programmed to
40A/100AH. Please note that if the programmed rate
exceeds the maximum rated charger amps, the
charger output will be limited to the maximum current
rating.
30
Flooded Lead Acid
Custom curve (programmable)
Sealed battery curve
Sealed battery curve
Sealed battery curve
Sealed battery curve
Sealed battery curve
Sealed battery curve
Opportunity Charge curve
59. BATTERY CHARGE AMP HOURS
The accumulated amp hours charged into the battery.
An Amp Hour Accumulator and BID module assembly
must be installed on the battery to use this function.
The Amp Hour Accumulator continually records this
data while it is installed on the battery.
The data is automatically read from the bid when the
control terminates each charge cycle, except for
Manual Stop. The data is stamped with the date and
BID number.
60. BATTERY DISCHARGE AMP HOURS
The accumulated amp hours discharged from the
battery. An Amp Hour Accumulator and BID module
assembly must be installed on the battery to use this
function. The Amp Hour Accumulator / BID continually
records this data while it is installed on the battery.
The data is automatically read from the bid when the
control terminates each charge cycle, except for
Manual Stop. The data is stamped with the date and
BID number.
61. LONG TERM AVERAGE BATTERY
TEMPERATURE
The average BID temperature of the battery. An Amp
Hour Accumulator and BID module assembly must be
installed on the battery to use this function. The BID
continually updates the average while it is installed on
the battery.
The data is automatically read from the bid when the
control terminates each charge cycle, except for
Manual Stop. The data is stamped with the date and
BID number.
62. BATTERY CYCLES
The number of battery discharge cycles, based on
the total discharge amp hours and 80% of the BID
amp hour setting. An Amp Hour Accumulator and
BID module assembly must be installed on the
battery to use this function. The control continually
updates this calculation using the total accumulated
discharge amp hours read in from the BID.
