63. CHARGE/DISCHARGE RATIO
The ratio of the total charge amp hours over the
total discharge amp hours. An Amp Hour Accumu-
lator and BID module assembly must be installed on
the battery to use this function. The control continu-
ally updates this calculation using the total accumu-
lated charge and discharge amp hours read in from
the BID.
64. LCD DISPLAY CONTRAST ADJUST
Make this adjustment if the LCD display is difficult to
read. Be sure the unit is in its permanent mounted
position before making the adjustment.
65. FIXED START AMPS
(Opportunity/Fast charging without a BID)
Programs the charger start rate at the programmed
charger AH setting to the selected amps/100AH.
For example, to charge an 800AH battery at 320
amps, the "battery start amps" would be pro-
grammed to 40A/100AH. Please note that if the
programmed rate exceeds the maximum rated
charger amps, the charger output will be limited to
the maximum current rating.
66. MAX CELL SIZE
Programs the Max Cell Size available on 40 cell
Chargers in the multi-cell mode. The charger
cannot automatically recognize the difference
between 40 and 36 cell sizes and therefore, the
Max Cell Size in that mode must be programmed to
36 or 40 cells. Regardless of this setting, 36 or 40
cell batteries with properly programmed Prestolite
BID modules will correctly be charged.
36 = 36 Cells
40 = 40 Cells
05/18/2021
EC2000 CONTROL FEATURES
67. NETWORK ID
The Network ID for the battery charger.
Default = 1234
68. EXTRA RUN TIME
The charge time can be extended past the normal
charge termination point (pT/dV/dT or VT) from 0 to
59 minutes. If equalize has been selected, any extra
run time programmed will not be added. This feature
may be useful in some abnormal charging situations
such as cold storage.
69. TMP COMP LEVEL
The VT Termination type selected for automatic tem-
perature compensation level (when used with a Pres-
tolite BID)
STD (1) - 4 hours VT
Def (0) - 6 hours VT
