COROLLA
2 0 1 0
I n f o r ma t i o n P r o v i d e d b y :
00505-QRG10-COR

QUICK REFERENCE

GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Corolla 2010 and is the answer not in the manual?

Questions and answers

Related Manuals for Toyota Corolla 2010

Summary of Contents for Toyota Corolla 2010

  • Page 1: Quick Reference

    COROLLA 2 0 1 0 CUSTOMER EXPERIENCE CENTER 1-800-331-4331 QUICK REFERENCE GUIDE Printed in U.S.A. 1/09 I n f o r ma t i o n P r o v i d e d b y : 00505-QRG10-COR 08-TCS-02940...
  • Page 2 Owner’s Manual and supplementary manuals so you will have a better understanding of your vehicle’s capabilities and limitations. Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your Jack Spare tire new Corolla.

  • Page 3: Table Of Contents

    Spare tire & tools Tire Pressure Monitoring (warning) System 20 Trunk-Internal release Visit your Toyota dealer for information on customizing this feature. Programmable by customer. Refer to the Owner’s Manual for instructions and more information. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 4 OVERVIEW Instrument panel Steering wheel controls Steering wheel audio controls Voice command button Telephone controls Ignition switch (mechanical key) Cruise control VSC/TRAC OFF switch Power rearview mirror control Auxiliary storage Headlight, turn signal and front fog light controls Wiper and washer controls Emergency flasher button Audio system Air Conditioning controls...
  • Page 5 Air Conditioning system Front passenger seatbelt reminder light “AIR BAG ON” and “AIR BAG OFF” indicator Engine immobilizer indicator AUX adapter Tire Pressure Monitoring (warning) System reset Tilt and telescopic steering control Hood lock release lever If equipped Vehicles with navigation system: for details, refer to the “Navigation System Owner’s Manual.”...

  • Page 6: Instrument Cluster

    OVERVIEW Instrument cluster Optitron type meters Non-optitron type meters Service indicator and reminder Tachometer Speedometer Fuel gauge Trip meter reset/Instrument panel light control Odometer and two trip meters Automatic Transmission shift range display (if equipped) Multi-information display Display button Engine coolant temperature I n f o r ma t i o n P r o v i d e d b y :...

  • Page 7: Indicator Symbols

    If indicator does not turn off within a few seconds of starting engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...

  • Page 8: Fuel Tank Door Release And Cap

    OVERVIEW Keyless entry (if equipped) Locking operation Unlocking operation Push ONCE: Driver door TWICE: All doors NOTE: If a door is not opened within 60 seconds of unlocking, all doors will Push relock for safety. Trunk lid operation Panic button Push and hold Push and hold Fuel tank door release and cap...

  • Page 9: Engine Maintenance

    Hood release Pull Pull up latch and raise hood Engine maintenance 4 cylinder (2AZ-FE) engine 4 cylinder (2ZR-FE) engine Engine coolant reservoir Engine oil filler cap Engine oil level dipstick Windshield washer fluid tank Note: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance.

  • Page 10: Automatic Transmission

    FEATURES/OPERATIONS Automatic Transmission (if equipped) Standard type Multi-mode type Park* Reverse Park* Neutral Reverse Drive Neutral Third gear Drive Second gear “S” mode First gear “S” “D” * The ignition switch must be “ON” and the brake pedal depressed to shift from Park.

  • Page 11: Auto Lock Functions 2

    Auto lock functions (if equipped) Automatic door locks can be programmed to operate in two different modes, or turned OFF. -Doors lock when shifting from Park. -Doors lock when the vehicle speed is approximately 12 mph or higher. -Doors unlock when shifting into Park. -Doors unlock when the driver’s door is opened within 10 seconds after setting the engine switch or “ENGINE START STOP”...

  • Page 12: Seats-Head Restraints

    FEATURES/OPERATIONS Seats-Head restraints Rear Front Lock release button Lock release button Windshield wipers & washers Single wipe Adjust frequency* Pull to wash and wipe Interval wipe Slow Fast * Intermittent windshield wiper frequency adjustment Rotate to increase/decrease wipe frequency (if equipped). Windows-Power (if equipped) Driver side Window lock switch...

  • Page 13: Lights & Turn Signals

    Lights & turn signals Headlights Headlights Parking lights High beam Low beam High beam flasher Daytime Running Light system (DRL) Headlights turn on automatically upon starting engine. The brightness of the headlights will automatically change depending on the darkness of the surroundings. Front fog lights (if equipped) Turn Front fog lights come on only when the headlights are on low beam.
  • Page 14 FEATURES/OPERATIONS Audio Type 1 functions Preset buttons - functions in other Eject CD modes indicated above number Push to Push and turn turn to ON/OFF adjust tone & balance Seek Push to skip station/ up/down CD track folder and select radio category Station/CD...
  • Page 15 RADIO To preset stations Tune in the desired station and hold down a preset button (1-6) until you hear a beep. Push desired preset button (1-6) to select. To scan stations Push and hold “SCAN” to scan preset stations. Push again to hold selection.

  • Page 16: Air Conditioning/Heating

    FEATURES/OPERATIONS Air Conditioning/Heating Airflow vent In “ ” or “ ” mode, use fresh air (“ ” indicator OFF) to reduce window fogging. Fan speed Temperature selector Air Conditioning ON/OFF Use for quick cooling. MAX A/C changes air intake to recirculate. It is not possible to change intake to fresh, or to turn A/C OFF in this mode.

  • Page 17: Cruise Control

    Cruise control (if equipped) Turning system ON/OFF System ON/OFF Functions Resume Increase speed Cancel Decrease speed The set speed may also be cancelled by depressing the brake pedal. The set speed may be resumed once vehicle speed exceeds 25 mph. Multi-information display Display button Push the display button to change information in the following:...

  • Page 18: Clock

    FEATURES/OPERATIONS Telephone controls (Bluetooth ® (if equipped) Vehicles with moonroof Vehicles without moonroof Steering wheel telephone switches Start call Volume control End call Voice command button ® Bluetooth technology allows dialing or receive calls without taking hands from the steering wheel or using a cable to connect the compatible telephone and the system.

  • Page 19: Door Locks-Power

    Moonroof (if equipped) Sliding operation Tilting operation Recommended driving position to minimize wind noise. Open Tilt Close Close Push once to open partway; again to open completely. Tilt and telescopic steering wheel Angle Length Hold wheel, push lever down, set angle and length, and return lever.

  • Page 20: Auxiliary Storage

    FEATURES/OPERATIONS Light control-Instrument panel Brightness control Cup holders Front Rear Auxiliary storage Instrument panel Type A Type B Type C Pull Pull Pull Overhead console Push I n f o r ma t i o n P r o v i d e d b y :...

  • Page 21: Child Comfort Guide

    SAFETY AND EMERGENCY FEATURES Seatbelts Take up slack Too high Keep as low on hips as possible If belt is fully extended, then retracted even slightly, it cannot be re-extended beyond that point, unless fully retracted again. This feature is used to help hold child restraint systems securely. To find more information about seatbelts, and how to install a child restraint system, refer to the Owner's Manual.

  • Page 22: Doors-Child Safety Locks

    If the tire pressure indicator flashes for more than 60 seconds and then remains on, take the vehicle to your local Toyota dealer. Note: The warning light may come on due to temperature changes or changes in tire pressure from natural air leakage. If the system has not been initialized recently, setting the tire pressures to factory specifications should turn off the light.
  • Page 23 Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Air Conditioning Anti-lock Brake System Accessory Automatic Locking Retractor Child Restraint System Electronic Control Unit Event Data Recorder Emergency Locking Retractor Electric Power Steering GAWR Gross Axle Weight Rating GVWR Gross Vehicle Weight Rating Emission inspection and maintenance LATCH Lower Anchors and Tethers for Children...

  • Page 24: For Your Information

    A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available on the market. You should know that these parts are not covered by Toyota warranty and that Toyota is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
  • Page 25 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
  • Page 26 CAUTION ■ General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
  • Page 27 This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
  • Page 28 I n f o r ma t i o n P r o v i d e d b y :...
  • Page 29 TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping and safe-driving information. Interior fea- Air conditioning and audio systems, as well as other in- tures terior features for a comfortable driving experience. Maintenance Cleaning and protecting your vehicle, performing do-it- and care...
  • Page 30 1-1. Key information Keys The following keys are provided with the vehicle. Vehicles with smart key system Electronic keys • Operating the smart key system (→P. 23) • Operating wireless remote control function (→P. 33) Mechanical keys Key number plate Vehicles without smart key system (type A) Master keys Operating the wireless remote...
  • Page 31 Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (→P. 407) ■...
  • Page 32 1-1. Key information NOTICE ■ To prevent key damage ● Do not subject the keys to strong shocks, expose them to high tempera- tures by placing them in direct sunlight, or get them wet. ● Do not expose the keys to electromagnetic materials or attach any mate- rial that blocks electromagnetic waves to the key surface.
  • Page 33 1-2. Opening, closing and locking the doors and trunk ∗ Smart key system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. (The driver should always carry the electronic key.) Locks and unlocks the doors (→P.
  • Page 34 1-2. Opening, closing and locking the doors and trunk Unlocking and locking the doors (front door handles only) Grip the handle to unlock the door. Make sure to touch the sensor on the back of the handle. The door cannot be unlocked for 3 seconds after the door is locked.
  • Page 35 1-2. Opening, closing and locking the doors and trunk Antenna location and effective range ■ Antenna location Antennas outside the cabin Antenna outside the trunk Antenna inside the trunk Antennas inside the cabin I n f o r ma t i o n P r o v i d e d b y :...
  • Page 36 1-2. Opening, closing and locking the doors and trunk ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 2.3 ft. (0.7 m) of either of the outside front door handles.
  • Page 37 1-2. Opening, closing and locking the doors and trunk ■ Operation signals A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) ■ Conditions affecting operation The smart key system uses weak radio waves. In the following situations, the communication between the electronic key and the vehicle may be affected, preventing the smart key system and wireless remote control from operating properly.
  • Page 38 1-2. Opening, closing and locking the doors and trunk ■ Switching the door unlock function It is possible to set which doors the entry function unlocks. Turn the “ENGINE START STOP” switch OFF. STEP STEP When the indicator on the key surface is off, press and hold , or for approximately 5 seconds while...
  • Page 39 1-2. Opening, closing and locking the doors and trunk ■ Electronic key battery depletion ● The standard battery life is 1 to 2 years. ● The battery becomes depleted even if the electronic key is not used because the key always transmits radio waves. If the smart key system or the wireless remote control function does not operate, or the detection area becomes smaller, the battery may be depleted.
  • Page 40 1-2. Opening, closing and locking the doors and trunk ● As long as the electronic key is within the effective range, the doors may be locked or unlocked by anyone. ● Even if the electronic key is not inside the vehicle, it may be possible to start the engine if the electronic key is near the window.
  • Page 41 1-2. Opening, closing and locking the doors and trunk ● When an alarm sounds: Take appropriate measures according to the following table. Alarm Situation Correction procedure Tried to lock the doors Retrieve the elec- using the entry function tronic key from the while the electronic key is vehicle and lock the Exterior alarm...
  • Page 42 (→P. 25) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of emitting the radio waves.
  • Page 43 1-2. Opening, closing and locking the doors and trunk ∗ Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle from outside the vehicle. Vehicles with smart key system Locks all doors Unlocks doors Pressing the button unlocks the driver’s door.
  • Page 44 1-2. Opening, closing and locking the doors and trunk ■ Operation signals Doors: A buzzer sounds and the emergency flashers flash to indicate that the doors have been locked/unlocked. (Locked: Once; Unlocked: Twice) Trunk: A buzzer sounds to indicate that the trunk has been unlocked. ■...
  • Page 45 1-2. Opening, closing and locking the doors and trunk ■ Key battery depletion Vehicles with smart key system →P. 29 Vehicles without smart key system If the wireless remote control function does not operate, the battery may be depleted. Replace the battery when necessary. (→P. 347) ■...
  • Page 46 1-2. Opening, closing and locking the doors and trunk ■ Customization that can be configured at Toyota dealer Settings (e.g. trunk unlocking function) can be changed. (Customizable features →P. 452) ■ Certification for wireless remote control For vehicles sold in the U.S.A.
  • Page 47 1-2. Opening, closing and locking the doors and trunk For vehicles sold in Canada NOTE: Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, includ- ing interference that may cause undesired operation of the device. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 48 1-2. Opening, closing and locking the doors and trunk Doors The vehicle can be locked and unlocked using the entry function, wireless remote control, key or door lock switch. ■ Entry function (vehicles with smart key system) →P. 23 ■ Wireless remote control (if equipped) →P.
  • Page 49 1-2. Opening, closing and locking the doors and trunk ■ Inside lock button Locks the door Unlocks the door The front doors can be opened by pulling the inside handle even if the lock buttons are in the lock position. Rear door child-protector lock The door cannot be opened from inside the vehicle when the locks...

  • Page 50: Power Door Lock System

    1-2. Opening, closing and locking the doors and trunk Automatic door locking and unlocking systems (vehicles with power door lock system) The following functions can be set or cancelled: Function Operation Shift position linked Shifting the shift lever out of P locks all door locking function doors.
  • Page 51 1-2. Opening, closing and locking the doors and trunk ■ Setting and canceling the functions To switch between set and canceled, follow the procedure below: Vehicles with smart key system: Close all the doors and STEP switch the “ENGINE START STOP” switch to IGNITION ON mode.
  • Page 52 Vehicles without smart key system The key is in the engine switch and either of the front door is open. ■ Customization that can be configured at Toyota dealer Settings (e.g. unlocking function using a key) can be changed. (Customizable features →P. 452)
  • Page 53 1-2. Opening, closing and locking the doors and trunk CAUTION ■ To prevent an accident Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. ●...
  • Page 54 1-2. Opening, closing and locking the doors and trunk Trunk The trunk can be opened using the entry function, wireless remote control, key or trunk opener. ■ Opening the trunk from inside the vehicle Release the trunk lid. ■ Opening the trunk from outside the vehicle Entry function (vehicles with smart key system) →P.
  • Page 55 1-2. Opening, closing and locking the doors and trunk Trunk opener cancelling system To protect luggage stored in the trunk against theft, do the following procedure. Turn the master key (vehicles without smart key system) or mechanical key (vehicles with smart key system) counterclock- wise to lock the trunk opener fea- ture.
  • Page 56 1-2. Opening, closing and locking the doors and trunk CAUTION ■ Caution while driving ● Keep the trunk lid closed while driving. If the trunk lid is left open, it may hit near-by objects while driving or lug- gage in the trunk may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
  • Page 57 ● Do not attach any accessories other than genuine Toyota parts to the trunk lid. Such additional weight on the trunk lid may cause the lid to fall closed again after it is opened.
  • Page 58 1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Power seat (driver's side only) Seat position switch Seatback angle switch Seat cushion (front) angle switch Vertical height adjustment switch Lumbar support switch I n f o r ma t i o n P r o v i d e d b y :...
  • Page 59 1-3. Adjustable components (seats, mirrors, steering wheel) Manual seat Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (driver’s side only) Active head restraints When occupant’s back presses against the seatback during a rear-end collision, the head restraint moves slightly for- ward to help reduce the risk of whiplash on the seat occupant.
  • Page 60 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Active head restraints Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may appear the head restraint inner structure. These do not indicate problems. During rear-end collision...
  • Page 61 1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats ■ Before folding down the rear seat Stow the rear outside seat belt buckles and move the rear center seat belt buckle as shown. ■ Folding down rear seatbacks Pull the seatback lever in the trunk for the seatback you wish to fold down.
  • Page 62 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ After returning the seatback to the upright position Observe the following precautions. Failure to do so may result in death or serious injury. ● Make sure the seatback is securely locked by pressing forward and rear- ward on the top of the seatback.
  • Page 63 1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. Front seats Pull the head restraints up. Down Push the head restraint down while pushing the lock release button. Lock release button Rear seats Pull the head restraints up.
  • Page 64 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Installing the head restraints Align the head restraint with the installa- tion holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint. ■...
  • Page 65 1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
  • Page 66 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Adjusting the height of the belt (front seats) Down Move the height adjuster up and down as needed. Seat belt comfort guide (outside rear seats) If the shoulder belt sits close to a person's neck, use the seat belt comfort guide.
  • Page 67 1-3. Adjustable components (seats, mirrors, steering wheel) Buckle, position and release the STEP seat belt. Seat belt pretensioners (front seats) The pretensioner helps the seat belt to quickly restrain the occu- pant by retracting the seat belt when the vehicle is subjected to certain types of severe frontal collision.
  • Page 68 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
  • Page 69 Toyota dealer free of charge. ■ Rear outside seat belt Use the seat belt after passing it through the guide if the seat belt comes free from the guide.
  • Page 70 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
  • Page 71 ● Ensure that the belt and tab are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
  • Page 72 1-3. Adjustable components (seats, mirrors, steering wheel) CAUTION ■ Using a seat belt comfort guide ● Make sure the belt is not twisted and that it lies flat. The elastic cord must be behind the belt and the guide must be on the front. ●...
  • Page 73 1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and STEP press the lever down. Adjust to the ideal position by STEP moving the steering wheel horizontally and vertically.
  • Page 74 1-3. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror Glare from the headlights of vehicles behind can be reduced by using the following functions. Manual anti-glare inside rear view mirror Normal position Anti-glare position Auto anti-glare inside rear view mirror In automatic mode, sensors are used to detect the headlights of vehicles behind and the reflected light is automatically reduced.
  • Page 75 1-3. Adjustable components (seats, mirrors, steering wheel) ■ To prevent sensor error To ensure that the sensors operate prop- erly, do not touch or cover them. CAUTION ■ Caution while driving Do not adjust the position of the mirror while driving. Doing so may lead to mishandling of the vehicle and an accident, resulting in death or serious injury.
  • Page 76 1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted using the switch. Select a mirror to adjust. STEP Left Right Adjust the mirror. STEP Right Down Left Folding back the mirrors Push backward to fold the mir- rors.
  • Page 77 1-3. Adjustable components (seats, mirrors, steering wheel) ■ Mirror angle can be adjusted when Vehicles with smart key system The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ACC” or “ON” position. ■...
  • Page 78 1-4. Opening and closing the windows ∗ Power windows The power windows can be opened and closed using the following switches. Closing Opening One-touch opening (driver’s window only) Pressing the switch in the opposite direction will stop win- dow travel partway. Lock switch Press the switch down to lock the passenger window switches.
  • Page 79 1-4. Opening and closing the windows ■ The power windows can be operated when Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ON” position. ■...
  • Page 80 1-4. Opening and closing the windows ∗ Moon roof Use the overhead switches to open, close, and tilt the moon roof up and down. ■ Opening and closing Open* The moon roof stops slightly before the fully opened posi- tion. Push the switch again to fully open.
  • Page 81 1-4. Opening and closing the windows ■ The moon roof can be operated when Vehicles with smart key system The “ENGINE START STOP” switch is in IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ON” position. ■...
  • Page 82 1-4. Opening and closing the windows CAUTION ■ Opening the moon roof Observe the following precautions. Failing to do so may cause death or serious injury. ● Do not allow any passengers to put their hands or heads outside the vehi- cle while it is moving.
  • Page 83 1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. ■ Before refueling the vehicle Vehicles with smart key system Turn the “ENGINE START STOP” switch OFF and ensure that all the doors and windows are closed. Vehicles without smart key system Turn the engine switch OFF and ensure that all the doors and windows are closed.
  • Page 84 1-5. Refueling Hang the fuel tank cap on the STEP back of the fuel filler door. Closing the fuel tank cap When replacing the fuel tank cap, turn it until a clicking sound is heard. After releasing your hand, the cap will turn slightly to the opposite direction.
  • Page 85 ■ When replacing the fuel cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 86 1-5. Refueling NOTICE ■ Refueling Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the exhaust systems to operate abnormally or damaging fuel system components or the vehicle's painted surface. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 87 1-6. Theft deterrent system Engine immobilizer system The vehicle's keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle's on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. Vehicles with smart key sys- The indicator light flashes after the “ENGINE START STOP”...
  • Page 88 1-6. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type engine immobilizer system. ■ Conditions that may cause the system to malfunction ● If the key is in contact with a metallic object ● If the key is in close proximity to or touching a key to the security system (key with a built-in transponder chip) of another vehicle ■...
  • Page 89 1-6. Theft deterrent system CAUTION Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTICE ■ To ensure the system operates correctly Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed.
  • Page 90 1-6. Theft deterrent system Theft prevention labels (for U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto- len vehicles. Do not remove under penalty of law. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 91 1-7. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. (→P. 49) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
  • Page 92 1-7. Safety information CAUTION ■ While driving ● Do not adjust the position of the driver's seat while driving. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
  • Page 93 1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag and front passenger airbag Can help protect the head and chest of the driver and front pas-...
  • Page 94 1-7. Safety information Airbag system components Front airbag sensors SRS warning light Front passenger occupant Front passenger’s seat belt classification system (ECU buckle switch and sensors) Airbag sensor assembly Side and curtain shield air- Curtain shield airbag sen- bag sensors sors Front passenger airbag Driver airbag...
  • Page 95 1-7. Safety information The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. The airbag sensor assembly consists of a safing sensor and an airbag sensor. In certain types of severe frontal or side impacts, the SRS airbag sys- tem triggers the airbag inflators.
  • Page 96 1-7. Safety information ■ SRS warning light This warning light system monitors the airbag sensor assembly, front airbag sensors, side and curtain shield airbag sensors, curtain shield airbag sen- sors, driver's seat position sensor, driver's seat belt buckle switch, front pas- senger occupant classification system, “AIR BAG ON”...
  • Page 97 1-7. Safety information Side airbags and curtain shield airbags ● The SRS side airbags and curtain shield airbags are designed to inflate when the passenger compartment is subjected to a severe impact from the side. Depending on the conditions and type of accident, there are times when the curtain shield airbags may deploy (inflate) in a front impact.
  • Page 98 1-7. Safety information ■ Types of collisions that may not deploy the SRS side airbags and cur- tain shield airbags The SRS side airbags and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a col- lision to the side of the vehicle body other than the passenger compartment.
  • Page 99 1-7. Safety information ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. Do not disconnect the battery cables before contacting your Toyota dealer. ● Any of the SRS airbags have been inflated.
  • Page 100 1-7. Safety information CAUTION ■ SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts.
  • Page 101 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are the safest for infants and children.
  • Page 102 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger. ● Do not drive the vehicle while the driver or passenger has items resting on their knees.
  • Page 103 1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not attach anything to areas such as the door, windshield glass, side door glass, front and rear pillars, roof side rail or assist grip. ● Do not hang coat hangers or other hard objects on the coat hooks.
  • Page 104 If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. ■ Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer.
  • Page 105 1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for the front passenger.
  • Page 106 1-7. Safety information Conditions and operation of the front passenger occupant classification system ■ Adult “AIR BAG ON” and “AIR BAG OFF” indicator “AIR BAG lights ON” Indicator/ SRS warning light warning light Front passenger’s seat belt reminder light Flashing Front passenger airbag Side airbag on the front passenger seats...
  • Page 107 1-7. Safety information ■ Unoccupied “AIR BAG ON” and “AIR BAG OFF” indicator Not illuminated lights Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seats Devices Curtain shield airbag in the front Activated passenger side...
  • Page 108 1-7. Safety information : Never install a rear-facing child restraint system on the front pas- senger seat. A forward-facing child restraint system should only be installed on the front passenger seat when it is unavoidable. (→P. 100) : In case the indicator is not illuminated, consult this manual as for installing the child restraint system properly.
  • Page 109 Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
  • Page 110 1-7. Safety information Child restraint systems A child restraint system for a small child or baby must be properly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of U.S.A. and Canada now require the use of child restraint systems.
  • Page 111 1-7. Safety information Types of child restraints Child restraint systems are classified into the following 3 types according to the age and size of the child. Rear facing ⎯ Infant seat/convertible seat Forward facing ⎯ Convertible seat Booster seat I n f o r ma t i o n P r o v i d e d b y :...
  • Page 112 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
  • Page 113 1-7. Safety information CAUTION ■ Child restraint precautions ● Do not use the seat belt extender when installing a child restraint system on the front or rear passenger seat. If installing a child restraint system with the seat belt extender connected to the seat belt, the seat belt will not securely hold the child restraint system, which could cause death or seri- ous injury to the child or other passengers in the event of an accident.
  • Page 114 1-7. Safety information Installing child restraints Follow the child restraint system manufacturer's instructions. Firmly secure child restraints to the rear seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
  • Page 115 1-7. Safety information Installation with LATCH system Rear right seat only: Slide the STEP rear center seat belt to the side to prevent it from getting pinched in the lower anchorage. Type A STEP Widen the gap between the seat cushion and seatback slightly.
  • Page 116 1-7. Safety information Type B STEP Widen the gap between the seat cushion and seatback slightly. STEP Latch the buckles onto the LATCH anchors. STEP If the child restraint has a top tether strap, the top tether strap should be latched onto tether strap anchors.
  • Page 117 1-7. Safety information Installing child restraints using a seat belt (child restraint lock function belt) Rear facing ⎯ Infant seat/convertible seat ■ Place the child seat on the rear STEP seat facing the rear of the vehi- cle. Run the seat belt through the STEP child seat and insert the plate into the buckle.
  • Page 118 1-7. Safety information While pushing the child seat STEP down into the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
  • Page 119 1-7. Safety information While pushing the child seat into STEP the rear seat, allow the shoulder belt to retract until the child seat is securely in place. After shoulder belt retracted to a point where there is no slack in the belt, pull the belt to check that it cannot be extended.
  • Page 120 1-7. Safety information Removing a child restraint installed with a seat belt Push the release button and fully retract the seat belt. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 121 1-7. Safety information Child restraint systems with a top tether strap STEP Secure the child restraint using a seat belt lower anchor, and do the following. Outside Remove the head restraint. Center Lock the head restraint in place at the lowest position. Open the anchor bracket cover, STEP latch the hook onto the anchor...
  • Page 122 1-7. Safety information Outside only: Replace the head STEP restraint. ■ Laws and regulations pertaining to anchorages The LATCH system conforms to FMVSS225 or CMVSS210.2. Child restraint systems conforming to FMVSS213 or CMVSS213 specifica- tions can be used. This vehicle is designed to conform to the SAE J1819. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 123 1-7. Safety information CAUTION ■ When installing a booster seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode: (→P. 59) ALR mode causes the belt to tighten only which could cause injury or dis- comfort to the child.
  • Page 124 1-7. Safety information CAUTION ■ When installing a child restraint system ● When a booster seat is installed, always ensure that the shoulder belt is positioned across the center of the child's shoulder. The belt should be kept away from the child's neck, but not so that it could fall off the child's shoulder.
  • Page 125 2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. ■ Starting the engine →P. 126, 130 ■ Driving Automatic transmission STEP With the brake pedal depressed, shift the shift lever to D. (→P.
  • Page 126 2-1. Driving procedures ■ Parking the vehicle Automatic transmission STEP With the shift lever in D, depress the brake pedal. STEP Set the parking brake. (→P. 141) STEP Shift the shift lever to P. (→P. 134) When parking on a hill, if necessary, block the wheels. STEP Vehicles with smart key system: Turn the “ENGINE START STOP”...
  • Page 127 ■ Breaking in your new Toyota To extend the life of the vehicle, the following precautions are recommended to observe: ●...
  • Page 128 2-1. Driving procedures ■ Operating your vehicle in a foreign country Comply with the relevant vehicle registration laws and confirm the availability of the correct fuel. (→P. 426) ■ Normal characteristics after turning off the engine Approximately five hours after the engine is turned off, you may hear sound coming from under the vehicle for several minutes.
  • Page 129 If the smell of exhaust is noticed inside the vehicle, open the windows and check that the trunk is closed. Large amounts of exhaust in the vehicle can cause driver drowsiness and an accident, resulting in death or a serious health hazard. Have the vehicle inspected by your Toyota dealer immedi- ately. ●...
  • Page 130 2-1. Driving procedures CAUTION ● Do not adjust the position of the steering wheel, the seat, or the inside or outside rear view mirrors while driving. Doing so may result in a loss of vehicle control that can cause accidents that may result in death or serious injury.
  • Page 131 The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
  • Page 132 2-1. Driving procedures CAUTION ■ When taking a nap in the vehicle Always turn the engine off. Otherwise, you may accidentally move the shift lever or depress the accelerator pedal, which could cause an accident or fire due to engine overheating. Additionally, if the vehicle is parked in a poorly ventilated area, exhaust gases may collect and enter the vehicle, leading to death or a serious health hazard.
  • Page 133 2-1. Driving procedures NOTICE ■ When driving the vehicle Manual transmission ● Do not shift gears unless the clutch pedal is fully depressed. After shifting, do not release the clutch abruptly. Doing so may damage the clutch, tran- saxle and gears. ●...
  • Page 134 If you hear a squealing or scraping noise (brake pad wear limit indica- tors) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage can result if the pads are not replaced when needed.
  • Page 135 2-1. Driving procedures Engine (ignition) switch (vehicles with smart key system) Performing the following operations when carrying the electronic key on your person starts the engine or changes “ENGINE START STOP” switch modes. ■ Starting the engine STEP Check that the parking brake is set. STEP Check that the shift lever is set in P.
  • Page 136 2-1. Driving procedures ■ Changing “ENGINE START STOP” switch mode Modes can be changed by pressing the “ENGINE START STOP” switch with the brake pedal released. (The mode changes each time the switch is pressed.) OFF* The emergency flashers can be used.
  • Page 137 ■ When the “ENGINE START STOP” switch indicator flashes in amber The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ Auto power OFF function If the vehicle is left in ACCESSORY mode for more than an hour with the shift lever in P, the “ENGINE START STOP”...
  • Page 138 2-1. Driving procedures CAUTION ■ When starting the engine Always start the engine while sitting in the driver's seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. ■...
  • Page 139 2-1. Driving procedures Engine (ignition) switch (vehicles without smart key system) ■ Starting the engine Automatic transmission STEP Check that the parking brake is set. STEP Check that the shift lever is set in P. STEP Sit in the driver’s seat and firmly depress the brake pedal. STEP Turn the engine switch to the “START”...
  • Page 140 2-1. Driving procedures ■ Changing engine switch position “LOCK” The steering wheel is locked and the key can be removed. (Vehicles with an automatic transmission: The key can be removed only when the shift lever is in P.) “ACC” Some electrical components such as the audio system can be used.
  • Page 141 2-1. Driving procedures ■ Steering lock release When starting the engine, the engine switch may seem stuck in the “LOCK” position. To free it, turn the key while turn- ing the steering wheel slightly in either direction. ■ If the engine does not start The engine immobilizer system may not have been deactivated.
  • Page 142 2-1. Driving procedures NOTICE ■ To prevent battery discharge Do not leave the key in the “ACC” or “ON” position for long periods if the engine is not running. ■ When starting the engine ● 2.4 L 4-cylinder (2AZ-FE) engine: Do not crank for more than 30 seconds at a time.
  • Page 143 2-1. Driving procedures ∗ Automatic transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever Standard type Vehicles with smart key system: While the “ENGINE START STOP” switch is in IGNITION ON mode, depress the brake pedal and move the shift lever.
  • Page 144 2-1. Driving procedures Multi-mode type While the engine switch is in “ON” position, depress the brake pedal and move the shift lever. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 145 2-1. Driving procedures ■ Shift position uses Function Shift position Standard type Multi-mode type Parking the vehicle or starting the engine Reversing Neutral Normal driving S mode driving (→P. 137) Position for engine braking Position for more powerful engine braking Position for maximum engine braking : Shifting to the D position allows the system to select a gear suitable...
  • Page 146 2-1. Driving procedures Changing shift ranges in S mode (multi-mode type) Shift the shift lever to the S position and operate the shift lever. Upshifting Downshifting The initial shift range in S mode is automatically set to 4 or 5. 5-speed models: When the shift range is “4”...
  • Page 147 S (multi-mode type) This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the vehicle will operate as if the shift lever is in D.) I n f o r ma t i o n P r o v i d e d b y :...
  • Page 148 2-1. Driving procedures ∗ Manual transmission ■ Shifting the shift lever Fully depress the clutch pedal before operating shift lever, and then release the clutch pedal slowly. ■ Maximum allowable speeds Observe the following maximum allowable speeds in each gear when maxi- mum acceleration is necessary.
  • Page 149 2-1. Driving procedures Turn signal lever Right turn Left turn Move and hold the lever partway to signal a lane change. The right hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change.
  • Page 150 2-1. Driving procedures Parking brake U.S.A. Canada Sets the parking brake Fully set the parking brake while depressing the brake pedal. Releases the parking brake Slightly raise the lever and lower it completely while pressing the but- ton. NOTICE ■ Before driving Fully release the parking brake.
  • Page 151 2-1. Driving procedures Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (→P.
  • Page 152 2-2. Instrument cluster Gauges and meters Optitron type meters Vehicles with smart key system The following gauges, meters and displays illuminate when the “ENGINE START STOP” switch is in IGNITION ON mode. Vehicles without smart key system The following gauges, meters and displays illuminate when the engine switch is in the “ON”...
  • Page 153 2-2. Instrument cluster Odometer/trip meter/instrument panel light control and trip meter reset button Switches between odometer and trip meter displays. Pressing and holding the button will reset the trip meter when the trip meter is being displayed. To adjust the brightness of the instrument panel light, turn the button. (→P.
  • Page 154 2-2. Instrument cluster Non-Optitron type meters The following gauges, meters and displays illuminate when the engine switch is in “ON” position. Tachometer Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed. Fuel gauge Displays the quantity of fuel remaining in the tank. Low fuel level warning light →P.
  • Page 155 2-2. Instrument cluster Odometer and trip meter display Odometer: Displays the total distance the vehicle has been driven. Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display different distances independently.
  • Page 156 2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. ■ Instrument cluster Optitron type meters Non-Optitron type meters I n f o r ma t i o n P r o v i d e d b y :...
  • Page 157 2-2. Instrument cluster ■ Center panel I n f o r ma t i o n P r o v i d e d b y :...
  • Page 158 2-2. Instrument cluster ■ Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator Headlight indicator (→P. 140) (→P. 154) (U.S.A.) Headlight high beam Tail light indicator indicator (→P. 154) (→P. 154) (Canada) Slip indicator Front fog light indicator...

  • Page 159: Warning Lights

    Have the vehicle inspected by your Toyota dealer immediately if this occurs.
  • Page 160 2-2. Instrument cluster Multi-information display The multi-information display presents the driver with a variety of driving-related data, including the outside temperature. ● Outside temperature dis- play Indicates the outside tempera- ture. ● Trip information Displays driving range, fuel consumption and other cruis- ing-related information.
  • Page 161 2-2. Instrument cluster ● Average fuel consumption Displays the average fuel consumption since the function was reset. The function can be reset by pressing the display but- ton for longer than one second when the average fuel consumption is displayed. ●...
  • Page 162 2-2. Instrument cluster ■ When disconnecting and reconnecting battery terminals The following information data will be reset. ● Average fuel consumption ● Driving range ● Average vehicle speed ● Elapsed time ■ Display In the following situations, the correct outside temperature may not be dis- played, or the display may take longer than normal to change.
  • Page 163 2-3. Operating the lights and wipers Headlight switch The daytime running lights turn on. side marker, parking, tail, license plate, daytime run- ning lights and instru- ment panel lights turn U.S.A.* Canada* The headlights and all lights listed above (except daytime run- ning lights) turn on.
  • Page 164 2-3. Operating the lights and wipers ■ Daytime running light system ● To make your vehicle more visible to other drivers, the headlights turn on automatically whenever the engine is started and the parking brake is released. The brightness of headlights will automatically change depending on the darkness of the surroundings.
  • Page 165 2-3. Operating the lights and wipers ∗ Fog light switch The fog lights improve visibility in difficult driving conditions, such as in rain or fog. They can be turned on only when the headlights are on low beam. Front fog lights on ∗...
  • Page 166 2-3. Operating the lights and wipers Windshield wipers and washer Wiper intervals can be adjusted for intermittent operation. Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Increases the intermittent windshield wiper frequency* Decreases the intermittent windshield wiper frequency* *: The interval adjuster may not...
  • Page 167 ■ When a nozzle becomes blocked In this case, contact your Toyota dealer immediately. Do not try to clear it with a pin or other object. The nozzle will be damaged. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 168 2-4. Using other driving systems ∗ Cruise control Use cruise control to maintain a set speed without using the acceler- ator. Indicator Cruise control switch ■ Setting the vehicle speed STEP Press the “ON-OFF” button to activate the cruise control. Press the button once more to deactivate the cruise control.
  • Page 169 2-4. Using other driving systems ■ Adjusting the speed setting Increase speed Decrease speed Hold the lever until the desired speed setting is obtained. Fine adjustment of the set speed (approximately 1.0 mph [1.6 km/h]) can be made by lightly pushing the lever up or down and releasing it.
  • Page 170 If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Contact your Toyota dealer and have your Toyota inspected. CAUTION ■...
  • Page 171 2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
  • Page 172 2-4. Using other driving systems To disable TRAC and/or VSC If the vehicle gets stuck in fresh snow or mud, TRAC and VSC may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it. ■...
  • Page 173 • The brake pedal may move down slightly after ABS is activated. ■ If the “VSC OFF” indicator light flashes There is a malfunction in the TRAC and VSC systems. Contact your Toyota dealer and have your Toyota inspected. ■...
  • Page 174 In addition, make sure that the tires are inflated to the recom- mended tire pressure level. The ABS and VSC system will not function correctly if different tires are fitted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause the system to malfunction.
  • Page 175 2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. ● Stow cargo and luggage in the trunk whenever possible. Be sure all items are secured in place. ● Be careful to keep the vehicle level. Placing the weight as far for- ward as possible helps maintain vehicle balance.
  • Page 176 2-5. Driving information (6) If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. (→P. 174) Example on your vehicle Cargo capacity Total load capacity...
  • Page 177 2-5. Driving information CAUTION ■ Storage precautions Observe the following precautions. Failing to do so may result in death or serious injury. ● To prevent cargo and luggage from sliding forward during braking, do not stack anything in the enlarged trunk. Keep cargo and luggage low, as close to the floor as possible.
  • Page 178 2-5. Driving information Vehicle load limits Vehicle load limits include total load capacity, seating capacity, towing capacity and cargo capacity. ■ Total load capacity: 825 lb. (370 kg) Total load capacity means the combined weight of occupants, cargo and luggage. ■...
  • Page 179 2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tem- peratures.
  • Page 180 2-5. Driving information ■ When driving the vehicle Accelerate the vehicle slowly and drive at a reduced speed suit- able to road conditions. ■ When parking the vehicle Park the vehicle and move the shift lever to P (automatic trans- mission), 1 or R (manual transmission) without setting the park- ing brake.
  • Page 181 2-5. Driving information Regulations on the use of snow chains ● Regulations regarding the use of tire chains vary according to loca- tion and type of road. Always check local regulations before install- ing chains. ● Install the chains on the front tires. ●...
  • Page 182 NOTICE ■ Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota dealers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
  • Page 183 Towing a trailer will have an adverse effect on handling, perfor- mance, braking, durability, and fuel consumption. For your safety and the safety of others, do not overload the vehicle or trailer. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. ■...
  • Page 184 Total trailer weight Tongue load Towing a trailer Contact your Toyota dealer for further information about additional requirements such as a towing kit, etc. Hitch Trailer hitch assemblies have different weight capacities established by the hitch manufacturer.
  • Page 185 ■ Break-in schedule Toyota recommends that you do not use a new vehicle or a vehicle with any new power train components (engine, transmission, differential, wheel bear- ings, etc.) to tow a trailer for the first 500 miles (800 km) of driving.
  • Page 186 When towing a trailer ● If the gross trailer weight exceeds 1000 lb. (453 kg), trailer brakes are required. Toyota recommends trailers with brakes that conform to all appli- cable federal and state/provincial regulations. ● Never tap into your vehicle's hydraulic system, as this will lower the vehi- cle's braking effectiveness.
  • Page 187 ■ When installing a trailer hitch ● Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ● Do not use axle-mounted hitches, as they can cause damage to the axle housing, wheel bearings, wheels or tires.
  • Page 188 2-5. Driving information ● Reversing with a trailer attached is difficult and requires practice. Grip the bottom of the steering wheel and move your hand to the left to move the trailer to the left. Move your hand to the right to move the trailer to right.
  • Page 189 2-5. Driving information ● In order to maintain efficient engine braking and electrical charging performance, do not use “D” (automatic transmission) or the 5th gear (manual transmission). ● Due to the added load of the trailer, your vehicle's engine may overheat on hot days (at temperatures over 85°F [30°C]) when driving up a long or steep grade.
  • Page 190 2-5. Driving information CAUTION ■ To avoid an accident ● Do not exceed 45 mph (72 km/h) or posted towing speed limit, whichever is lower. As instability (swaying) of the towing vehicle-trailer combination increases as speed increases, exceeding 45 mph (72 km/h) may cause loss of control.
  • Page 191 2-5. Driving information Dinghy towing (automatic transmission) Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 192 2-5. Driving information Dinghy towing (manual transmission) Your vehicle can be dinghy towed in a forward direction (with 4 wheels on the ground) behind a motor home. Towing your vehicle with 4 wheels on the ground To prevent damage to your vehicle, perform the following procedures before towing.
  • Page 193 2-5. Driving information NOTICE ■ Dinghy towing direction Do not tow the vehicle backwards. Doing so may cause serious damage. ■ To prevent the steering from locking Ensure the engine switch is in the “ACC” position. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 194 2-5. Driving information I n f o r ma t i o n P r o v i d e d b y :...
  • Page 195 3-1. Using the air conditioning system and defogger ∗ Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Temperature control Automatic mode Windshield defogger Air conditioning ON/OFF switch Air intake mode switch Fan speed Temperature setting display Fan speed display...
  • Page 196 3-1. Using the air conditioning system and defogger Adjusting the settings ■ Adjusting the temperature setting Press “∧” to increase the temperature and “∨” to decrease the tem- perature on ■ Adjusting the fan speed Press “∧” (increase) or “∨” (decrease) on The fan speed is shown on the display.
  • Page 197 3-1. Using the air conditioning system and defogger Air flows to the upper body and feet. : Some models Mainly air flows to the feet. : Some models Air flows to the feet and the windshield defogger operates. Recirculated air mode will auto- matically switch to outside air mode.
  • Page 198 3-1. Using the air conditioning system and defogger Defogging the windshield Defogging The air conditioning system con- trol operates automatically. Recirculated air mode will auto- matically switch to outside air mode. It is not possible to return to recirculated air mode when the switch is on.
  • Page 199 3-1. Using the air conditioning system and defogger I n f o r ma t i o n P r o v i d e d b y :...
  • Page 200 3-1. Using the air conditioning system and defogger ■ Using the automatic mode Fan speed is adjusted automatically in accordance with the temperature set- ting and ambient conditions. As a result, the following may occur. ● Immediately after is pressed, the fan may stop for a while until warm or cool air is ready to flow.
  • Page 201 3-1. Using the air conditioning system and defogger CAUTION ■ To prevent the windshield from fogging up Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
  • Page 202 3-1. Using the air conditioning system and defogger ∗ Manual air conditioning system Heater Air outlet selection dial Temperature control dial Fan speed control dial Air intake mode switch ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
  • Page 203 3-1. Using the air conditioning system and defogger Air conditioning system Air outlet selection dial Temperature control dial Fan speed control dial Air intake mode switch Air conditioning ON/OFF switch Adjusting the settings ■ Adjusting the temperature setting (heater) Turn the temperature control dial clockwise to increase the temper- ature.
  • Page 204 3-1. Using the air conditioning system and defogger ■ Adjusting the fan speed Turn the fan speed control dial clockwise (increase) or counter- clockwise (decrease). Set the dial to “0” to turn the fan off. ■ Selecting the air outlets Set the air outlet selection dial to an appropriate position.
  • Page 205 3-1. Using the air conditioning system and defogger Mainly air flows to the feet. : Some models Air flows to the feet and the windshield defogger operates. The air intake is automatically switched to outside air mode. It is not possible to return to recircu- lated air mode when the switch is : Some models Air flows to the windshield and...
  • Page 206 3-1. Using the air conditioning system and defogger Adjusting the position of and opening and closing the air outlets Center outlets Direct air flow to the left or right, up or down. Right and left side outlets Direct air flow to the left or right, up or down.
  • Page 207 3-1. Using the air conditioning system and defogger ■ For quick cooling (vehicles with air conditioning system) Turn the temperature control dial to the “MAX A/C” position and select the recirculated air mode. ■ For quick clearing of the windshield and side windows (vehicles with air conditioning system) Press to turn the air conditioning on.
  • Page 208 3-1. Using the air conditioning system and defogger CAUTION ■ To prevent the windshield from fogging up Do not set the air outlet selection dial to during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
  • Page 209 3-1. Using the air conditioning system and defogger Rear window and outside rear view mirror defoggers Clear the rear window using the defogger. Vehicles with automatic air conditioning system On/off The defoggers will automati- cally turn off after approxi- mately 15 minutes. Vehicles with manual air conditioning system On/off The defoggers will automati-...
  • Page 210 3-2. Using the audio system Audio system types With navigation system Owners of models equipped with a navigation system should refer to the “Navigation System Owner's Manual”. Without navigation system Type A: CD player with changer controller and AM/FM radio Type B: CD player with changer and AM/FM radio I n f o r ma t i o n P r o v i d e d b y :...
  • Page 211 3-2. Using the audio system Title Page Using the radio P. 205 Using the CD player P. 211 Playing MP3 and WMA discs P. 218 Optimal use of the audio system P. 225 Using the AUX adapter P. 228 Using the steering wheel audio switches P.
  • Page 212 3-2. Using the audio system NOTICE ■ To prevent battery discharge Do not leave the audio system on longer than necessary with the engine off. ■ To avoid damaging the audio system Take care not to spill drinks or other fluids over the audio system. I n f o r ma t i o n P r o v i d e d b y :...

  • Page 213: Using The Radio

    3-2. Using the audio system Using the radio Power Volume Changing the channel Adjusting the frequency (AM, FM mode) or channel (SAT mode) Scanning for Station selector receivable stations Displaying radio text AM⋅SAT/FM messages mode buttons Seeking the frequency ® Setting station presets (excluding XM Satellite Radio) ∧...
  • Page 214 3-2. Using the audio system ■ Scanning all radio stations within range Press STEP All stations with reception will be played for 5 seconds each. When the desired station is reached, press once STEP again. ® Satellite Radio* (if equipped) ®...
  • Page 215 *: Except JBL brand audio system⎯ ® ® Satellite Radio requires XM tuner and service. Use of XM Contact your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 216 3-2. Using the audio system ■ When the battery is disconnected Station presets are erased. ■ Reception sensitivity ● Maintaining perfect radio reception at all times is difficult due to the con- tinually changing position of the antenna, differences in signal strength and surrounding objects, such as trains, transmitters, etc.
  • Page 217 XM antenna cable is attached securely. ANTENNA There is a short-circuit in the antenna or the sur- rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to XM Satellite Radio. The radio is being updated with the latest encryp- ®...
  • Page 218 3-2. Using the audio system The channel you selected is no longer available. Wait for about 2 seconds until the radio returns to the previous channel or “CH001”. If it does not change automatically, select another channel. ® Contact the XM Listener Care Center at 1-800-967-2346 (U.S.A.) or 1-877- 438-9677 (Canada).

  • Page 219: Using The Cd Player

    3-2. Using the audio system Using the CD player Power Volume CD load (type B only) CD eject Displaying text messages Selecting a track Searching playback Fast-for- warding a track Playback Random playback Reversing Selecting a CD Repeat play a track Loading CDs ■...
  • Page 220 3-2. Using the audio system ■ Loading multiple CDs (type B) Press and hold until you hear a beep. STEP Insert a CD when the indicator on the slot turns from amber to STEP green. The indicator on the slot turns to amber when the CD is inserted. Insert the next CD when the indicator on the slot turns from STEP amber to green again.
  • Page 221 3-2. Using the audio system Fast-forwarding and reversing tracks To fast-forward or reverse, press (reverse) or (fast-for- ward). Scanning tracks Press STEP The first ten seconds of each track will be played. Press again when the desired track is reached. STEP Selecting a CD (type A with a CD changer and type B) ■...

  • Page 222: Random Playback

    3-2. Using the audio system Random playback ■ Current CD Press (RAND). Tracks are played in a random order until is pressed once more. ■ All CDs (type A with a CD changer and type B) Press and hold (RAND) until you hear a beep. Tracks on all loaded CDs are played in a random order until pressed once more.
  • Page 223 Operation has stopped due to a high temperature inside the player. Wait for a while and then press . Contact your Toyota dealer if the CD still cannot be played back. ■ Discs that can be used Discs with the marks shown below can be used.
  • Page 224 3-2. Using the audio system NOTICE ■ CDs and adapters that cannot be used Do not use the following types of CDs, 3 in. (8 cm) CD adapters or Dual Discs. Doing so may damage the CD player and/or the CD insert/eject function. ●...
  • Page 225 3-2. Using the audio system NOTICE ■ CD player precautions Failure to follow the precautions below may result in serious damage to the CDs or the player itself. ● Do not insert anything other than CDs into the CD slot. ●...

  • Page 226: Playing Mp3 And Wma Discs

    3-2. Using the audio system Playing MP3 and WMA discs Power Volume CD load CD eject Selecting a file (type B only) Selecting Selecting a folder a file Fast-for- Searching warding playback a file Displaying text Reversing Random playback a file messages Repeat play Selecting a CD...
  • Page 227 3-2. Using the audio system Selecting and scanning a folder ■ Selecting folders one at a time Press “∧” or “∨” on to select the desired folder. ■ Selecting the desired folder by cueing the first file of each folder Press and hold until you hear a beep.
  • Page 228 3-2. Using the audio system Repeat play ■ To repeat a file Press (RPT). ■ To repeat all of the files in a folder Press and hold (RPT) until you hear a beep. Random playback ■ To play files from a particular folder in random order Press (RAND).
  • Page 229 Operation has stopped due to a high temperature inside the player. Wait for a while and then press . Contact your Toyota dealer if the CD still cannot be played. “NO MUSIC”: This indicates that the MP3/WMA file is not included in the ■...
  • Page 230 3-2. Using the audio system ■ MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
  • Page 231 3-2. Using the audio system ● Compatible disc formats The following disc formats can be used. • Disc formats: CD-ROM Mode 1 and Mode 2 CD-ROM XA Mode 2, Form 1 and Form 2 • File formats: ISO9660 Level 1, Level 2, (Romeo, Joliet) MP3 and WMA files written in any format other than those listed above may not play correctly, and their file names and folder names may not be displayed correctly.
  • Page 232 3-2. Using the audio system ● Extensions If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be mistakenly recognized and played as MP3 and WMA files. This may result in large amounts of interference and damage to the speakers.

  • Page 233: Optimal Use Of The Audio System

    3-2. Using the audio system Optimal use of the audio system Displays the current mode Changes the following set- tings • Sound quality and volume balance (→P. 226) The sound quality and bal- ance setting can be changed to produce the best sound. •...
  • Page 234 3-2. Using the audio system ■ Adjusting sound quality and volume balance Turning adjusts the level. Mode Sound qual- Turn to the Turn to the Level displayed ity mode left right BAS* Bass -5 to 5 Mid- 1, 2 MID* -5 to 5 High range...
  • Page 235 3-2. Using the audio system ■ Adjusting the Automatic Sound Levelizer (ASL) Except JBL brand audio system When “ASL” is selected, turning to the right changes the “ASL” level in the order of “LOW”, “MID” and “HIGH”. Turning to the left turns “ASL” off. ASL automatically adjusts the volume and tone quality according to vehi- cle speed.

  • Page 236: Using The Aux Adapter

    3-2. Using the audio system Using the AUX adapter This adapter can be used to connect a portable audio device and lis- ten to it through the vehicle’s speakers. Open the cover and connect STEP the portable audio device. Press STEP ■...

  • Page 237: Using The Steering Wheel Audio Switches

    3-2. Using the audio system ∗ Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Volume Radio: Select radio stations Select tracks, files (MP3 and WMA) and discs Power on/off, select audio source Turning on the power Press...
  • Page 238 ® ® Use of XM Satellite Radio requires XM tuner and service. Contact your Toyota dealer. Adjusting the volume Press “+” on to increase the volume and “-” to decrease the volume. Press and hold the switch to continue increasing or decreasing the vol- ume.
  • Page 239 3-2. Using the audio system Selecting a track/file Press to select the CD mode. STEP Press to select the desired track/file. STEP Selecting a folder (type A) Press to select the CD mode. STEP Press and hold until you hear a beep. STEP Selecting a disc (type A with a CD changer and type B) Press...
  • Page 240 3-3. Using the hands-free phone system (for cellular phone) ∗ Hands-free phone system (for cellular phone) features ® This system supports Bluetooth , which allows you to make or receive calls without using cables to connect a cellular phone and the system, and without operating the cellular phone.
  • Page 241 3-3. Using the hands-free phone system (for cellular phone) ■ Trademark owned by Bluetooth SIG. Inc. ■ Certification for the hands-free phone system FCC ID: ACJ932C5ZZZ035 IC ID: 216J-C5ZZZ035 MADE IN JAPAN NOTE: This device complies with Part 15 of the FCC Rules and RSS-210 of industry Canada.
  • Page 242 3-3. Using the hands-free phone system (for cellular phone) FCC WARNING: Changes or modifications in construction not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. CAUTION: Radio Frequency Radiation Exposure This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65.

  • Page 243: Using The Hands-Free Phone System (For Cellular Phone)

    3-3. Using the hands-free phone system (for cellular phone) ∗ Using the hands-free phone system (for cellular phone) ■ Audio unit Displays such items as message, name, and phone number Lower-case characters special characters, such as an umlaut, cannot be displayed. Selects speed dials Press and hold: Displays information that is too long...
  • Page 244 3-3. Using the hands-free phone system (for cellular phone) ■ Steering wheel Volume The voice guidance volume cannot be adjusted by using this button. Hands-free phone system on/starts a call (off-hook switch) Hands-free phone system off/ends a call/refuses a call (on-hook switch) Press: Voice command sys- tem on...
  • Page 245 3-3. Using the hands-free phone system (for cellular phone) ■ Microphone Vehicles with moon roof Vehicles without moon roof I n f o r ma t i o n P r o v i d e d b y :...
  • Page 246 3-3. Using the hands-free phone system (for cellular phone) Operating the system by using a voice command By following voice guidance instructions output from the speaker, voice commands can be given to allow for operation of the hands- free phone system without checking the display or operating ■...
  • Page 247 3-3. Using the hands-free phone system (for cellular phone) Using the hands-free phone system for the first time Before using the hands-free phone system, it is necessary to register a cellular phone in the system. The phone registration mode will be entered automatically when starting the system with no cellular phone registered.
  • Page 248 3-3. Using the hands-free phone system (for cellular phone) Menu list of the hands-free phone system ■ Normal operation Second First menu Third menu Operation detail menu Dialing a number stored in Callback the incoming call history memory Dialing a number stored in Redial the outgoing call history memory...
  • Page 249 3-3. Using the hands-free phone system (for cellular phone) Second First menu Third menu Operation detail menu Set PIN Setting a PIN code Phonebook Lock Locking the phone book Security Phonebook Unlocking the phone book Unlock Registering the cellular Pair Phone phone to be used Changing a registered name Change Name...
  • Page 250 3-3. Using the hands-free phone system (for cellular phone) ■ Using a short cut key First menu Second menu Operation detail Dialing a number registered Dial “XXX (name)” in the phone book Phone book add Adding a new number entry Changing the name of a Phone book change phone number in the phone...
  • Page 251 3-3. Using the hands-free phone system (for cellular phone) ■ Automatic adjustment of volume When vehicle speed is 50 mph (80 km/h) or more, the volume automatically increases. The volume returns to the previous volume setting when vehicle speed drops to 43 mph (70 km/h) or less. ■...

  • Page 252: Making A Phone Call

    3-3. Using the hands-free phone system (for cellular phone) Making a phone call ■ Making a phone call ● Dialing by inputting a number “Dial by number” ● Dialing by inputting a name “Dial by name” ● Speed dialing ● Dialing a number stored in the outgoing history memory “Redial”...
  • Page 253 3-3. Using the hands-free phone system (for cellular phone) Dialing by inputting a name Press the talk switch and say “Dial by name”. STEP Select a registered name to be input by either of the following STEP methods: a. Press the talk switch and say a registered name. b.
  • Page 254 3-3. Using the hands-free phone system (for cellular phone) Transferring a call A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call. Use one of the follow- ing methods: a. Operate the cellular phone. Refer to the manual that comes with the cellular phone for the oper- ation of the phone.
  • Page 255 3-3. Using the hands-free phone system (for cellular phone) The following operations can be performed: Dialing: Press the off-hook switch or select “Dial” by using a voice command or Storing the number in the phone book: Select “Store” by using a voice command or Deleting: Select “Delete”...

  • Page 256: Setting A Cellular Phone

    3-3. Using the hands-free phone system (for cellular phone) Setting a cellular phone Registering a cellular phone in the hands-free phone system allows the system to function. The following functions can be used for reg- istered cellular phones: ■ Functions and operation procedures To enter the menu for each function, follow the steps below by using a voice command or ●...
  • Page 257 3-3. Using the hands-free phone system (for cellular phone) Selecting the cellular phone to be used Select “Select Phone” by using a voice command or STEP Pattern A Select the cellular phone to be used by either of the following STEP methods, and select “Confirm”...
  • Page 258 3-3. Using the hands-free phone system (for cellular phone) Press the talk switch or select “Record Name” by using STEP , and say a new name. Select “Confirm” by using a voice command or STEP Listing the registered cellular phones Selecting “List Phones”...
  • Page 259 3-3. Using the hands-free phone system (for cellular phone) Deleting a cellular phone Select “Delete” by using a voice command or STEP Pattern A Select the cellular phone to be deleted by either of the follow- STEP ing methods and select “Confirm” by using a voice command a.
  • Page 260 3-3. Using the hands-free phone system (for cellular phone) Changing the passkey Select “Set Passkey” by using a voice command or STEP Pattern A Press the talk switch, say a 4 to 8-digit number, and select STEP “Confirm” by using a voice command or Pattern B Select a 4 to 8-digit number by using STEP...

  • Page 261: Security And System Setup

    3-3. Using the hands-free phone system (for cellular phone) Security and system setup To enter the menu of each setting, follow the steps below: ■ Security setting items and operation procedure ● Setting or changing the PIN (Personal Identification Number) 1.
  • Page 262 3-3. Using the hands-free phone system (for cellular phone) ■ Changing the PIN Select “Set PIN” by using a voice command or STEP Enter the registered PIN by using a voice command or STEP Enter a new PIN by using a voice command or STEP When using , input the code 1 digit at a time.
  • Page 263 3-3. Using the hands-free phone system (for cellular phone) Setting voice guidance volume Select “Guidance Vol” by using STEP Change the voice guidance volume. STEP To decrease the volume: Turn counterclockwise. To increase the volume: Turn clockwise. Initialization Select “Initialize” and then “Confirm” by using STEP Select “Confirm”...
  • Page 264 3-3. Using the hands-free phone system (for cellular phone) ■ Initialization ● The following data in the system can be initialized: • Phone book • Outgoing and incoming call history • Speed dials • Registered cellular phone data • Security code ●...

  • Page 265: Using The Phone Book

    3-3. Using the hands-free phone system (for cellular phone) Using the phone book To enter the menu of each setting, follow the steps below: ● Adding a new phone number 1. “Phonebook” → 2. “Add Entry” ● Setting speed dials 1.
  • Page 266 3-3. Using the hands-free phone system (for cellular phone) ■ Adding procedure Select “Add Entry” by using a voice command or STEP Use one of the following methods to input a telephone num- STEP ber: Inputting a telephone number by using a voice command STEP2-1 Select “By Voice”...
  • Page 267 3-3. Using the hands-free phone system (for cellular phone) Inputting a phone number by using STEP2-1 Select “Manual Input” by using STEP2-2 Input a phone number by using , and press once again. Input the phone number 1 digit at a time. Selecting a phone number from outgoing or incoming call history STEP2-1 Select “Call History”...
  • Page 268 3-3. Using the hands-free phone system (for cellular phone) Select the name to be registered by either of the following STEP methods, and select “Confirm” by using a voice command or a. Press the talk switch and say the desired name. b.
  • Page 269 3-3. Using the hands-free phone system (for cellular phone) Select the desired preset button, and register the data into STEP speed dial by either of the following methods: a. Press the desired preset button, and select “Confirm” by using a voice command or b.
  • Page 270 3-3. Using the hands-free phone system (for cellular phone) Deleting registered data Select “Delete Entry” by using a voice command or STEP Pattern A Select the data to be deleted by either of the following meth- STEP ods, and select “Confirm” by using a voice command or a.
  • Page 271 3-3. Using the hands-free phone system (for cellular phone) Listing the registered data Selecting “List names” by using a voice command causes a list of the registered data to be read aloud. When listing is complete, the system returns to “Phonebook”. Pressing the talk switch while the desired data is being read aloud selects the data, and the following function will be available.
  • Page 272 3-4. Using the interior lights Interior lights list Interior light (→P. 266) Personal lights or personal/interior lights (→P. 266, 267) “ENGINE START STOP” switch light (vehicles with smart key system) I n f o r ma t i o n P r o v i d e d b y :...
  • Page 273 “DOOR” position, the lights will go off automatically after 20 minutes. ■ Customization that can be configured at Toyota dealer Settings (e.g. The time elapsed before lights turn off) can be changed. (Customizable features →P. 452)

  • Page 274: Interior Light

    3-4. Using the interior lights Interior light and personal lights Interior light “DOOR” position Personal lights (vehicles without moon roof) On/off I n f o r ma t i o n P r o v i d e d b y :...
  • Page 275 3-4. Using the interior lights Personal/interior lights Personal/interior lights (vehicles with moon roof) ■ Interior lights “DOOR” position ■ Personal lights On/off I n f o r ma t i o n P r o v i d e d b y :...
  • Page 276 3-5. Using the storage features List of storage features Auxiliary boxes Glove box Bottle holders Cup holders Console box CAUTION ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause the following when cabin temperature becomes high: ●...

  • Page 277: Glove Box

    3-5. Using the storage features Glove box and console box Glove box Pull up the lever. CAUTION ■ Caution while driving Keep the glove box closed. Injuries may result in the event of an accident or sudden braking. Console box Type A Lift the lid while pulling the lever.
  • Page 278 3-5. Using the storage features Console box Type B Lift the lid while pulling the lever. Lift the lid and tray. Lift the lid. Pull the tray up to open the box. ■ When using the console box lid as an armrest (type B only) If necessary, the console box lid can slide forward.

  • Page 279: Cup Holders

    3-5. Using the storage features Cup holders Cup holders Front Rear Pull the lid to open. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 280 3-5. Using the storage features Cup holders ■ Using the cup support (front) Push the cup support. ■ Using the cup holder (front) to store small items Remove the cup support. CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or aluminum cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.

  • Page 281: Auxiliary Boxes

    3-5. Using the storage features Auxiliary boxes Auxiliary boxes Type A Pull up the lever. Type B (if equipped) Pull the lid. Type C (vehicles with moon roof) Push the lid. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 282 3-5. Using the storage features Auxiliary boxes Type D Pull up the lever. CAUTION ■ Caution while driving Keep the auxiliary boxes closed. Injuries may result in the event of an accident or sudden braking. ■ Items unsuitable for storing (type C only) Do not store items heavier than 0.4 lb.

  • Page 283: Bottle Holders

    3-5. Using the storage features Bottle holders Bottle holders Front Rear CAUTION ■ Items unsuitable for the bottle holder Do not place anything other than pet bottles in the bottle holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
  • Page 284 3-6. Other interior features Sun visors Forward position: Flip down. Side position: Flip down, unhook, and swing to the side. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 285 3-6. Other interior features Vanity mirrors Slide the cover. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 286 3-6. Other interior features Clock Adjusts the hour Adjusts the minutes ■ The clock is displayed when Vehicles with smart key system The “ENGINE START STOP” switch is in ACCESSORY or IGNITION ON mode. Vehicles without smart key system The engine switch is in the “ACC” or “ON” position. ■...
  • Page 287 3-6. Other interior features Grocery bag hook This hook is designed to hang things like grocery bag. NOTICE ■ Grocery bag hook weight capacity Do not hang any object heavier than 7 lb. (3 kg) on the grocery bag hook. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 288 3-6. Other interior features ∗ Ashtray Pull the lid to open. Pull the ashtray to remove. CAUTION ■ When not in use Keep the ashtray closed. Injuries may result in the event of sudden braking, sudden swerving or an accident. ■...
  • Page 289 3-6. Other interior features ∗ Cigarette lighter Pull the lid to open, and push the cigarette lighter down. The cigarette lighter will pop up when it is ready for use. ■ The cigarette lighter can be used when Vehicles with smart key system The “ENGINE START STOP”...
  • Page 290 3-6. Other interior features Power outlet The power outlet can be used for 12 V accessories that run on less than 10 A. Type A (if equipped) Type B ■ The power outlet can be used when Vehicles with smart key system The “ENGINE START STOP”...
  • Page 291 3-6. Other interior features NOTICE ■ To avoid damaging the power outlet Close the power outlet lid when the power outlet is not in use. Foreign objects or liquids that enter the power outlet may cause a short cir- cuit. ■...
  • Page 292 3-6. Other interior features ∗ Seat heaters Heats the driver’s seat Heats the front passenger’s seat The indicator light is on while the seat heater is operating. Push the switch once again to turn off the seat heater. ■ The seat heaters can be used when Vehicles with smart key system The “ENGINE START STOP”...
  • Page 293 3-6. Other interior features NOTICE ■ To prevent seat heater damage Do not put unevenly weighted objects on the seat and do not stick sharp objects (needles, nails, etc.) into the seat. ■ To prevent battery discharge Turn the switches off when the engine is not running. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 294 3-6. Other interior features ∗ Armrest Pull the armrest down for use. NOTICE ■ To prevent damage to the armrest Do not place too much strain on the armrest. ∗ : If equipped I n f o r ma t i o n P r o v i d e d b y :...
  • Page 295 When installing the driver's floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver's seat. ●...
  • Page 296 3-6. Other interior features Trunk features ■ Storage box ■ Cargo hooks (if equipped) Cargo hooks are provided for securing loose items. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 297 3-6. Other interior features ∗ Compass The compass on the inside rear view mirror indicates the direction in which the vehicle is heading. ■ Operation To turn the compass on or off, press and hold “AUTO” for 3 seconds. ■ Displays and directions Display Direction...
  • Page 298 3-6. Other interior features Calibrating the compass The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in the illustration, the compass will deviate.
  • Page 299 3-6. Other interior features ■ Circling calibration Stop the vehicle in a place where it is safe to drive in a circle. STEP Press and hold “AUTO” for 9 STEP seconds. C appears on the compass dis- play. Drive the vehicle at 5 mph (8 STEP km/h) or less in a circle until a direction is displayed.
  • Page 300 3-6. Other interior features CAUTION ■ While driving the vehicle Do not adjust the display. Be sure to adjust the display only when the vehicle is stopped. ■ When doing the circling calibration Be sure to secure a wide space, and watch out for people and vehicles in the neighborhood.
  • Page 301 4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
  • Page 302 4-1. Maintenance and care ■ To prevent deterioration and body corrosion ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads • If you see coal tar or tree sap on the paint surface •...
  • Page 303 4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle's interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
  • Page 304 4-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle's interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
  • Page 305 4-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use organic substances such as benzene or gasoline, acidic or alkaline solutions, dye, bleach or other detergent. Doing so may discolor the vehicle interior or cause streaks or damage to painted surfaces. ●...
  • Page 306 It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than a Toyota dealer performs repairs, confirm the war- ranty coverage.
  • Page 307 4-2. Maintenance ■ Allow inspection and repairs to be performed by a Toyota dealer ● Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.

  • Page 308: Engine Compartment

    Booklet” “Owner’s Manual Supplement/Scheduled Maintenance Guide”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items Check points Check the connections. Battery (→P.

  • Page 309: Vehicle Interior

    4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be held securely Automatic transmission “Park” on an incline with the shift lever in mechanism • Moves smoothly? •...

  • Page 310: Vehicle Exterior

    4-2. Maintenance Vehicle exterior Items Check points Doors/trunk • Operate smoothly? Engine hood • The lock system works properly? • Is there any leakage after park- Fluid leaks ing? • Inflation pressure is correct? • Tire surfaces not worn or dam- aged? Tires •...
  • Page 311 If the malfunction indicator lamp comes on The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. ■...
  • Page 312 Brake fluid level (→P. 321) • Rag or paper towel • Funnel (used only for adding brake fluid) • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
  • Page 313 4-3. Do-it-yourself maintenance Items Parts and tools • Fuse with same amperage rating Fuses (→P. 350) as original Radiator and condenser ⎯ (→P. 321) • Tire pressure gauge Tire inflation pressure (→P. 337) • Compressed air source • Water washer fluid containing Washer fluid (→P.
  • Page 314 4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing, and tools away from the moving fan and engine drive belt.
  • Page 315 4-3. Do-it-yourself maintenance NOTICE ■ If you remove the air cleaner Driving with the air cleaner removed may cause excessive engine wear due to dirt in the air. Also, a backfire could cause a fire in the engine compart- ment. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 316 4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood release lever. STEP The hood will pop up slightly. Lift the auxiliary catch lever STEP and lift the hood. Hold the hood open by insert- STEP ing the supporting rod into the slot.
  • Page 317 4-3. Do-it-yourself maintenance CAUTION ■ Pre-driving check Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. ■...
  • Page 318 4-3. Do-it-yourself maintenance Positioning a floor jack When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury. ■ Front 1.8 L 4-cylinder (2ZR-FE) engine 2.4 L 4-cylinder (2AZ-FE) engine ■...
  • Page 319 4-3. Do-it-yourself maintenance Set the jack attachment on the STEP floor jack with the “FOR- WARD” facing towards the front of the vehicle, and place the jack. Front of vehicle Before raising the vehicle, STEP make sure that the floor jack is positioned so that the jack point fits securely inside the groove on the jack attach-...
  • Page 320 4-3. Do-it-yourself maintenance CAUTION ■ When raising your vehicle Make sure to observe the following to reduce the possibility of death or seri- ous injury. ● Lift up the vehicle using a floor jack such as the one shown in the illustra- tion.
  • Page 321 4-3. Do-it-yourself maintenance Engine compartment 1.8 L 4-cylinder (2ZR-FE) engine Engine coolant reservoir Battery (→P. 324) (→P. 320) Radiator (→P. 321) Engine oil filler cap Electric cooling fan (→P. 317) Condenser (→P. 321) Brake fluid reservoir Engine oil level dipstick (→P.
  • Page 322 4-3. Do-it-yourself maintenance 2.4 L 4-cylinder (2AZ-FE) engine Engine coolant reservoir Fuse box (→P. 350) (→P. 320) Battery (→P. 324) Engine oil filler cap Radiator (→P. 321) (→P. 317) Electric cooling fans Engine oil level dipstick Condenser (→P. 321) (→P. 316) Washer fluid tank (→P.
  • Page 323 4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After turning off the engine, STEP wait more than five minutes for the oil to drain back into the bottom of the engine.
  • Page 324 4-3. Do-it-yourself maintenance 2.4 L 4-cylinder (2AZ-FE) engine Full ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
  • Page 325 1000 km) ● If you consume more than 1.1 qt. (1.0 L, 0.9 lmp. qt.) every 600 miles (1000 km), contact your Toyota dealer. ■ After changing the engine oil (U.S.A. only) The engine oil maintenance data should be reset. Perform the following pro-...
  • Page 326 Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.

  • Page 327: Engine Coolant

    If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, coolant reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. ■...
  • Page 328 Radiator and condenser Check the radiator and condenser and remove any foreign objects. If any of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION ■...
  • Page 329 4-3. Do-it-yourself maintenance ■ Adding fluid Make sure to check the fluid type and prepare the necessary items. Fluid type FMVSS No.116 DOT 3 or SAE J1703 brake fluid Items Clean funnel Disconnect the claws to remove STEP the service cover as shown in the illustration.
  • Page 330 4-3. Do-it-yourself maintenance CAUTION ■ When filling the reservoir Take care because brake fluid can harm your hands or eyes and damage painted surfaces. If fluid gets in your eyes, flush your eyes with clean water immediately. If you still experience discomfort, see a doctor. NOTICE ■...
  • Page 331 Type A Blue: Good condition White: Charging is necessary. Have the vehicle inspected by your Toyota dealer. Red: Not working properly. Have the vehicle checked by your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 332 4-3. Do-it-yourself maintenance Type B Green: Good condition Dark: Charging is necessary. Have the vehicle inspected by your Toyota dealer. Clear or light yellow: Not working properly. Have the vehicle checked your Toyota dealer. ■ Before recharging When recharging, the battery produces hydrogen gas which is flammable and explosive.
  • Page 333 4-3. Do-it-yourself maintenance CAUTION ■ Chemicals in the battery A battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the battery: ●...
  • Page 334 4-3. Do-it-yourself maintenance NOTICE ■ When recharging the battery Never recharge the battery while the engine is running. Also, be sure all accessories are turned off. Washer fluid For vehicles sold in U.S.A. Check the washer fluid level on the level gauge. If the washer fluid level is at “LOW”, add washer fluid.
  • Page 335 4-3. Do-it-yourself maintenance NOTICE ■ Do not use any fluid other than washer fluid Do not use soapy water or engine antifreeze instead of washer fluid. Doing so may cause streaking on the vehicle’s painted surfaces. ■ Diluting washer fluid Dilute washer fluid with water as necessary.
  • Page 336 ■ The tire pressure warning system (if equipped) Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (→P. 384) The compact spare tire is not equipped with the tire pressure warning valve and transmitters.
  • Page 337 Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (→P. 331) Initializing the tire pressure warning system The tire pressure warning system must be initialized when changing the tire size.
  • Page 338 ID code of tire pressure warning valve and transmitter. Have the ID code registered by your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 339 ● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
  • Page 340 4-3. Do-it-yourself maintenance ■ Low profile tires (vehicles with 17-inch tires) Generally, low profile tires will wear more rapidly and tire grip perfor- mance will be reduced on snowy and/or icy roads when compared to standard tires. Be sure to use snow tires or tire chains on snowy and/or icy roads and drive carefully at a speed appropriate for road and weather conditions.
  • Page 341 Initialization can be completed in a few minutes. However, in the follow- ing cases, the settings have not been recorded and the system will not operate properly. If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ●...
  • Page 342 Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
  • Page 343 ● When removing or fitting the wheels, tires or the tire pressure warning valves and transmitters, contact your Toyota dealer as the tire pres- sure warning valves and transmitters may be damaged if not handled correctly.
  • Page 344 4-3. Do-it-yourself maintenance Tire inflation pressure ■ Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (→P. 434) Type A Type B I n f o r ma t i o n P r o v i d e d b y :...
  • Page 345 4-3. Do-it-yourself maintenance Type C Type D I n f o r ma t i o n P r o v i d e d b y :...
  • Page 346 4-3. Do-it-yourself maintenance ■ Inspection and adjustment procedure Tire valve Tire pressure gauge Remove the tire valve cap. STEP Press the tip of the tire pressure gauge onto the tire valve. STEP Read the pressure using the graduations of the gauge. STEP If the tire inflation pressure is not at the recommended level STEP...
  • Page 347 Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
  • Page 348 4-3. Do-it-yourself maintenance CAUTION ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. ● Excessive wear ● Uneven wear ●...
  • Page 349 ● Bent wheels that have been straightened ■ Aluminum wheel precautions ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
  • Page 350 4-3. Do-it-yourself maintenance ■ When replacing wheels The wheels of your Toyota, except for the compact spare tire, are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure.
  • Page 351 4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. ■ Removal method Vehicles with smart key system: Turn the “ENGINE START STEP STOP” switch OFF. Vehicles without smart key system: Turn the engine switch OFF.
  • Page 352 4-3. Do-it-yourself maintenance ■ Replacement method Remove the air conditioning filter and replace it with a new one. The “↑UP” marks shown on the filter should be pointing up. ■ Checking interval Replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required.
  • Page 353 4-3. Do-it-yourself maintenance Key battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Flathead screwdriver (To prevent damage to the key, cover the tip of the screwdriver with a rag.) ●...
  • Page 354 4-3. Do-it-yourself maintenance Remove the depleted battery. STEP Insert a new battery with the “+” terminal facing up. ■ Replacing the battery (vehicles without smart key system) Remove the cover. STEP Remove the module. STEP I n f o r ma t i o n P r o v i d e d b y :...
  • Page 355 4-3. Do-it-yourself maintenance Type A Open the case cover using a STEP flathead screwdriver pro- tected with tape etc. and remove the depleted battery. Insert a new battery (CR2025) with the “+” terminal facing up. Type B Open the case cover using a STEP coin protected with tape etc.
  • Page 356 Vehicles with smart key system: CR1632 Vehicles without smart key system: CR2025 (Type A), CR2016 (Type B) ● Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. ● Replace only with the same or equivalent type recommended by your Toyota dealer.
  • Page 357 4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Vehicles with smart key system: Turn the “ENGINE START STEP STOP”...
  • Page 358 4-3. Do-it-yourself maintenance Driver’s side instrument panel Remove the instrument panel. After a system failure, see “Fuse layout and amperage rat- STEP ings” (→P. 354) for details about which fuse to check. Take out the pullout tool. STEP Only type A fuse can be removed using the pullout tool.
  • Page 359 4-3. Do-it-yourself maintenance Check if the fuse has blown. STEP Type A Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type B Normal fuse Blown fuse Replace it with one of an appropriate amperage rating.
  • Page 360 4-3. Do-it-yourself maintenance Type C Normal fuse Blown fuse Contact your Toyota dealer. Type D Normal fuse Blown fuse Contact your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 361 4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment Fuse Ampere Circuit CDS FAN 30 A Electric cooling fan(s) RDI FAN 40 A Electric cooling fan(s) Anti-lock brake system, vehicle sta- ABS NO. 3 30 A bility control system Anti-lock brake system, vehicle sta- ABS NO.
  • Page 362 4-3. Do-it-yourself maintenance Fuse Ampere Circuit GLOW* 80 A No circuit 50 A EFI MAIN, HORN, IG2 H-LP LH LO, H-LP RH LO, H-LP H-LP MAIN 50 A LH HI, H-LP RH HI EFI NO. 2 10 A Emission control system Multiport fuel injection system/ EFI NO.
  • Page 363 4-3. Do-it-yourself maintenance Fuse Ampere Circuit MAYDAY* 10 A No circuit SPARE 10 A Spare fuse SPARE 30 A Spare fuse SPARE 20 A Spare fuse Multiport fuel injection system/ EFI MAIN 20 A sequential multiport fuel injection system, EFI NO. 1, EFI NO. 2 HORN 10 A Horn...
  • Page 364 4-3. Do-it-yourself maintenance ■ Under the driver’s side instrument panel Fuse Ampere Circuit 40 A Rear window defogger, MIR HTR PWR SEAT 30 A Power seat Parking lights, tail lights, license plate lights, front side marker lights, TAIL 10 A multiport fuel injection system/ sequential multiport fuel injection system, instrument cluster lights...
  • Page 365 4-3. Do-it-yourself maintenance Fuse Ampere Circuit POWER 30 A Power windows SEAT HTR 15 A Seat heater HTR-IG 10 A Air conditioning system WIPER 25 A Windshield wipers WASHER 15 A Windshield washer Automatic transmission, main body ECU, electric power steering, elec- tric cooling fan(s), shift lock control ECU-IG NO.
  • Page 366 Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. ● Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix. This can cause extensive damage or even fire.
  • Page 367 You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
  • Page 368 4-3. Do-it-yourself maintenance ■ Rear bulb locations Rear turn signal lights Stop/tail and rear side marker lights Back-up lights License plate lights I n f o r ma t i o n P r o v i d e d b y :...
  • Page 369 4-3. Do-it-yourself maintenance Replacing light bulbs ■ Headlight low beams Turn the bulb base counterclock- STEP wise. Unplug the bulb while depress- STEP ing the lock release. ■ Headlight high beams and daytime running lights Turn the bulb base counterclock- STEP wise.
  • Page 370 4-3. Do-it-yourself maintenance Unplug the bulb while depress- STEP ing the lock release. ■ Front fog lights (if equipped) Remove the fender liner bolts STEP and clip. Partly remove the fender liner. STEP Turn the bulb base counterclock- STEP wise. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 371 4-3. Do-it-yourself maintenance Unplug the bulb while depress- STEP ing the lock release. ■ Front turn signal/parking lights and front side marker lights Turn the steering wheel away from the side being worked on. STEP This will move the tire to provide more room. Remove the fender liner clips.
  • Page 372 4-3. Do-it-yourself maintenance Partly remove the fender liner STEP and turn the bulb base counter- clockwise. Front side marker light Front turn signal/parking light Remove the light bulb. STEP Front side marker light Front turn signal/parking light I n f o r ma t i o n P r o v i d e d b y :...
  • Page 373 4-3. Do-it-yourself maintenance ■ Stop/tail and rear side marker lights, and rear turn signal lights Open the trunk lid. STEP Remove the luggage trim cover STEP clips. Partly remove the luggage trim cover. Type A Turn the bulb base counterclock- STEP wise.
  • Page 374 4-3. Do-it-yourself maintenance Type B Turn the bulb base counterclock- STEP wise. Stop/tail and rear side marker light Rear turn signal light Remove the light bulb. STEP Stop/tail and rear side marker light Rear turn signal light ■ Back-up light Open the trunk lid and remove STEP the cover.
  • Page 375 4-3. Do-it-yourself maintenance Remove the light bulb. STEP ■ License plate lights Open the trunk lid and remove STEP the trunk panel cover clips. Partly remove the trunk panel STEP cover and turn the bulb base counterclockwise. Remove the light bulb. STEP I n f o r ma t i o n P r o v i d e d b y :...
  • Page 376 ■ LED high mounted stoplight The high mounted stoplight consists of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. ■ Condensation build-up on the inside of the lens Contact your Toyota dealer for more information in the following situations.
  • Page 377 4-3. Do-it-yourself maintenance I n f o r ma t i o n P r o v i d e d b y :...
  • Page 378 5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE ■ To prevent battery discharge Do not leave the emergency flashers on longer than necessary when the engine is not running.
  • Page 379 If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
  • Page 380 5-1. Essential information Emergency towing If a tow truck is not available, in an emergency your vehicle may be temporarily towed using a cable or chain secured to the emergency towing eyelet. This should only be attempted on hard surfaced roads for short distances at low speeds.
  • Page 381 5-1. Essential information ■ Emergency towing procedure STEP Release the parking brake. STEP Shift the shift lever to N. STEP Vehicles with smart key system Turn the “ENGINE START STOP” switch to ACCESSORY (engine off) or IGNITION ON (engine running) mode. Vehicles without smart key system Turn the engine switch to the “ACC”...
  • Page 382 5-1. Essential information Towing with a sling-type truck NOTICE ■ To prevent body damage Do not tow with a sling-type truck, either from the front or rear. Towing with a wheel-lift type truck from the front Release the parking brake. NOTICE ■...
  • Page 383 5-1. Essential information Towing with a wheel-lift type truck from the rear Automatic transmission: Use a towing dolly under the front wheels. Manual transmission: We recom- mend to use a towing dolly under the front wheels. When not using a towing dolly, turn the engine switch to the “ACC”...
  • Page 384 5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
  • Page 385 Do not restart the engine. Have the vehi- cle checked and repaired by your Toyota dealer. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 386 5-1. Essential information Event data recorder Your vehicle has computers that monitor and control certain aspects of your vehicle. These computers assist in driving and maintaining optimal vehicle performance. Besides storing data useful for troubleshooting, there is an event data recorder (EDR) that records data in a crash or a near car crash event.
  • Page 387 5-1. Essential information Disclosure of the data Toyota will not disclose the data recorded in an EDR to a third party except when: ● An agreement from the vehicle's owner (or the leasing company for a leased vehicle) is obtained ●...
  • Page 388 Stop the vehicle immediately. The following warning indicates the possibility of damage to the vehi- cle that may lead to an accident. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Charging system warning light Indicates a malfunction in the vehicle’s charging system.
  • Page 389 Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: (U.S.A.)
  • Page 390 The malfunction indicator lamp will go off after taking several driving trips. If the malfunction indicator lamp does not go off even after several trips, con- tact your Toyota dealer as soon as possible. Follow the correction procedures. After taking the specified steps to correct the suspected problem, check that the warning light turns off.
  • Page 391 1 minute: Have the system checked Malfunction in the tire by your Toyota dealer. pressure warning system. *: Driver's and front passenger’s seat belt warning buzzers: The driver’s and front passenger’s seat belts warning buzzers sound to alert the driver and front passenger that his or her seat belt is not fastened.
  • Page 392 5-2. Steps to take in an emergency ■ Front passenger detection sensor and passenger seat belt reminder ● If luggage is placed on the front passenger seat, the front passenger detection sensor may cause the warning light to flash, even if a passen- ger is not sitting in the seat.
  • Page 393 If there is a lot of snow or ice on the vehicle, in particular around the wheels or wheel housings. ● If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
  • Page 394 If the tire pressure warning light comes on after blinking for 1 minute fre- quently when the “ENGINE START STOP” switch or engine switch is turned ON, have it checked by your Toyota dealer. ■ Customization that can be configured at Toyota dealer The vehicle speed linked seat belt reminder buzzer can be disabled.
  • Page 395 5-2. Steps to take in an emergency CAUTION ■ Maintenance of the tires Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label (tire and load information label).
  • Page 396 5-2. Steps to take in an emergency CAUTION Your vehicle has also been equipped with a TPMS (tire pressure warning system) malfunction indicator to indicate when the system is not operat- ing properly. The TPMS (tire pressure warning system) malfunction indi- cator is combined with the low tire pressure telltale (tire pressure warning light).
  • Page 397 5-2. Steps to take in an emergency Follow the correction procedures. (vehicles with smart key system) After taking the specified steps to correct the suspected problem, check that the warning light turns off. Interior Exterior Warning Correction Warning light/Details light procedure buzzer buzzer...
  • Page 398 5-2. Steps to take in an emergency Warning Correction Interior Exterior Warning light/Details light procedure buzzer buzzer Smart key system warning light • Shift the shift Indicates that the driver’s door lever to P. has been opened or closed • Confirm the Conti n uous Continuous with the shift lever not in P, the...
  • Page 399 5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ●...
  • Page 400 5-2. Steps to take in an emergency Taking out the jack Remove the luggage floor cover. STEP Tighten STEP Loosen I n f o r ma t i o n P r o v i d e d b y :...
  • Page 401 5-2. Steps to take in an emergency Taking out the spare tire Remove the luggage floor cover. STEP Remove the tool tray. STEP Loosen the center fastener that STEP secures the spare tire. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 402 5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. STEP Wheel Flat tire chock positions Behind the Left- rear right- hand hand side side tire Front Behind the Right- rear left- hand hand side side tire In front of Left-...
  • Page 403 5-2. Steps to take in an emergency Slightly loosen the wheel nuts STEP (one turn). Turn the tire jack portion “A” by STEP hand until the notch of the jack is in contact with the jack point. The jack point guides are located under the rocker panel.
  • Page 404 5-2. Steps to take in an emergency Raise the vehicle until the tire is STEP slightly raised off the ground. Remove all the wheel nuts and STEP the tire. When resting the tire on the ground, place the tire so that the wheel design faces up to avoid scratching the wheel surface.
  • Page 405 5-2. Steps to take in an emergency Install the tire and loosely tighten each wheel nut by hand by STEP approximately the same amount. Replacing a steel wheel with a compact spare tire Tighten the nuts until the tapered Tapered portion portion comes into loose contact with the disc wheel seat.
  • Page 406 5-2. Steps to take in an emergency Firmly tighten each nut two or STEP three times in the order shown in the illustration. Tightening torque: 76 ft•lbf (103 N•m, 10.5 kgf•m) Stow the flat tire, tire jack and all tools. STEP ■...
  • Page 407 5-2. Steps to take in an emergency CAUTION ■ Using the tire jack Improper use of the tire jack may lead to death or serious injuries due to the vehicle suddenly falling off the jack. ● Do not use the tire jack for any purpose other than replacing tires or installing and removing tire chains.
  • Page 408 5-2. Steps to take in an emergency CAUTION ■ Replacing a flat tire Observe the following precautions to reduce the risk of death or serious injury: ● Never use oil or grease on the wheel bolts or wheel nuts. Oil and grease may cause the wheel nuts to be excessively tightened, leading to bolt or disc wheel damage.
  • Page 409 ■ When replacing the tires When removing or fitting the wheels, tires or the tire pressure warning valve and transmitter, contact your Toyota dealer as the tire pressure warning valve and transmitter may be damaged if not handled correctly. ■...
  • Page 410 5-2. Steps to take in an emergency If the engine will not start If the engine still does not start after following the correct starting procedure (→P. 126, 130) or releasing the steering lock (→P. 128, 132), confirm the following points. ■...
  • Page 411 ● There may be a malfunction in the steering lock system (vehi- cles with smart key system). Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function (vehicles with smart key system) When the engine does not start, the following steps can be used as an interim measure to start the engine if the “ENGINE START STOP”...
  • Page 412 (a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
  • Page 413 5-2. Steps to take in an emergency If you lose your keys New genuine keys can be made by your Toyota dealer. For vehicles with the smart key system, bring the other key and the key number stamped on the key number plate. For vehicles without the smart key system, bring a master key and the key number stamped on the key number plate.
  • Page 414 5-2. Steps to take in an emergency If the electronic key does not operate properly (vehicles with smart key system) If communication between the electronic key and the vehicle is inter- rupted (→P. 27) or the electronic key cannot be used because the battery is depleted, the smart key system and wireless remote con- trol cannot be used.
  • Page 415 5-2. Steps to take in an emergency Changing “ENGINE START STOP” switch modes and starting the engine Shift the shift lever to P and apply the brakes. STEP Touch the Toyota emblem side of STEP electronic “ENGINE START STOP” switch.
  • Page 416 You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your Toyota following the steps below. 1.8 L 4-cylinder (2ZR-FE) engine Remove the engine cover.
  • Page 417 5-2. Steps to take in an emergency STEP Connecting the jumper cables Positive (+) battery terminal on your vehicle Positive (+) battery terminal on the second vehicle Negative (-) battery terminal on the second vehicle Connect the jumper cable to ground on your vehicle as shown in the illustration.
  • Page 418 Once the vehicle’s engine has started, remove the jumper STEP cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. 2.4 L 4-cylinder (2AZ-FE) engine STEP...
  • Page 419 Once the vehicle’s engine has started, remove the jumper STEP cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. ■ Avoiding a discharged battery ●...
  • Page 420 5-2. Steps to take in an emergency CAUTION ■ Avoiding battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery. ● Make sure the jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any part other than the intended termi- nal.
  • Page 421 5-2. Steps to take in an emergency NOTICE ■ To prevent damage to the vehicle Do not pull- or push-start the vehicle, because the catalytic converter may overheat and become a fire hazard. ■ When handling jumper cables Be careful that the jumper cables do not become tangled in the cooling fans or any of the belts when connecting or disconnecting them.
  • Page 422 Wait until the temperature of the engine (shown on the instrument cluster) begins to fall and then stop the engine. If the fans are not operating: Stop the engine and call your Toyota dealer. After the engine has cooled STEP STEP...
  • Page 423 Water can be used in an emer- gency if engine coolant is (→ unavailable. P. 431 Have the vehicle checked at the nearest Toyota dealer as soon as possible. ■ Overheating If you observe the following, your vehicle may be overheating.
  • Page 424 5-2. Steps to take in an emergency NOTICE ■ When adding engine coolant Wait until the engine has cooled down before adding engine coolant. When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly can cause damage to the engine. I n f o r ma t i o n P r o v i d e d b y :...
  • Page 425 5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the engine. Set the parking brake and put the shift STEP lever in P (automatic transmission) or N (manual transmis- sion).
  • Page 426 5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: Steadily step on the brake pedal with both feet and firmly STEP...
  • Page 427 5-2. Steps to take in an emergency Vehicles with a smart key sys- STEP tem: Stop the engine by press- ing and holding the “ENGINE START STOP” switch for 3 consecutive seconds or more. Press and hold for 3 seconds or more Stop the vehicle in a safe place by the road.
  • Page 428 5-2. Steps to take in an emergency I n f o r ma t i o n P r o v i d e d b y :...
  • Page 429 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
  • Page 430 6-1. Specifications Type A On some models, this number is stamped under the front passen- ger seat. Type B On some models, this number is stamped under the front passen- ger seat. This number is also on the certifi- cation label on the driver’s side center pillar.
  • Page 431 6-1. Specifications ■ Engine number The engine number is stamped on the engine block as shown. 1.8 L 4-cylinder (2ZR-FE) engine 2.4 L 4-cylinder (2AZ-FE) engine I n f o r ma t i o n P r o v i d e d b y :...
  • Page 432 6-1. Specifications Engine 1.8 L 4-cylinder (2ZR-FE) engine Model 2ZR-FE engine 4 cylinder in line, Type 4 cycle, gasoline 3.17 × 3.48 in. Bore and stroke (80.5 × 88.3 mm) Displacement 109.7 cu.in. (1798 cm Drive belt tension* 143 ± 22 lb. Valve clearance (engine cold) Intake Automatic adjustment...
  • Page 433 6-1. Specifications 2.4 L 4-cylinder (2AZ-FE) engine Model 2AZ-FE engine 4 cylinder in line, Type 4 cycle, gasoline 3.48 × 3.78 in. Bore and stroke (88.5 × 96.0 mm) Displacement 144.1 cu.in. (2362 cm Drive belt tension Automatic adjustment Valve clearance (engine cold) 0.007 ⎯...

  • Page 434: Lubrication System

    3.8 qt. (3.6 L, 3.2 Imp. qt.) ■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC multigrade engine oil...
  • Page 435 6-1. Specifications How to read oil container label: The ILSAC (International Lubricant Standardization and Approval Committee) Certification Mark is added to some oil containers to help you select the oil you should use. I n f o r ma t i o n P r o v i d e d b y :...

  • Page 436: Cooling System

    (reference) 2.4 L 4-cylinder (2AZ-FE) engine 6.0 qt. (5.7 L, 5.0 Imp. qt.) Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based non-silicate, Coolant type non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.

  • Page 437: Electrical System

    Fluid capacity (reference) 2.4 L 4-cylinder (2AZ-FE) engine 8.2 qt. (7.8 L, 6.9 Imp. qt.) Fluid type Toyota Genuine ATF WS I n f o r ma t i o n P r o v i d e d b y :...
  • Page 438 6-1. Specifications NOTICE ■ Automatic transmission fluid type Using automatic transmission fluid other than “Toyota Genuine ATF WS” may cause deterioration in shift quality, locking up of your transmission accompanied by vibration, and ultimately damage the transmission of your vehicle.
  • Page 439 6-1. Specifications Steering Free play Less than 1.2 in. (30 mm) Tires and wheels Type A Tire size P195/65R15 89S, T135/70R16 100M Tire inflation pressure Front: 30 psi (210 kPa, 2.1 kgf/cm or bar) (Recommended cold tire Rear: 30 psi (210 kPa, 2.1 kgf/cm or bar) inflation pressure) Spare: 60 psi (420 kPa, 4.2 kgf/cm...
  • Page 440 6-1. Specifications Type C Tire size P205/55R16 89H, T135/70R16 100M Tire inflation pressure Front: 32 psi (220 kPa, 2.2 kgf/cm or bar) (Recommended cold tire Rear: 32 psi (220 kPa, 2.2 kgf/cm or bar) inflation pressure) Spare: 60 psi (420 kPa, 4.2 kgf/cm or bar) 16 ×...

  • Page 441: Light Bulbs

    6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights Low beam 9006 High beam 9005 Front side marker ⎯ lights Front turn signal/park- 3457NA 27/8 ing lights Front fog lights ⎯ (if equipped) Exterior Rear turn signal lights ⎯ (Type A) Rear turn signal lights 3156...
  • Page 442 ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. ■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. ■...
  • Page 443 Toyota allows the use of oxygenate blended gasoline where the oxygen- ate content is up to 10% ethanol or 15% MTBE. ● If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 87. ●...
  • Page 444 6-1. Specifications NOTICE ■ Notice on fuel quality ● Do not use improper fuels. If improper fuels are used the engine will be damaged. ● Do not use leaded gasoline. Leaded gasoline can cause damage to your vehicle’s catalytic converters causing the emission control system to malfunction.
  • Page 445 6-1. Specifications Tire information Typical tire symbols Full-size tire Compact spare tire Tire size (→P. 443) DOT and Tire Identification Number (TIN) (→P. 442) Uniform tire quality grading For details, see “Uniform Tire Quality Grading” that follows. Location of treadwear indicators (→P.
  • Page 446 6-1. Specifications Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire. Radial tires or bias-ply tires A radial tire has “RADIAL” on the sidewall. A tire not marked “RADIAL”...
  • Page 447 6-1. Specifications Typical DOT and Tire Identification Number (TIN) DOT symbol Tire Identification Number (TIN) Tire manufacturer's identifica- tion mark Tire size code Manufacturer's optional tire type code (3 or 4 letters) Manufacturing week Manufacturing year : The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
  • Page 448 6-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 or 3 digits) Speed symbol...
  • Page 449 U.S.A. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
  • Page 450 6-1. Specifications ■ Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a speci- fied government test course. For example, a tire graded 150 would wear one and a half (1-1/2) times as well on the government course as a tire graded 100.
  • Page 451 6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either sepa- rately or in combination, can cause heat buildup and possible tire fail- ure.
  • Page 452 6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as speci- Occupant distribution fied in the third column of Table 1 below The combined weight of installed regular pro- duction options weighing over 5 lb.
  • Page 453 6-1. Specifications Tire related term Meaning The surface area of the rim not covered by the Weather side inflated tire The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components Bead separation...
  • Page 454 6-1. Specifications Tire related term Meaning The parting of the innerliner from cord material Innerliner separation in the carcass (a) The sidewall that contains a whitewall, bears white lettering, or bears manufac- turer, brand, and/or model name molding that is higher or deeper than the same Intended outboard molding on the other sidewall of the tire, or sidewall...
  • Page 455 6-1. Specifications Tire related term Meaning A layer of rubber-coated parallel cords A parting of rubber compound between adja- Ply separation cent plies A mechanical device made of rubber, chemi- cals, fabric and steel or other materials, that, Pneumatic tire when mounted on an automotive wheel, pro- vides the traction and contains the gas or fluid that sustains the load...
  • Page 456 6-1. Specifications Tire related term Meaning That portion of a tire that comes into contact Tread with the road A tread section running circumferentially Tread rib around a tire Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear indicators designed to give a visual indication of the...
  • Page 457 Your vehicle includes a variety of electronic features that can be per- sonalized to your preferences. Programming these preferences requires specialized equipment and may be performed by your Toyota dealer. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer. Customized Item Function Default setting...
  • Page 458 6-2. Customization Customized Item Function Default setting setting Wireless remote control Driver's door unlocked in one All doors Unlocking operation step, all doors unlocked in one unlocked in two step steps Automatic door lock function to be activated if door is not opened after being unlocked Time elapsed before 30 seconds...
  • Page 459 6-2. Customization Customized Item Function Default setting setting Driver's door unlocked in one All doors Unlocking using a key step, all doors unlocked in one unlocked in two step steps Speed-detecting auto- matic door lock function (vehicles with smart key Door lock system) (vehicles...
  • Page 460 6-2. Customization Customized Item Function Default setting setting Time elapsed before 7.5 seconds lights turn off (vehicles 15 seconds with power door lock 30 seconds system) Operation when the doors are unlocked (vehicles with power door lock system) Illumination Vehicles with smart key →...
  • Page 461 6-3. Initialization Items to initialize The following items must be initialized for normal system operation in cases such as after maintenance is performed on the vehicle. Item When to initialize Reference Engine oil mainte- nance data After changing engine oil P.
  • Page 462 If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
  • Page 463 Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation correcte des ceintures de sécurité...
  • Page 464 Guide de confort de ceinture de sécurité (sièges arrière extérieurs) Si la sangle diagonale gêne la personne au niveau du cou, utilisez le guide confort de la ceinture de sécurité. Sortez le guide confort de sa ÉTAPE poche. Engagez la ceinture dans le ÉTAPE guide.
  • Page 465 Entretien et soin ■ Ceintures de sécurité Nettoyez avec un chiffon ou une éponge humectée d'eau savonneuse tiède. Profitez l'occasion pour vérifier régulièrement que les ceintures ne sont pas effilochées, entaillées, ou ne paraissent pas exagérément usées. ATTENTION ■ Détérioration et usure des ceintures de sécurité Inspectez les ceintures de sécurité...
  • Page 466 I n f o r ma t i o n P r o v i d e d b y :...
  • Page 467 What to do if... What to do if... If you have a flat tire A tire punctures P. 393 P. 404 If the engine will not start P. 77 Engine immobilizer system The engine does not start P. 410 If the battery is discharged If the electronic key does not oper- P.
  • Page 468 What to do if... Optitron type meters Non-Optitron type meters I n f o r ma t i o n P r o v i d e d b y :...
  • Page 469 What to do if... ■Warning lights Brake system warning Tire pressure warning light light P. 384 Low windshield washer fluid level warning light P. 382 P. 384 Electric power steering Charging system warn- warning light ing light P. 382 P. 383 Low engine oil pressure Open door warning light warning light...

  • Page 470: Gas Station Information

    GAS STATION INFORMATION Auxiliary catch lever Trunk opener Fuel filler door P. 309 P. 44 P. 73 Hood lock release lever Fuel filler door opener Tire inflation pressure P. 309 P. 73 P. 434 Fuel tank capacity 13.2 gal. (50 L, 10.9 Imp. gal.) (Reference) Fuel type Unleaded gasoline only...

Table of Contents

Save PDF
