Relay to Modem connection. Direct/through cable, no crossing.
OT
DB-9
MALE
Relay to computer connection (standard null modem)
It is recommended to use a direct cable with an standard Null Modem connector at one end.
DB-9
MALE
GEK-106166E
FIGURES
Figure 8. RS-232 Connection
DFF Digital Feeder Relay
DB-9
MALE
DO NOT CONNECT THE
NOTE :
SHIELD
DB-9
FEMALE
DO NOT CONNECT THE
NOTE :
SHIELD
67
