SWIMMING POOL PUMP
Sta-Rite Pool/Spa Group
600 S. Jefferson Street, Waterford, WI 53185
North America: 800-752-0183, FAX 800-582-2217
International: 414-728-5551, FAX: 414-728-4461, TELEX: ITT 4970245
Oxnard, CA • Orlando, FL • Union City, TN • Delavan, WI • Mississauga, Ont
© 1995, Sta-Rite Industries, Inc. Printed in U.S.A.
O W
N E R '
INSTALLATION, OPERATION & PARTS
MODELS
3/4 HP
JWPD-075
JWPE-100
S
M
A
N U A
1 HP
1-1/2 HP
JWPF-150
L
This manual should be furnished to
the end user of this pump; its use will
reduce service calls and chance of
injury and will lengthen pump life.
S331 (Rev. 4/18/95)
Advertisement
Table of Contents
Related Manuals for STA-RITE JWPD-075
Summary of Contents for STA-RITE JWPD-075
- Page 1 600 S. Jefferson Street, Waterford, WI 53185 North America: 800-752-0183, FAX 800-582-2217 International: 414-728-5551, FAX: 414-728-4461, TELEX: ITT 4970245 Oxnard, CA • Orlando, FL • Union City, TN • Delavan, WI • Mississauga, Ont © 1995, Sta-Rite Industries, Inc. Printed in U.S.A. S331 (Rev. 4/18/95)
-
Page 2: Table Of Contents
Internal filter components and valves are warranted for a period of one (1) year from date of installation. The foregoing warranties relate to the original consumer purchaser (“Purchaser”) only. Sta-Rite shall have the op- tion to repair or replace the defective product, at its sole discretion. Purchasers must pay all labor and shipping charges necessary to replace the product covered by this warranty. -
Page 3: Safety Instructions
• Check all clamps, bolts, lids, and system accessories before testing. • Release all air in system before testing. • Tighten Sta-Rite trap lids to 30 ft. lbs. (4.1 kg-m) torque for testing. • Water pressure for test must be less than 25 PSI (7.5 kg/cm •... -
Page 4: Specifications/Dimensions
Model Motor Voltage/ Full Load Circuit Breaker Dist. in Ft. (M)-Service Motor Temp. H.P. Hz/Phase Amps Rating (amps) Rating-°C 0-100’ (0-30) 101-200’ (31-60) 201-300’ (61-90) JWPD-075 115/60/1 JWPE-100 115/230/60/1 12.0/6.0 14/14 10/14 8/14 JWPF-150 1-1/2 115/230/60/1 16.0/8.0 20/15 12/14 8/14... -
Page 5: Installation
Strainer Basket Cover " NPT Discharge Port " NPT Suction Port Return Line To Pool 764 0294 Skimmer Drain Plug Figure 2 Pool To Separation Tank Water or Waste INSTALLATION Pool Drain Line Installation and wiring of pump should only be done by qualified, li- Figure 3: Typical Pump/Filter censed personnel. - Page 6 Teflon Taping Instructions • Use only new or clean PVC pipe fittings. • Wrap male pipe thread with one or two layers of teflon tape, winding tape clockwise as you face the start of thread. Cover entire thread por- tion of pipe. See Figure 6. •...
-
Page 7: Electrical
ELECTRICAL Ground motor before connecting to electrical power supply! Failure to ground pump motor can cause serious or fatal electrical shock hazard! Do not ground to a gas supply line! To avoid dangerous or fatal electrical shock, turn OFF power to motor before working on electrical connections. -
Page 8: Operation
OPERATION NEVER run pump dry! Running pump dry may damage seals, causing leakage and flooding! Fill pump with water before starting motor. Do not add chemicals to pool/spa system directly in front of pump suc- tion. Adding undiluted chemicals may damage pump and voids warranty. -
Page 9: Pump Service
PUMP SERVICE Pump should only be serviced by qualified personnel. Be sure to prime pump (Page 8) before starting. Before removing trap cover or front plate bolts: 1. STOP PUMP before proceeding. 2. CLOSE GATE VALVES in suction and discharge pipes. 3. -
Page 10: Storage/Winterizing
STORAGE/WINTERIZING To prevent damage to components from fumes, store pool and spa chemicals away from pump and spa. If possible, store chemicals in an other well-ventilated area. Allowing pump to freeze will damage pump and void warranty! • Drain all water from pump and piping when expecting freezing temper- atures or when storing pump for a long time (see instructions below). -
Page 11: Troubleshooting Guide
TROUBLESHOOTING GUIDE D. CIRCUIT BREAKER IN HOME PANEL Read and understand safety and operating in- TRIPS REPEATEDLY structions in this manual before doing any work on pump! 1. Breaker must be of adequate capacity. 2. For GFCI breaker; test according to GFCI manufac- Only qualified personnel should electrically test turer’s instructions. -
Page 12: Repair Parts List
Impeller No. Trap Body C153-53P1 (Key No. 1) (Key No. 8) Gasket C20-123 115Volt Pipe Plug WC78-40T • Nameplate U33-155 JWPD-075 AS900DLL C105-228PHS • Decal-”Use Copper 115/230 Volt Conductors Only. . .” 90000-1388 JWPE-100 62003-2002 C105-228PGS • Warning Tag C63-12 •...
