Dual Outlet (divert) Controller

START/STOP
1. Turn the temperature dial to the required setting.
N.B. The temperature can also be adjusted during water flow by turning the bezel.
2. Press the Start/Stop button on the controller to turn the shower on.
Whilst the shower is in use, press and hold to divert (the 1
stop and the 2
slight outlet temperature change when switching between outlets.
3. The red and blue LED display will flash until the selected temperature has been
reached. When the LED display is constant, your shower is ready to use.
4. Press the 'Boost' on the controller to increase the flow of the shower when
desired. To turn 'Boost' off, press the 'Boost' button again at any time.
N.B. The strength of the 'Boost' button will vary depending on the water system
pressure and the configuration of the pipework. For further information, see
the Important Information section in the main product (Aqualisa SmartValve™)
installation guide.
5. Press the Start/Stop button to turn the shower off.
As a safety feature, the Aqualisa SmartValve™ has a maximum run time
of 20 minutes. The flow can be stopped and started at anytime by
pressing the 'Start/Stop' button.
This can be enhanced by activating and using the free Aqualisa app.
See pages 3 and 9 for details.
TEMPERATURE
Adjust before starting
or during shower
outlet will start). Depending on system pipe runs, there may be a
nd
CHANGE OUTLET
Push and hold for over 3
seconds and release when flow
switches between outlets
BOOST
Increase flow rate
during shower
outlet will automatically
st
