Battery Operated Hydraulic
Crimping Tool with Insulated Head
Catalog Number: BPLT14BSCRI
IMPORTANT: Read and understand all of the instructions and safety
information in this manual before operating or servicing this tool.
1.0 General Information
1.1 Battery Operated Hydraulic Crimping Tool .................................................. 2
1.2 General Characteristics ............................................................................... 2
1.3 Acoustic Noise ............................................................................................. 2
1.4 Risk Due to Vibration ................................................................................... 2
1.5 Overall View ................................................................................................. 2
2.0 Instruction for use .......................................................................
2.1 Preparation .................................................................................................. 3
2.2 Die Advancement......................................................................................... 3
2.3 Compression ................................................................................................ 3
2.4 Release of Dies ............................................................................................ 3
2.5 Die Replacement ......................................................................................... 3
3.0 Batteries .......................................................................................
3.1 Battery Status & Replacement ..................................................................... 3
3.2 Battery Charger ............................................................................................ 3
3.3 Battery Use .................................................................................................. 3
4.0 Maintenance ................................................................................
4.1 Cleaning ....................................................................................................... 4
4.2 Storage ........................................................................................................ 4
4.3 Adding Oil .................................................................................................... 4
5.0 Parts List
for Type 2
6.0 Parts List
for Older Models
Table of Contents
.................................................................................. 2
........................................................................
...............................................................
3
3
4
4
6
TA02966 E page 1 of 8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Thomas & Betts BPLT14BSCRI
Summary of Contents for Thomas & Betts BPLT14BSCRI
- Page 1 Battery Operated Hydraulic Crimping Tool with Insulated Head Catalog Number: BPLT14BSCRI IMPORTANT: Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. Table of Contents 1.0 General Information .................. 2 1.1 Battery Operated Hydraulic Crimping Tool ..........2 1.2 General Characteristics ................
-
Page 2: General Information
2.5 m/sec The “BPLT14BSCRI” hydraulic tool is powered by a 14.4V Ni-MH battery. It is a balanced tool for optimum control, quiet in operation with very little vibration, with lightweight construction enabling the... -
Page 3: Die Replacement
INSTRUCTION FOR USE PREPARATION The tool can be easily carried using either the handle or shoulder strap (01) attached to rings (15 and 18). With the tool at rest, prepare the tool as follows: (see Figure 2) − Select the appropriate die set for the connector. −... -
Page 4: Maintenance
MAINTENANCE The tool is robust, completely sealed and requires very little daily maintenance. Compliance with the following points should help to maintain the optimum performance of the tool: CLEANING ADDING OIL − Dust, sand and dirt are a danger for any hydraulic device. Should it be required, top up the oil as follows (Refer to Figure. - Page 5 FIGURE 4 TA02966 E page 5 of 8...
- Page 6 PARTS LIST for Older Models See Figure 5 for complete tool assembly. Code Nº Item DESCRIPTION Code Nº Item DESCRIPTION 6000354 WRIST STRAP 6040427 STRAP ANCHOR RING 6900022 M3X8 SCREW 6000236 PRESSURE RELEASE BUTTON 6100038 6000378 OPERATING PUSH-BUTTON 6370237 "C" HEAD COMPLETE 6040427 STRAP ANCHOR RING 6620440...
- Page 7 FIGURE 5 TA02966 E page 7 of 8...
- Page 8 In case of a breakdown, contact the Thomas & Betts Tool Service Center at 1-800-284-TOOL (8665). WARRANTY: Thomas & Betts sells this product with the understanding that the user will perform all necessary tests to determine the suitability of this product for its intended use. Thomas & Betts manufactures its goods and tools in a manner to be free of defects.
