urmet domus Alpha iPerCom 1168 Manual page 23

3.10 OPENING THE DOOR USING A TRANSPONDER KEY WITH DOOR CODE
3.10.1
The Homepage appears on the display when any button on the call module is
pressed or after the user approaches the call station as indicated by the presence
sensor (optional).
3.10.2
Pass the transponder key near the reader on the key reader module Ref. 1168/45,
near the sensor located in the center of the module. You are prompted to enter
the door opening code. The screen shown on the side refers to a system where
both gates are available.
If there is only one gate in the system, the screen will only show the indication
of the available gate.
3.10.3
Then, enter the door opener code on the keypad.
If you make a mistake while typing, you can delete the wrong character using the
button in the shortcut menu or by pressing "X" on the keypad.
Press the shortcut button next to the
one next to the icon to open the door. The screen shown on the side refers to
a system where both gates are available.
If there is only one gate in the system, the screen will only show the indication
of the available gate.
3.10.4
According to the selected input type, one of the two screens shown by the side
appears on the display:
3.10.5
If the key is not valid (not registered), the screen shown opposite appears on the
display for  seconds.
DS1168-033
icon to open the gate. Similarly, press the
