THE 239 MOTOR MANAGEMENT RELAY
4.2.5

Interfacing to the RTT through the EnverVista 239 Setup Program

4.2.5.1 Current
4.2.5.2 RTDs
70
The following section demonstrates how to navigate, configure, and monitor the operation
of the 239 Relay using the EnerVista 239 Setup program.
Setup: Enter the Phase CT Primary, then Save.
Metering: View the current values measured by the relay, in real-
time.
Setup: Configure the RTD Type and the application, for each RTD.
CHAPTER 4: MOTOR MANAGEMENT & METERING
FIGURE 4–12: Current Setup
FIGURE 4–13: Current Metering
FIGURE 4–14: RTD Setup
