ABOUT YOUR NEW RTT UNIT
6
The figure below shows the wire labels (see figure 1-2, above), that correspond to the RTT
terminals..
CHAPTER 1: GETTING STARTED
RTD1 +
RTD1 -
RTD1 C
RTD2 +
RTD2 -
18 AWG
RTD2 C
RTD3 +
RTD3 -
RTD3 C
SPARE
Output C
Output 2
Output 1
Input C
Input 8
Input 7
18 AWG
Input 6
Input 5
Input 4
Input 3
Input 2
Input 1
Current I
+
10 AWG
Current I
-
Voltage V
+
18 AWG
Voltage V
-
