- Page 1 INSTRUKCJA DOORPHONE ANALOG SET WITH PANEL ELITE (flush mounting) AND UNIPHONE SIGNO 6025/401 6025/402 6025/441 6025/442 Version I, 10.09.2018...
-
Page 2: General Informations
DOORPHONE ANALOG SET 6025/401 6025/402 6025/441 6025/442 SPEAKER’S MODULE REF. NO. 6025/PR1 DIMENSIONS OF CASING 6025/PR2 Surface-mounted housing ref. no. 6025/OND-M GENERAL INFORMATIONS Speaker's plate is made of stainless steel, vandal-proof degree of protection IK07. Its compact size makes it ideal for mounting on narrow pillars fence. -
Page 3: Montage
SPEAKER’S MODULE REF. NO. 6025/PR1..2 MONTAGE PANEL MONTAGE In the slot in the faceplate Plexiglas insert the correct label. Tighten the screw that secures the motherboard. INSERTING THE LABEL TO INFO WINDOW To attach the label information have to: In the original packaging is one additional label. 1. - Page 4 SPEAKER’S MODULE REF. NO. 6025/PR1..2 MONTAGE To mount the panel-mounted version follow the steps below. 1. Loosen the screw with a key patent secures the front panel. Remove face plate. 2. Insert the wires connecting using one B of the holes in the back housing (Photo below).
- Page 5 UNIPHONE NR REF. 1140/1 , 1140/41 GENERAL INFOMATIONS UNPHONE “SIGNO” NR REF. 1140/1 (white), Inside the uniphone, after removing its housing on the PCB, there is a terminal strip used to connect the camera to the system. The 1140/41 (black) function buttons have independent contacts.
-
Page 6: Wall Mount
UNIPHONE NR REF. 1140/1 , 1140/41 MONTAGE INSTALATION SIGNO can be mounted on a wall WALL MOUNT It is advisable to install the uniphone at such a height that the highest part of the device is at a height of 1.55 m from the ground To mount a uniphone in a hanging version, follow the steps below. -
Page 7: Basic Features
POWER SUPPLY NR REF. 18A2 GENERAL INFORMATIONS POWER SUPPLY UNIT REF. 18A2 The power supply ref. 18A2 is equipped with 2 potentiometers for adjusting external (on the right) and internal volume (on the left). Exchanging of the fuse is possible after taking the cover of power supply off. - Page 8 SCHEMA WITH POWER SUPPLY 18A2 AND SPEAKER’S MODULE 6025/PR1...
- Page 9 SCHEMA WITH POWER SUPPLY 18A2 AND SPEAKER’S MODULE 6025/PR2...
- Page 10 MIWI-URMET Co. Ltd. Pojezierska 90A 90-341 Lodz, Poland tel: 004842 616 21 00 fax: 004842 616 21 13 e-mail: miwi@miwiurmet.pl http:/www.miwiurmet.pl The symbol of the crossed out wheeled bin indicates that the product (electrical and electronic equipment) should not be placed in municipal waste.
