Tefcold EXPRESS EX125C Instruction Manual page 22

dp Maximum defrost duration
d4 Defrost when switching the instrument on
d5 Defrost delay on power-up or when enabled by digital input
d6 Freeze control temperature display during defrost
dd Dripping time
d8 Alarm bypass time after defrost
d9 Defrost priority over compressor protectors
d/ Defrost probe reading (2)
dc Time base
A Alarm Parameters
A0 Alarm and fan temperature differential
Al Absolute/relative temperature for low temperature alarm
Ah Absolute/relative temperature for high temperature alarm
Ad Temperature alarm delay
3rd input configuration: 0=multifunction input disabled,
1=external alarm, 2=Enable defrost, 3=Start defrost on
closing, 4=Curtain switch and night-time operation,
5=Remote ON – OFF, 6=Direct operation of AUX output with
A4 H1=3, 7=Door switch with evaporator fans off, 8=Door switch
with evaporator fan and compressor off, 9=Direct/reverse
operating mode r3= 0 specifies the activation of the defrost
control, 10=Probe for dirty condenser alarm, 11=Product
probe
A7 Digital input alarm delay
A8 Enable alarm "Ed" (end defrost by timeout)
Ac Set point dirty condenser alarm
Ae Dirty condenser alarm differential temperature
Acd Dirty condenser alarm delay
F Fan Parameters
F0 Enable evaporator fan control
F1 Evaporator fan control set point
F2 Stop evaporator fan if compressor off
F3 Evaporator fan status during defrost
Fd Post-dripping time
H Other Settings
H0 Serial address
min./s 30
- 0
min. 0
- 1
min. 0
h 1
- 0
°C/°F -
- 0
°C/°F 0
°C/°F -8
°C/°F 20
min. 15
- 0
min. 30
- 0
°C/°F 55
°C/°F 10
min. 0
- 1
°C/°F 50
- 0
- 0
min. 0
- 0
30
0
0
1
0
1
0
-
0
0
-8
20
15
0
30
0
55
10
0
1
50
0
0
0
0
