Packing List

In addition to this

iSN-101 iSN-101/DIN

ASO-0043

3m Water Sense Cable

ASO-0046

180° Hold-Down Clip

The ASO-0042 and ASO-0044 are included for iSN-101/S and iSN-101/S/DIN.

The ASO-0043 and ASO-0044 are included for iSN-101/S2 and iSN-101/S2/DIN.

The ASO-0045 are included for iSN-101/S3 and iSN-101/S3/DIN.

iSN-101 Quick Start

Quick Start Guide

Quick Start

ASO-0044

3m Extended Cable

ASO-0047

90° Hold-Down Clip

, the package includes the following items:

v1.0, Jul 2019

ASO-0042

1m Water Sense Cable

ASO-0045

Water Sense Probe

Page 1 ASO-0047 180° Hold-Down Clip 90° Hold-Down Clip The ASO-0042 and ASO-0044 are included for iSN-101/S and iSN-101/S/DIN. The ASO-0043 and ASO-0044 are included for iSN-101/S2 and iSN-101/S2/DIN. The ASO-0045 are included for iSN-101/S3 and iSN-101/S3/DIN. Copyright © 2018 ICP DAS Co., Ltd. All Rights Reserved.
Page 4 Quick Start v1.0, Mar 2019 iSN-101 Getting Started/User Manual  iSN-101 Series User Manual http://ftp.icpdas.com.tw/pub/cd/iiot/  DCON Utility http://ftp.icpdas.com.tw/pub/cd/iiot/utility/  iSN-101 Website http://www.icpdas.com/root/product/solutions/remote_io/rs-485/sensor_series/isn-101.html DIP Switch and Jumper Settings Address Settings via Hardware Configuration If there is any other question, please feel free to contact us.
