Garmin Speed Sensor 2 Quick Start Manual page 6

3 Rotate the wheel to check for clearance.
The sensor should not contact other parts
of your bike.
NOTE: The LED flashes green for five
seconds to indicate activity after two
revolutions.
Installing the Cadence Sensor
NOTE: If you do not have this sensor, you can
skip this task.
TIP: Garmin recommends you secure your
bike on a stand while installing the sensor.
1 Select the band size that fits your crank
①
arm securely.
The band you select should be the
smallest one that stretches across the
crank arm.
2 On the non-drive side, place and hold the
flat side of the cadence sensor on the
inside of the crank arm.
3 Pull the bands
and attach them to the hooks
sensor.
Spd/Cad Sensor 2
②
around the crank arm,
③
on the
5
EN
