Home Styles Dolly Madison 88 4528 95 Quick Start Manual

88 4528 95
Wood Top Kitchen Cart
(Black Finish)
IMPORTANT NOTE
Carefully remove all the parts from the carton and put them individually
on a soft cloth to prevent scratches or other damages occuring to the wood parts.
We have taken great care in the design of this product and request that you carefully
and strictly follow our assembly instructions to ensure a completed product as it was designed.
PART LIST
A.
Top
1 pc.
H.
Back Panel
4 pcs.
M.
Side Bar
2 pcs.
HARDWARE LIST
Caster
Wood Screw
two lock
for Caster
two non-lock
16 pcs. (+1 extra)
4 pcs.
Tools Required For Assembly : Phillips screwdriver
Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319
B.
Side Panel
1 pc.
I.
C.
Front Piece
Middle Panel
1 pc.
1 pc.
J.
Front Piece
1 pc.
N.
Shelf
2 pcs.
Cam Lock Screw
Hex Wrench
1 pc. 6 pcs. (+1 extra)
Cam Lock
6 pcs. (+1 extra)
servicedesk@homestyles-furniture.com
D.
Side Panel
1 pc.
K.
Divider
1 pc.
O. P.
Door Door
2 pcs. 2 pcs.
Wood Screw (long)
Head Cap Bolt
for Drawer Side Part
12 pcs. (+1extra)
16 pcs. (+1 extra)
Adjustable Pin Head Cap Bolt (long)
8 pcs. (+1 extra) 7 pcs. (+1extra)
E.
Back Stretcher
2 pcs.
F.
Back Piece
1 pc.
Back Piece
L.
Base
1 pc.
Q.
KD. Drawer
2 pcs.
(Knock-Down Construction,
please refer to the last page of
instructions for steps to complete
assembling drawers)
Wood Screw (short)
for Drawer Base Part
12 pcs. (+1 extra)
Pull Handle
6 pcs.
Cross Dowel
7 pcs. (+1extra)
G.
2 pcs.
Machine Screw
for Pull Handle
12 pcs.
Wood Plug
9 pcs.
(+1 extra)
