Cleveland KDM-25 Specifications

™
Cleveland
DIRECT STEAM KETTLES
CABINETIZED, DIRECT STEAM
POWER TILTING OR STATIONARY
2⁄3 STEAM JACKETED
25, 40 or 60 GALLONS (100, 150 or 225 LITERS)
Cleveland Standard Features
I Compact, Space Saving Modular Design
I Type 304 Stainless Steel with # 4 finish on Kettle and Cabinet
I Steam Control Kit includes: Steam Control Valve, Steam Trap
Assembly, Condensate Strainer, Check Valve, all Factory
Assembled and Mounted
I Spring Assisted, Hinged, Domed Stainless Steel Cover
I 2" diameter Tangent Draw-Off Valve with Srainer
I Hot and Cold Water Faucet with Swing Spout
I 25 psi Steam Jacket Rating and Safety Valve
I Kettle Drain Swing Funnel
I Typical approvals include NSF and ASME
FOR TILTING MODELS ONLY
I High Capacity Pouring Lip
I Permanently lubricated Power Tilt Mechanism
Options & Accessories
Ë Steam Pressure Reducing Valve where pressure exceeds 20
psi (PRV)
Ë Steam Supply Moisture Separator (MS)
Ë Type 316 Stainless Steel Kettle Liner for high acid food
products (316-G)
Ë Cooking Baskets and Tri- Basket Supports (BS and TBS)
Ë Kettle Accessory Kit (KAK) includes:
Ë Clean-up Brush (CB)
Ë 36˝ Kettle Whip (KW)
Ë Draw-off Brush (DB)
Ë Lift-Off Covers (CL)
Ë Measuring Strip (MS)
Ë Gallon Markings (KM)
Ë Hot and Cold or Cold Only Kettle Filler with 60" hose (DKF-K
or SKF-K)
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
Ë 36˝ Kettle Paddle (KP)
Ë 36˝ Kettle Brush (KB)
Ë 24 oz. Ladle (KL)
Tel: 1-216-481-4900
Fax: 1-216-481-3782
MODELS:
Short Form Specifications
Kettle Shall be CLEVELAND, Direct Steam Kettle, Cabinetized,
Model KDM - _____ - T (Power Tilt) or KDM- _____ (stationary);
_____Gallons. 2/3 Steam Jacketed, Type 304 Stainless Steel with
25 psi Steam Jacket Rating; Cabinet and frame to be Type 304
Stainless Steel; includes: Spring Assisted Domed Cover, 2"
Tangent Draw-Off Valve, Hot and Cold Water Faucet with Swing
Spout. To operate, connect directly to a steam source supplying
from 5 to 20 psi steam. Chromed Steam Condensate Trap and
Strainer factory assembled.
FOR TILTING MODELS ONLY
Ë Pan Carrier (PCK)
Ë Flow Diverter (FD)
Ë Food Strainer (FS)
Web Site: www.ClevelandRange.com
Email: Steam@ClevelandRange.com
Project ________________________________
Item __________________________________
Quantity _______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
KDM-25-T KDM-25
KDM-40-T KDM-60
KDM-60-T KDM-80
X 15
SECT. PAGE
0707
