Summary of Contents for Nuna Pipa
- Page 2 Designed around your life...
-
Page 3: Table Of Contents
Child Usage Requirements KEEP THESE Warnings INSTRUCTIONS FOR Car Seat Use after a Crash FUTURE REFERENCE: Vehicle Compatibility Infant Car Seat Parts List READ CAREFULLY Base Parts List Product Overview Product Use Installation Cleaning and Maintenance PIPA instructions PIPA instructions... -
Page 4: Product Information
Send your name, address, warranty questions, please contact our customer e-mail address if available and the Child Restraint’s service department. model number and manufacturing date to: In the USA: Nuna Baby Essentials Inc. infousa@nunababy.com 70 Thousand Oaks Blvd. www.nunababy.com Morgantown, PA 19543 1.855.NUNA.USA or call 1.855.NUNA.USA... -
Page 5: Warnings
(2 and 14.5 kg) and whose height EXPIRATION DATE Check the label on the is 32 inches (81 cm) or less. Exceeding underside of the base or child restraint for these height and weight limits is unsafe. expiration date information. PIPA instructions PIPA instructions... - Page 6 DO NOT use any products or accessories The carrier can fall with this child restraint unless they are from a shopping cart. approved by Nuna for use with this child DO NOT USE on a restraint. Doing so may be unsafe and may shopping cart.
-
Page 7: Car Seat Use After A Crash
If your vehicle is equipped with passenger side air NEVER use a car seat that has been involved in bags, check your vehicle owner’s manual for child a moderate to severe crash. Contact Nuna with restraint installation instructions. questions or concerns about your seat. - Page 8 This belt cannot be used to install this child restraint. - Lap Belts forward of Seat Bight This belt (Where the seat bottom and seat back meet) should not be used to install this Child Restraint. PIPA instructions PIPA instructions...
-
Page 9: Infant Car Seat Parts List
Adjuster Button 15 Harness Slots Adjuster Strap 16 Base Attachment Lap Belt Guides 17 Harness Straps Handle Button 18 Splitter Plate Stroller Release 19 Base Attachment Button 10 Shoulder Pads *only used with infant car seat adapters PIPA instructions PIPA instructions... -
Page 10: Base Parts List
Button Primary Rigid 10 Car Seat Release LATCH Release Button Button Bubble Indicator Secondary Rigid LATCH Release 12 Instruction Manual Button Storage Rigid LATCH Guides 13 Stability Leg Locking Clip Storage Stability Leg 14 Recline Adjustment PIPA instructions PIPA instructions... -
Page 11: Product Overview
The low birth weight pillow (highlighted) can be used in the infant insert for even smaller babies, but should be removed once a snug fit can be achieved without it, at approximately 11 lb. PIPA instructions PIPA instructions... - Page 12 Be sure handle is locked in the carry position before lifting child restraint by handle. An unlocked handle could move unexpectedly, causing injury to child. Handle MUST NOT contact the vehicle interior (side of car or seat in front) when installed. 20 PIPA instructions PIPA instructions...
- Page 13 - Grasp the seat pad at the bottom of the adjuster button as shown and pull the seat pad out from under one edge of the adjuster button. Work around the adjuster button to release the remainder of the seat pad. 22 PIPA instructions PIPA instructions...
- Page 14 - To adjust shoulder harness height, remove child and loosen harness. - Turn child restraint over and remove one harness loop from metal splitter plate. - Pull loose ends of harness out through slots and place in correct slot. 24 PIPA instructions PIPA instructions...
- Page 15 - This position provides a medium fit. Crotch belt is threaded into rear slot as shown. - This position provides the largest fit. Crotch belt is threaded through front slot as shown. 26 PIPA instructions PIPA instructions...
-
Page 16: Product Use
- The child should be seated against both the back and bottom of the seat with no gap behind the child. Do not allow child to slouch. Gently guide child’s arms through harness loops. - Insert buckle tongues into buckle. 28 PIPA instructions PIPA instructions... - Page 17 Serious injury or death could occur to a child that is not secured properly. If child is not secured properly, child could be ejected in a sudden stop or crash, resulting in serious injury or death. 30 PIPA instructions PIPA instructions...
-
Page 18: Installation
For instructions on using the stability leg when installing the base, see stability leg section. - If necessary, install rigid LATCH guides on vehicle LATCH lower anchor bars. 32 PIPA instructions PIPA instructions... - Page 19 (side of car or seat in front) when installed. - To release the child restraint, squeeze the car seat release button (1) located on the base, while pulling the child restraint up (2). 34 PIPA instructions PIPA instructions...
- Page 20 - Place vehicle in park and on level ground. - Position base in a forward facing vehicle seat. Use recline adjustment to position bubble in indicator. Adjust base so bubble touches line. - Use recline adjustment to achieve correct angle for installation. 36 PIPA instructions PIPA instructions...
- Page 21 Belts and buckles must not interfere with click attachment of child restraint to base. Vehicle belts must lay flat under lock off. It is acceptable to install with both LATCH (lower attachments) and the vehicle belt. 38 PIPA instructions PIPA instructions...
- Page 22 - Do not use if stability leg lifts base off seat. Do not use stability leg to recline the base. The recline adjustment feature is meant to recline the base. Always store stability leg when not in use. 40 PIPA instructions PIPA instructions...
- Page 23 This child restraint can be installed without a base in 3 different ways. - Place vehicle in park and on level ground. Position child restraint so that child is facing the rear of the vehicle. Only install in a forward facing vehicle seat. 42 PIPA instructions PIPA instructions...
- Page 24 Blue line must be level with ground. Vehicle belt must be buckled, tight and must stay locked. Child restraint should be stable and not move side to side more than 1 inch at belt path. 44 PIPA instructions PIPA instructions...
- Page 25 (1). The angle is correct when the blue line is level with the floor of the aircraft (2). Tighten the aircraft belt while pushing the child restraint firmly into the seat. 46 PIPA instructions PIPA instructions...
-
Page 26: Cleaning And Maintenance
Check regularly if everything functions properly. If any parts are torn, broken, or missing, stop using this product. Nuna Baby Essentials, Inc. Nuna and all associated logos are trademarks. 48 PIPA instructions PIPA instructions...
