Nuna PIPA Manual

Harness: Shoulder straps are attached to a splitter plate behind seat. Pull
strap end in front of seat to tighten harness. Push button at lower front of seat
and pull on shoulder straps to loosen. Lap straps are threaded through slots
near child's hips to outside/underside of seat.
Harness Slots: There are three sets of slots. To change shoulder strap slot
height, remove straps from splitter plate on back and rethread through
desired slots, then reattach to splitter plate. Harness straps must be
between child restraint and attachment bar (diagram 1)
Crotch Strap: Adjustable. There are two slots; length is also adjustable.
Crotch strap is sewn to a metal anchor which must lie flat against underside
of seat. Use position closest to, but not under, child. To change position,
turn metal anchor sideways, feed through slot, and insert into desired slot.
To shorten length for smaller child, feed metal anchor through inner slot and
out through outer slot (diagram 2).
Angle Adjustment: Recline adjustment foot is located beneath base
(diagram 3). Once extended, make sure it is locked into position. Angle
indicator is located on side of base. Bubble must touch black line
(diagram 4).
Belt Path: If LATCH is not in use, leave connectors locked in place on side
of base (diagram 3).
With base: Unfold load leg from beneath base (diagram 5). Route
vehicle belt through openings in base, and under lock-off (diagram 6).
Tighten vehicle belt and close lock-off.
Important: This information sheet is not a substitute for complete manufacturer's directions and current recall list.
SafetyBeltSafe U.S.A., P.O. Box 553, Altadena CA 91003 (310)222-6860 (800)745-SAFE ©SafetyBeltSafe U.S.A. #450 01/14
NUNA
Type: Rear facing only
Last date made: Current
First made: 2013
Weight Limits: 4-32 lbs.
Harness: 5 pt. harness
PIPA
5
P. 1 of 2
1
2
3
4
6
