Cleveland 18-DM-K6 Specifications

™
Cleveland
MODULAR BASES
MODULAR BASE WITH KETTLE(S)
DIRECT STEAM
ONE or TWO, 6 GALLON KETTLE(S)
CABINET BASE: 18" (450MM), 24" (600MM) or 36" (900MM) WIDE
Cleveland Standard Features
I Factory assembled Kettle/Modular Base combination with
one or two, 6 gallon kettle(s) for direct connection to steam
from another source
I Steam Control Kit: includes needle type Steam Control
Valve(s), Steam Trap, Condensate Strainer, Check Valve,
nipples and fittings, factory assembled and mounted on
kettle(s)
I Type 430 Stainless Steel exterior enclosure, kettle(s) and
table top (with drain Trough which has 1.50" diameter male
drain); #4 exterior finish
I 6 gallon kettle(s) are 2/3 Steam Jacketed and include
Lift-Off Cover(s)
I Hot and Cold Water Faucet with Swing Spout
I Kettle(s) have 50 psi Steam Jacket Rating, 50 psi chrome
plated Safety Valve(s) and Manual Tilting, balanced design
I Tilt Handles can be mounted on either side of kettle(s)
I Adjustable Flanged Feet (FF-A)
Options & Accessories
Ë Type 316 Stainless Steel Kettle interior(s) for high acid food
products (316)
Ë Food Strainers (FS)
Ë Pressure Reducing Valve for incoming supply over 50 psi
(PRV)
Ë Stainless Steel Base Frame (FSS)
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
Tel: 1-216-481-4900 Web Site: www.ClevelandRange.com
Fax: 1-216-481-3782 Email: Steam@ClevelandRange.com
MODELS: 18-DM-K6
24-DM-K6
36-DM-K66
Short Form Specifications
Shall be CLEVELAND, Direct Steam, Modular Cabinet Base with one or two,
6 gallon kettle(s), Model _____ DM-K _____ Type 430 Stainless Steel exterior
enclosure, Table Top and 4 Level adjustable Feet. 2/3 Steam Jacketed,
type 304 Stainless Steel kettle(s) with 50 psi Steam Jacket Rating. Needle
type Steam Control Valve on each kettle. To operate connect directly to a
steam source supplying from 5 to 10 psi steam. Steam Condensate Trap and
Strainer, factory assembled and installed. Includes Hot and Cold Water
Faucet with Spring Spout and Lift-Off Kettle Cover(s).
Project ________________________________
Item __________________________________
Quantity _______________________________
FCSI Section ____________________________
Approval _______________________________
Date __________________________________
VII 35
SECT. PAGE
0707
