- Page 1 FOCUS Sign Lights 10W 20W Installation Manual SOLTECH Provides Advanced LED Technology Powered With Eco-friendly, Clean, Solar Energy.
- Page 2 01 Introduction Thank you for purchasing FOCUS Urban Lighting Products. Important electricity stored in the battery. The performance of the solar lights is Please read these instructions before installation to ensure optimum results dependent on the location of the solar panel and/or weather conditions. and longevity of your lights.
- Page 3 02 Specification Specification FOCUS 10W FOCUS 20W LED Nominal Power Solar Panel 12V 13W 12V 26W Lithium Ion Battery 74WH 7.4V 10AH 148WH 7.4V 20AH 4,000K & 5,000K 4,000K & 5,000K Lumen Output@5000K 1,000 2,000 > 70 > 70 LED Chip...
-
Page 4: Ground Mount
03 Installation GROUND MOUNT Secure Mounting For signage near the ground, the FOCUS can use a drill instal- lation into concrete, to create a Attach light by using scale holes secure, tightly bolted fixture. Mounting Stand GROUND MOUNT—For Grassland & Soil If you want to install the FOCUS on grassland and soil, you SPIKE—For need SPIKE accessory. - Page 5 THE RIGHT ANGLE You can adjust the angles of your FOCUS solar light, ensuring that no matter the installation, you can provide a right angle in different weather, signs, or temperature situations. Optimize efficiency by Adjust pole height, then tighten rotation Panel and Light screws to position.
- Page 6 04 Luminous Distribution FOCUS 10W Lamp=734.25 lm Type C Max=1 103.1 cd/klm Power=6 W Multiplier=0.73425 Degrees=0 1000 Point 0x0x0 mm A. Legotin (C) 2004 IES Viewer v2.99n FOCUS 20W Lamp=1 lm Type B Max=724 250 cd/klm Power=0W Multiplier=0.001 Degrees=0 100 000...
- Page 7 05 Warranty FOCUS is covered by a 3 year limited warranty. SOLTECH urban light warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 3 years from date of purchase. To obtain warranty service please contact your local distributor or sales rep for further instruction.
- Page 8 1460 Park Avenue. Emeryville, CA 94608 USA www.soltechlighting.com SOLTECH LLC reserves the right to update all product data sheets at any time. Consult SOLTECH marketing specialists for publication updates at Copyright©2021–2022 SOLTECH LLC, hello@soltechlighting.com All Rights Reserved.
