- Page 1 USER MANUAL Timing set - basic ZPCP14 File: 2014-11-04 PRODUCT SUPPORT Pawel Ciechanowski p.ciechanowski@polanik.com...
- Page 2 1. General use ZPCP14 is a basic timing system for track events in the athletics. It allows you to record the competitors’ times with the resolution up to 1/1000 s. The shot from the staring revolver initiates the timing of the chronometer and the time is recorded when the infrared beam of the sports photocell is tripped by the competitor.
- Page 3 Product Description Image code chronometer RS-START9 starting revolver PNB-150 start signal cable 150 m on spool 3. Assembly of the set The example of the wiring the set is presented below. Technical specification / user manual ZPCP14 3 / 4...
- Page 4 Signed for and in behalf of: POLANIK 2014-11-04 Piotrkow Tryb. (Date and place of issue) 6) Pawel Ciechanowski Product Manager …………………….………………….. …………………………………………………………………………… (Name, function) (Signature or equivalent authorized by the issuer) Technical specification / user manual ZPCP14 4 / 4...
