INSTRUCTION MANUAL
Premium Line
competition take-off board for long jump and triple jump
with stainless steel foundation tray and stainless steel adjustable base board
S12-250
(ver. 2018)
NEW TECHNOLOGY – SAFE JUMPS AND EASIER OPERATION
File: 2020-09-08
PRODUCT SUPPORT
Pawel Ciechanowski
p.ciechanowski@polanik.com
Advertisement
Table of Contents
Related Manuals for Polanik S12-250
Summary of Contents for Polanik S12-250
- Page 1 INSTRUCTION MANUAL Premium Line competition take-off board for long jump and triple jump with stainless steel foundation tray and stainless steel adjustable base board S12-250 (ver. 2018) NEW TECHNOLOGY – SAFE JUMPS AND EASIER OPERATION File: 2020-09-08 PRODUCT SUPPORT Pawel Ciechanowski...
-
Page 2: Table Of Contents
• Before you start to assemble and use the product please read this manual carefully and store the manual in a safe place for further reference. Polanik shall not be liable for any cage damages which are the result of the failure to follow this manual. -
Page 3: General Characteristics
1. General characteristics The premium take-off board S12-250 is designed for conducting sports events and training programs of horizontal jumps. Main features of the take-off board: • high safety – construction according to the latest recommendations – no metal elements in take-off zone,... -
Page 4: Parts List (Part Sets)
(draining tubes and spacing boards) K3-250 Stainless steel base board S-0250-000-09-00-00 White take-off board 20 mm with screws K2-250 Indicator plasticine board S-250-02-00 Training indicator board without plasticine S-250-02-03 Spare plasticine 300 g S-250-02-01 Instruction manual S12-250 ver. 2018 4/15... -
Page 5: Assembly And Installation
For any other competition, the distance shall be adjusted to competitors` level. The installation point of the tray (item 1) of the take-off board is presented below. Drawing 1. Installing the take-off board – general view Instruction manual S12-250 ver. 2018 5/15... - Page 6 1. and draw. 2.), so that it does not deform while placing the concrete. Deformations can make the plasticine board (item 4) or training board (item 5) block inside the tray. Image 1. Installed tray secured with spacing boards Instruction manual S12-250 ver. 2018 6/15...
- Page 7 During the embedding process of the foundation tray (item 1), draining tubes can stick out over the foundation tray bottom. After the concrete setting, the sticking tube ends are to be cut off as close to the tray bottom as possible to ensure the correct water outflow. Instruction manual S12-250 ver. 2018 7/15...
-
Page 8: Installing The Take-Off Board Set In The Foundation Tray
(see g, drawing 3) of the base board (item 2) need to be re-regulated, so please do the following: - take out the whole set from the tray, - unscrew the white take-off board (item 3) from the base board (item 2) using the included screwdriver (item 10), Instruction manual S12-250 ver. 2018 8/15... - Page 9 - if the white take-off board is on the correct level, use the wrench to screw down the counter nuts to block the feet, - if the level of the white take-off board is still incorrect, continue to adjust the feet. Instruction manual S12-250 ver. 2018 9/15...
-
Page 10: Installing Indicator Boards
Put the plasticine indicator board (item 4) or training indicator board (item 5) into the tray next to the white take-off board (item 3) and the set is ready for use. Image 2. Set ready for use, mounted in the runway Instruction manual S12-250 ver. 2018 10/15... - Page 11 – ground d – white take-off board (item 3) j – draining tube e – adjustable stainless steel base board (item 2) k – athletics synthetic surface f – screw fastening white take-off board Instruction manual S12-250 ver. 2018 11/15...
-
Page 12: Remarks On Maintenance And Operating
Any defects in paint coating revealed during thorough regular inspections of the board set must be repaired with wood paint or impregnant. It is recommended that the embedded tray (item 1) should be sheltered with the cover when not used (see page 14). Instruction manual S12-250 ver. 2018 12/15... -
Page 13: Technical Drawing - Scheme Of Construction And Dimensions
– plasticine indicator board (item 4) d – white take-off board (item 3) e – adjustable stainless steel base board (item 2) f – screw fastening white take-off board g – adjustable foot of stainless steel base board Instruction manual S12-250 ver. 2018 13/15... -
Page 14: Additional Equipment, Available Separately
Plasticine straps for indicator board P8x31 Set of 8 red plasticine straps, specially shaped, ready to be put into the indicator board recess, designed for Polanik competition take-off boards Rubber indicator board for competition board LG15-250 black full rubber indicator board designed for... -
Page 15: Wa Certificate
7. WA Certificate Instruction manual S12-250 ver. 2018 15/15...
