- Page 1 GETINGE 88-SERIES USER MANUAL 502404300 SEV0647139-...
-
Page 2: Table Of Contents
Contents FOREWORD ____________________________________________3 SAFETY REGULATIONS _________________________________4 INTRODUCTION ________________________________________5 Intended use of the machine _________________________________ 5 Symbols on the machine ____________________________________ 5 Attention symbols __________________________________________ 5 General ___________________________________________________ 5 Control system _____________________________________________ 7 Door function ______________________________________________ 7 Dosing system _____________________________________________ 8 OPERATING INSTRUCTIONS_____________________________9 Machine without barcode scanner ____________________________ 9 Machine with barcode scanner _______________________________ 10... -
Page 3: Foreword
FOREWORD This instruction manual is intended for users of the Getinge washer disinfector 88-5. The instruction manual describes the design and operation of the machine and the main- tenance for which the user is responsible. The purpose of the information in the manual is to ensure safe operation and optimum efficiency. -
Page 4: Safety Regulations
• Spare parts may only be obtained from Getinge EDC. Product liability Any modification or incorrect use of the equipment without the approval of Getinge Dis- infection AB invalidates Getinge Disinfection AB’s product liability. This product was manufactured by: GETINGE DISINFECTION AB Ljungadalsgatan 11, Box 1505 351 15 Växjö, Sweden... -
Page 5: Introduction
OP shoes. Depending on program design. Validation of goods according to intended use is done with Getinge Disinfection AB’s standard loads. An Installation Qualification, an Operating Qualification and a Performance Qualification according to ISO 15883 must be carried out before putting the machine into service. - Page 6 The machine is operated from the control panels, one to the left of the door on the soiled side and one on the right of the door on the clean side. The picture below shows the location of buttons and indicators on both panels. Panel, soiled side Before starting: Chosen program Program...
-
Page 7: Control System
Control system The machine has an electronic controller which can hold up to 64 programs, 16 of which can be started (activated). You can choose six of these programs with the program selec- tion buttons. To choose the others, use the menu buttons; see under Operating instruc- tions. -
Page 8: Dosing System
Dosing system In standard form, the machine has two dosing systems. One is for alkaline detergent and one is for rinse-aid or acid detergent. The dosing amount can be set individually for each program. The machine cannot be started until detergent has been added. If the detergent holder is empty, “DOS 1 LOW LEVEL”, for example, appears on the display. -
Page 9: Operating Instructions
OPERATING INSTRUCTIONS Machine without barcode scanner Loading goods to be washed into the machine • Load the items to be washed on to the trolley and run the trolley into the machine. Examples showing how to load the trolley are shown on the goods positioning sign and in the loading handbook. -
Page 10: Machine With Barcode Scanner
Machine with barcode scanner Every wash trolley has its own unique five-digit number. The first two digits indicate which wash program is to be used; the third digit is for extra equipment and the last two are the trolley’s ID. Loading goods to be washed into the machine •... - Page 11 While a program is running While the program is running, a yellow lamp at M is lit and the program phase (e.g. “Rinse”) and the current temperature are shown on the display. Press S to see how much time remains. When the program is complete When the program is complete, a green lamp lights up at N and the clean-side door •...
-
Page 12: Positioning The Items
Do not use detergent for household dishwashers. • Follow the detergent manufacturer’s dosage instructions. The cleaning effect can vary between different detergents. If the cleaning result is not satisfactory, try an- other quality detergent before contacting Getinge. Page 1 of 4... -
Page 13: Daily Inspection
Daily inspection • Check that no objects have fallen down into the bottom of the washing chamber. Loose objects may cause blockages and seriously reduce the performance of the washer disinfector. • Check that the spray arms can rotate freely. Check that the holes in the spray arms are not blocked. -
Page 14: If Necessary
If necessary Spray arm Clean the spray arms when necessary by unscrewing the central nut, lifting off the spray arm and rinsing it until it is clean. Take off the plastic end pieces by pressing the metal bar over the edge of the rinse arm and removing them. Using a washing brush, clean the inside of the spray arm. -
Page 15: Printer (Option)
Printer (Option) Replacing the paper roll • Open the front door of the printer. • Remove any paper residue. • Fold down the printing mechanism by pressing the latch marked PUSH (A). V1973 • Cut the end of the new roll square (B). (This makes it easier to thread the paper into the printer mechanism.) V197 •... - Page 16 Ribbon cassette replacement • Open the front door of the printer. • Remove the ink ribbon by pressing gently on the left-hand side of the ribbon cassette. V1973 • Insert the new ribbon cassette. The printer is now ready to use again. Never use the printer without paper and/or ink ribbon.
-
Page 17: Process
PROCESS Changing parameters Normally the preset parameter settings of the installed programs are used, but in special cases it may be necessary to adjust certain parameters for matching to a specific wash process. Information about the parameters that can be changed and their limit values can be found under heading “A- or P-parameters”... -
Page 18: Fault Indications
FAULT INDICATIONS Handling alarm Handling alarm or fault code or fault code P01 OP-SHORT-D P01 OP-SHORT-D DOSE 1 LOW LEVEL DOSE 1 LOW LEVEL Red lamp: Alarm indi- cation Red lamp: Alarm indication V133 J131 Panel, soiled side Panel, clean side Handling alarms Handling alarms appear on the display in plain text. -
Page 19: Alarms
Alarms If the red lamp at O lights up, the process has been aborted because of a fault. The display shows a fault code, Acknowledging a fault code Acknowledge the fault code as follows: • Note the fault code Cancel the acoustic signal by pressing U. The machine remains locked but the •... - Page 20 Fault code Description Not enough detergent 2 dosed Not enough detergent 3 dosed Not enough detergent 4 dosed High conductivity. Low pressure in drying unit. High pressure in drying unit. Low pressure from circulation pump. High pressure from circulation pump. Low temperature in drying unit.
-
Page 21: Detergents
Detergents The machine has been tested with Getinge detergents. We recommend that you use Ge- tinge detergent or equivalent detergent from a reputable manufacturer. Do not use detergent for household dishwashers. The recommendation of chemical agents does not mean that the manufacturer of the machine bears responsibility for the effects of these agents on the goods. -
Page 22: Water Quality - Washer Disinfectors
High concentrations of and high exposure to sanitary chemicals may cause corrosion and pitting on stainless steel. Getinge Disinfection AB therefore recommends that water used in the pre-rinsing, wash- ing and final rinsing phases should be of drinkable quality in accordance with the guide- lines. - Page 23 Page 3 of 4...
- Page 24 Australia France South Africa Getinge Australia Pty Ltd Getinge France SAS Getinge South Africa (Pty) Ltd 154 Lytton Road BP 49, avenue du Canada P O Box 4849 Bulimba Qld 4171 ZA de Courtaboeuf Hercules info@getinge.com.au Les Ulis, FR-9194 Pretoria SA 000 getinge.france@getinge.fr...
